Cloud Camera user manual
IP Camera - CM-IPMP
Note: after the setup , in Order to protect your privacy please modify the factory
password, and keep the user name and password safe.
Manual version:
Version
V1.0

(HD Cloud camera)
User's manual
M
o
d
e
l
: CM-IPMP
M
o
d
e
l
:
Date
September 16, 2012
description
CM-IPMP revised version of A1
1
