- Page 1 English Model : iMM183 Instruction Manual Weather Radio Dual Alarm Clock for Your iPhone® and iPod® NOAA weather – all 7 channels | S.A.M.E Weather Hazard Alert...
- Page 2 24 hours a day as a public service. iMM183 receives all seven NOAA channels; it has an automatic alert system; in the event of a special warning broadcast, the receiver will automatically activate along with a loud tone; a flashing LED indicator;...
- Page 3 • All hazard weather alert system • SAME decode and alert message display • Store up to 10 alert messages • LED warning indicator *Compatible with any iPod with dock connector (Excluding 1 , and 3 generation iPod) iMM183 | V10M10_IM_EN_09092009 iLuv | 2...
-
Page 4: Table Of Contents
Setting the Clock Using the Time Sync Feature Sleep Mode Setting the Treble / Bass Mute Function Dimmer Setting Setting the Alarm Snooze Function Using the FM Radio iPhone and iPod Operation iPhone Function Menu and Enter Repeat 3 | iLuv... - Page 5 Turning the Alert ON / OFF Setting the Alert Volume Selectable Alert Option Testing the Alert Reviewing Alerts Deleting Alerts LED Indicators Alert Out Socket Low Battery indication No Reception Warning Maintenance Troubleshooting Guide User Safety Guide iMM183 | V10M10_IM_EN_09092009 iLuv | 4...
-
Page 6: Getting Started
2. Insert a “CR2025” 3V lithium battery making certain to follow the correct polarity. Observe the corresponding symbols (+/-). 3. Secure battery and push the battery holder back into the remote control until it is fully inserted. 5 | iLuv... -
Page 7: Installing The Dock Adapter
• Remove spent batteries immediately and dispose of them. • Do not use old and new batteries together. Also never use an alkaline battery with a magnesium battery. Backup battery time is approximately 54 hours. iMM183 | V10M10_IM_EN_09092009 iLuv | 6... -
Page 8: Location Of Controls On The Main Unit
22. WEATHER/HAZARD ON/OFF button 11. SETUP button 23. ALERT button 12. ENTER button SELECT AL SET AUTO SCAN SLEEP BASS/TREBLE SETUP MODE ENTER POWER ALERT 1 - 2 3 - 4 5 - 6 AL OFF VOLUME SEARCH 7 | iLuv... -
Page 9: Location Of Controls On The Remote Control
6. SNOOZE/DIMMER Button 17. BASS TREBLE Button 7. MODE Button MEMORY 18. WEATHER/HAZARD Button 8. SLEEP Button 19. REPEAT Button 9. MENU Button SNOOZE/DIMMER 10. SETUP Button BASS MODE MUTE TREBLE WEATHER SLEEP HAZARD iMM183 | V10M10_IM_EN_09092009 iLuv | 8... -
Page 10: Location Of Indications On The Lcd Screen
ST Indicator ALL Indicator MONO Indicator SINGLE Indicator WB RSSI Indicator MULTIPLE Indicator COUNTY Indicator PLAY, PAUSE REPEAT, RANDOM Indicator Date/Settings, Volume, Weather, Bass/Treble, Sleep Display KEY, SLEEP, BATTERY, KHz, MHz Indicator NOAA Indicator Clock/Radio Frequency/Time Display 9 | iLuv... -
Page 11: Operational Instructions
Select Source Press MODE on main unit or on remote control, to select: iPod iPod… Radio Tuner Press MODE on the main unit or remote control, and the "FM" icon will appear on the display. iMM183 | V10M10_IM_EN_09092009 iLuv | 10... -
Page 12: Using The Ipod Function
0 and 40 (40 is Max). For example: “VOLUME: 23” may display current volume level. This volume level setting will be stored when the unit is power off. When the unit is powered on, the unit will return to this volume setting. 11 | iLuv... -
Page 13: Setting The Clock
• Press ENTER to confirm. "SET DATE" and a flashing number will display on the screen. In the same way, set Day > Year > Hour > Minute. • To exit clock setting mode, Press SETUP. The time and date will display on the screen. iMM183 | V10M10_IM_EN_09092009 iLuv | 12... -
Page 14: Using The Time Sync Feature
OPERATIONAL INSTRUCTIONS Using the Time Sync Feature The iMM183 is equipped with a Time Sync function which sets the time and date on the clock in sync with a docked iPhone or iPod. • In the power OFF (Standby) mode, press SETUP on the unit and rotate the SEARCH wheel to select "1. -
Page 15: Sleep Mode
2. “MUTE” will display on the screen. 3. Press MUTE again to resume normal playback. Dimmer Setting 1. Press SNOOZE / DIMMER during normal operation to adjust the brightness of LCD display. 2. Dimmer grade: 8 levels iMM183 | V10M10_IM_EN_09092009 iLuv | 14... -
Page 16: Setting The Alarm
OPERATIONAL INSTRUCTIONS Setting the Alarm The Alarm 1 and Alarm 2 functions can only be set while the iMM183 is in Standby mode. 1. Press AL SET, the (alarm 1) and (alarm 2) icons will flash on the screen. 2. Press AL1 or AL2 to select the alarm 1 or alarm 2 to set and the hour will flash. -
Page 17: Snooze Function
1. Press SNOOZE / DIMMER when the alarm sounds. 2. The alarm will be silenced and come on again. 3. Snooze can be pressed several times during the 1 hour alarm period. 4. Snooze interval time is 9 minutes. iMM183 | V10M10_IM_EN_09092009 iLuv | 16... -
Page 18: Using The Fm Radio
SKIP /AUTO SCAN on remote control to search automatically for a clear station. 3. Press volume button or rotate the VOLUME wheel to adjust iMM183 volume up or down. 4. Press access a radio presets, just press any one of the radio preset buttons (preset 6 stations). -
Page 19: Iphone And Ipod Operation
1. Press REPEAT once on remote control while your iPhone or iPod is playing. The current track will repeat. 2. Press REPEAT twice on remote control while your iPhone or iPod is playing. All tracks will repeat. iMM183 | V10M10_IM_EN_09092009 iLuv | 18... -
Page 20: Weather Band Operation
WEATHER BAND OPERATION Obtaining Weather Channel/County Codes from NOAA In order to receive alerts, iMM183 must be set to the correct weather channel and county codes) (FIPS code). To get this information for your area, call the NWS toll free number: 1-888-NWS-SAME (1-888-697-7263), or visit the website: www.nws.noaa.gov/nwr/indexnw.htm... -
Page 21: Programming A Single S.a.m.e. County Code
9. To program your next code, rotate the SEARCH wheel to go to the next code location. When you have entered all your desired codes, press SETUP to store your settings. iMM183 | V10M10_IM_EN_09092009 iLuv | 20... -
Page 22: Deleting The County Code
2. Rotate the SEARCH wheel until “5. SIREN LEVEL” is displayed. 3. Press ENTER and “HIGH”, "MID" or “LOW” will start blinking. 4. Then rotate the SEARCH wheel to choose “HIGH”, "MID" or “LOW” volume. 5. Press ENTER to save your setting. 21 | iLuv... -
Page 23: Selectable Alert Option
5. Press ENTER again to silence the alarm. Reviewing Alerts The iMM183 weather receiver can store 10 different alerts/events with overlapping effective time in its memory. If the receiver receives a new alert while a previous alert is still in effect, it automatically displays the new alert message. -
Page 24: Deleting Alerts
NOTE: The color-coded indicator will remain illuminated until the alert/event expires. Alert Out Socket The Alert Out socket is provided on the back of the iMM183. The socket’s output is compatible with home automation alert devices for a loud siren. -
Page 25: No Reception Warning
United States. Currently, only a few areas are not covered. Typical broadcasts are within reception distance of 25-50 miles of the weather station. iMM183 weather receiver can receive broadcasts from up to 50 miles from the weather station, depending on your location and conditions of weather, terrain, etc. -
Page 26: Troubleshooting Guide
Please refer to the owner’s instruction manual of your iPod. c. You are using the first, second, or third generation of iPod. First, second, and third generation of iPod is only charged with the FireWire connection. The FireWire connection is not supported by the system. 25 | iLuv... - Page 27 The installed battery is weak. Replace with a new battery. b. It is not aimed to the system or too far away from it. Move within 10 feet of the unit and point the remote control toward the system. iMM183 | V10M10_IM_EN_09092009 iLuv | 26...
-
Page 28: User Safety Guide
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the 27 | iLuv... - Page 29 17. The MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. iMM183 | V10M10_IM_EN_09092009 iLuv | 28...
- Page 30 Please remember to respect the local regulations: Hand in the non-working electri- cal equipment to an appropriate waste disposal center. FOR USED BATTERIES Disposed of the used batteries properly. Please follow the local regulations for the battery disposal. 29 | iLuv...
- Page 31 Note: Do not make changes or modify the device in any way. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. iMM183 | V10M10_IM_EN_09092009 iLuv | 30...
- Page 32 Damage to your hearing is accumulative and is irreversible. Any ringing or discomfort in the ears indicates that the volume is too loud. Once you have established a comfortable listening level, DO NOT INCREASE THE VOLUME LEVEL FURTHER. 31 | iLuv...
- Page 33 • Mains plug is used as the disconnect device. It shall remain readily operable and should not be obstructed during intended use. To be completely disconnected, the apparatus from supply mains, the mains plug of the apparatus shall be disconnected from the mains socket outlet completely. iMM183 | V10M10_IM_EN_09092009 iLuv | 32...
- Page 34 · No naked flame sources such as lighted candles should be placed on the apparatus. · Dispose of used batteries properly. Follow the local regulation for the battery disposal. · Use this apparatus in the moderate climates. It is recommended not to use this apparatus such in a lighting storm. 33 | iLuv...
- Page 35 AC100V~240V 60/50Hz Adapter "AA" size x 6 batteries • Power consumption: ≤22W • Dimensions (W x H x D): 11.2” x 3.4” x 7.2” (284mm x 87mm x 183mm) • Unit weight: 5.31lbs (2.4kg) iMM183 | V10M10_IM_EN_09092009 iLuv | 34...
