Cloud Camera user manuals
IP Camera
Note: To protect your privacy, please modify the default password after landing, and
please take good care of your username and password.
Manual version:
Version
Dates
V1.0
Sep. 16, 2012
V1.1
Nov. 12, 2012
Note: in practical application, it is possible that the instruction functions are a little
different from the function of the machine .
(HD Cloud Camera )
User's manual
M
o
d
M
o
d
Description
Adjustment of interface
e
l
:
I
P
C
2
e
l
:
I
P
C
2
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cloud IPC2
Summary of Contents for Cloud IPC2
- Page 1 Cloud Camera user manuals IP Camera (HD Cloud Camera ) User's manual Note: To protect your privacy, please modify the default password after landing, and please take good care of your username and password. Manual version: Version Dates Description V1.0 Sep. 16, 2012 V1.1 Nov. 12, 2012 Adjustment of interface Note: in practical application, it is possible that the instruction functions are a little different from the function of the machine . 1 ...
-
Page 2: Table Of Contents
Cloud Camera user manuals Content Product Overview:..........................4 Packing List..........................4 System Requirements........................4 Introduction ..........................4 Features.............................5 Overview of the Hardware view....................6 Installation............................8 Hardware Installation........................8 Camera Installation Wizard ....................8 Wireless Installation Considerations..................11 Homepage ............................12 First: Camera status bar: ......................12 Second: Image settings and PTZ control bar................13 THIRD. Interface buttons:......................13 Playback ............................14 Management...........................16 1. Product information......................16 2. Equipment:..........................16 Equipment nickname ......................17 Password .........................17 3. Media stream: ........................17 ... - Page 3 Cloud Camera user manuals 9. Date / Time: ........................25 Date ..........................25 Time server address ......................25 10. System maintenance: ......................25 Online upgrade........................26 Restore the default settings ....................26 Restart the device ......................26 11. Others:..........................26 PTZ...........................26 Audio ..........................26 Equipment flip.........................27 Troubleshooting ..........................27 Wireless Infrastructure ........................30 Wireless Security..........................32 Technical parameters ........................34 ...
-
Page 4: Product Overview
Cloud Camera user manuals Product Overview: Packing List A set of network Camera An Ethernet cable A set of 5V power adapter A piece of CD Quick Installation Guidelines A set of bracket (base) and mounting A warranty card Note: The use of non‐product rated voltage power supply, will result in equipment damage, and does not enjoy the product warranty. If something is missing of these items, please contact your dealer. System Requirements • With Microsoft Windows ® 7, Vista ®, XP ®, Mac OS or Linux system computer ... -
Page 5: Features
Cloud Camera user manuals network perfectly .The Cloud Camera also has remote monitoring and motion detection function, making it a complete, cost‐effective home security solution. Features Can support H.264/MPEG4/MJPEG stream, suitable for Local, Internet access as well as cross‐platform; CMOS sensor, support 1280 * 720,640 * 360 , 320 * 180,160 * 90 real‐time video encoding; Support watching the video screen in the smartphone anywhere and anytime, support Windows Phone, Android system smartphone / IPHONE phone / IPAD devices to ensure the image smooth / no stumble. (25 image transmission, can watch 720P HD image); P2P technology‐free configuration, plug‐and‐play (no need to do port mapping , DNS, IP address settings) A key WPS easy wireless connectivity, privacy features, arm function. Intelligent transmission technology (bandwidth adaptive ,code rate adjust dynamically , the priority voice, jitter buffer). Support two‐way voice intercom, the use of carrier‐grade signal processing ... -
Page 6: Overview Of The Hardware View
Cloud Camera user manuals Support polytype browser viewing device video, such as IE / Firefox / Safari / Google Chrome, etc.; Support Flash Player, Quicktime, Realplayer, VLC, Mplayer player direct access to the Camera. Infrared LED for night vision range of 8 meters, whole day monitoring; support IRCUT, day / night filter switch, Image unbiased color Built‐in wifi modules, and the flexibility to set up wireless monitoring environment; Maximum support 32G SD card storage, alarm photographed and alarm video; Support the PIR (human infrared thermal sensing).Double insurance arm, to prevent false triggering. Overview of the Hardware view STA1 Status Light ... - Page 7 Cloud Camera user manuals Headset/ audio jack Ethernet interface DC5V power interface Reset FN composite button Camera base ...
-
Page 8: Installation
Cloud Camera user manuals Installation Hardware Installation Connect the network cable and power Attach the Ethernet cord into Ethernet port behind IPCAM and the other end into the router or other network equipment, to access network. Connect the original power supply into the wall power outlet or line board, then connect the power of the DC head into the DC power input port behind the Camera, when the PWR indicator lights up in red, indicating the normal supply of electricity. External audio output interface: Inserted the External 3.5 inch headphone connector into the AUDIO OUT Jack. Camera Installation Wizard The first step : connecting the network: 1. Wired internet: IPCAM connected to the power supply and cable network, the front of the machine "PWR" light a STA2 long red light. 'STA2 "lights turn red, Wait 20 seconds, into indicator a green light flashes (flashing seven times every three seconds). 2. Wi‐Fi: You can use the WI‐FI Protected Setup (WPS) button for Camera to create wireless connection. IPCAM connect electric and start, a: press button the "FN" button for three seconds under the rear of the machine, then STA2 green LED indicator light began to flicker. b: press the WPS button on the router in 60 seconds,. WPS button is usually in the front or side of the router. Some ... - Page 9 Cloud Camera user manuals the screen to start the WPS characteristics. If you are not sure whether your router has the WPS button, check the user manual of the router. After a successful connection , The green light of STA2 flashes (every 3 seconds flashing 7 under). Note: The router's DHCP server function must be enabled. The second step : landing: A: Open the browser,input http://www.mipcm.com/ in the address bar, enter the following login screen, enter the ID number and password of the machine (each IPCAM is labeled with a unique ID number and password, need to scratch off the ...
- Page 10 Cloud Camera user manuals Use ID landing interface Registered users landing interface Click the play C: install plug‐ins: 10 ...
-
Page 11: Wireless Installation Considerations
Cloud Camera user manuals Click on the install plugin Note: If the user's router is not connected to the Internet, users can watch video via LAN. Running the searching tool in the CD‐ROM to search the IP address of the IPCAM. .Double‐click the IP address into the login screen. If the video image is blurring maybe the Camera lens and CMOS sensor is not in a good focal ,please let the camera aims at the object away from 5 meters, slowly turn the lens repeatedly and slowly by hand until the image be the clearest. Wireless Installation Considerations Wireless IP cameras allow you to access the network in any wireless coverage area by using a wireless connection. However, the wireless signal is required to pass through the walls, ceilings and other objects, the number, thickness, and position will limit its scope. Usually the change of coverage, depends on your room or office type of building materials and environmental RF (radio frequency) noise. Follow these basic guidelines can maximize the wireless range: 1. The Wall, ceiling between the routers and other network devices (such as ... -
Page 12: Homepage
Cloud Camera user manuals objects, such as glass, steel, metal, band insulator, water (fish tanks), mirrors, file cabinets, brick and concrete walls will weaken the wireless signal. 4. The product was placed in a position away from generating the RF noise of electronic devices and appliances at least 3‐6 feet or 1‐2 meters. 5. If you are using 2.4GHz cordless phones or other radio emitting source equipment (such as microwave ovens), your wireless connection may obviously deteriorated or completely dropped. Put the 2.4GHz phone base away from the wireless device as far as possible. Even if the phone is not using the dock will still transmit signals. Homepage Logged in, displays the home page, click on the Play button, and display real‐time video images. Double-click the video to watch window, can full display: First: Camera status bar: 1. Here, you can see the online status of each Camera.Online status for the following categories: • Green means that your Camera is online and ready. • Yellow means the Camera online, but the Camera password ... -
Page 13: Second: Image Settings And Ptz Control Bar
Cloud Camera user manuals • Red indicates the Camera is offline and not accessible remotely. If the Camera is offline, try the following approaches: • Check and make sure the Camera's network connection is normal. • Try restarting your network router. • Check the Camera cable connections to ensure they are secure connection. • Check and confirm the Camera STA2 the green light flashes flashing (every 3 seconds flashing 7 times ). If you still cannot access your Camera, please restart the camera. 2. : Search the IPCAM in the local LAN, add the outer IPCAM and manage the Cameras have been added. 3 . : The status bar to show and hide icons. Second: Image settings and PTZ control bar. 1. : Exit the video interface. 2. Brightness: adjust the brightness level of the video screen. 3. Contrast: adjust the video screen contrast level. 4. Saturation: adjust the video screen color saturation level. : PTZ control IPCAM up / down / left / right rotation. 6. : Control the size of the voice of the computer . 7. : Status bar display and hide the icon. THIRD. Interface buttons: ... -
Page 14: Playback
Cloud Camera user manuals 2. Record button (the recorded files are stored‐FLASH card): Click button on the audio / video recording , the recording icon indicates Click on the inverted triangle button to enter the mode : The plans record: when optioned, can choose 7 days a week, 24 hours intermittent video and regular video. Alarm Recording: When checked, the implementation of the alarm video Optional I / O alarm mobile investigative Alarm. Length of time "refers to the pre‐recorded trigger Video before the video can be directly input time, second unit. 'Duration "refers to the reported the police recording time can be directly input time ,second unit. The recorded single frequency: When optioned ,sound recording when select the alarm recording. 3. Snapshot button: Click the button to capture images of the playing video. Click on the inverted triangle button , selectable resolution (1280 * 720,640 * 360,320 * 180,160 * 90). 4. Intercom: click buttons, open the microphone / loudspeaker in Camera and computer, two way sound speaker,can hear each other's voice Playback Play the video files recorded in the SD card. ... - Page 15 Cloud Camera user manuals Video file query Camera and directory list: list Progress bar and Previ play/paus next queries to the video Fast 数 fast reve 1.Select the Camera in the Camera List. 2. Queries the video files , documents and more information on the right in the image by time. ...
-
Page 16: Management
Cloud Camera user manuals Management This section do the configuration of the Camera settings. 1. Product information : Quit, returns to the landing Display the basic information of the Camera. Modify registered users password Model: The model of the Camera. Firmware version: the Camera software firmware version number. Plug‐in version: the Camera video viewing plug‐in version number. Device serial number: ID number of the Camera. 2. Equipment: Modify the Camera password.. 16 ... -
Page 17: Equipment Nickname
Cloud Camera user manuals Equipment nickname : the name of the Camera, the user can according to their own requirements to change the name. Password : modify the current Camera to enter the login password of the current Camera New Password: here, the user can enter the current Camera landed a new password. (To protect your privacy, after landing modify the default password, and please take good care of the user name and password.) Confirm Password: Re‐enter the password of the current Camera modified. Click” Apply” to save your changes. 3. Media stream : Audio / video stream bit rate settings. 17 ... -
Page 18: Stream
Cloud Camera user manuals Stream : means the video stream ,have high (HD) / normal (normal) / half (half) / (min) four, and their corresponding resolution of 1280*720, 640*360, 320*180, 160*90.Different stream, Framerate / bitrate / I frame interval set. Image : Resolution: The resolution of the image display. Select a different stream, corresponding to the different resolution. Framerate: the number of images per second, use fps. The larger the frame rate, the more fluent image. Bit rate: use bps. The higher the Bit rate, image display more clear, but the highest occupied network resources. The user can set a maximum and minimum values. I frame interval: send each key frame interval. Audio Encoding types: audio encoding, G.711, G.726, AMR, AAC four encoding. Sampling rate: refers to the frequency of the audio samples. Click” Apply” to save your changes. 18 ... -
Page 19: Network
Cloud Camera user manuals 4. Network: NIC: Ethernet (wired) and wireless networks. 1. Ethernet : Effective when connected to wired network. Startup Status: Displays the current Ethernet enable / disable. Mac address: Displays the current Ethernet Mac address. Automatically obtain an IP address (Cameras default): select Camera Machine automatically get connected to the router and it is automatically assigned to IP address / gateway / subnet mask information. Use the following IP address: Check the user manual allocation One IP address / gateway / subnet mask to the Camera. Dns server address automatically exercised: Check, Camera Automatically get to be automatically assigned to the router connected to it DNS information. 19 ... -
Page 20: Wireless Network
Cloud Camera user manuals Following dns server addresses: when checked, user manually assign DNS to the Camera 2. Wireless Network : NIC choose a wireless network. Startup Status: Displays the current wireless network, enable / disable. Wireless mode: hot / terminal A. Hot spot: as the default search equipment, network Cameras, wireless ,Hot mode, wireless devices through wireless search Point to point connection to the Camera. DHCP: Dynamic Host Configuration Protocol for wireless hotspots, starting address to the end of the address and gateway. B. Terminal: As search equipment. Connection Status: Displays the status of the wireless network. Select Network: Wireless will automatically search for the Cameras surrounding the wireless, choose the Network terminal in the drop‐down list. Password: Enter the password for the wireless network equipment. Click the connect button to connect the selected wireless Click Apply to save your changes. Mac address: displays the current wireless network Mac address. Automatically obtain an IP address (Cameras ... -
Page 21: Osd
Cloud Camera user manuals Use the following IP address: Check the user manual allocation One IP address / gateway / subnet mask to the Camera. Dns server address automatically exercised: Check, Camera Automatically get to be automatically assigned to the router connected to it Its DNS information. Following dns server addresses: Check user Manually assign DNS to the Camera. Click Apply to save your changes. 5. OSD: Image screen display menu settings. Display Name : Check the upper left corner of the screen will display the name of the Camera. Name: The user can modify the screen displays the name of the Camera. (can't have Chinese and symbol, is only English and Allah hundred digital) Display: Check the upper left corner of the screen will display the date. Date format: User selectable year / month / day or month / day / year both date formats. Show time : check, will be displayed in the upper left corner of the screen time. Time format: user can select 24‐hour or 12‐hour clock. 21 ... -
Page 22: Display Week
Cloud Camera user manuals Display week : Check the upper left corner of the screen displays the day of the week. Click Apply to save your changes 6. SD card : Display the status of the Camera SD card. Status : Displays the current SD card plugged into the Camera and whether it has been read to the Camera. Capacity : Show the total size of the plug into the Camera's SD card. Usage : displays the current plug into the SD card in the Camera has been used in the situation. Click Apply to save your changes. 22 ... -
Page 23: Alarm
Cloud Camera user manuals 7. Alarm : External input arming : trigger signal input, an external alarm sensor probe (such as smoke alarms probe).When checked can select normally closed or normally open in mode according to the type of external alarm probe equipment. IO linkage : the alarm trigger signal output, external alarm equipment (such as speaker equipment).When Checked, the machine triggered the alarm linkage output alarm signal to trigger external alarm, normally closed or normally open mode depending on the type of external alarm devices. Click Apply to save your changes. 8.Joural Record all operation to the IPCAM according to the time sequence record. 23 ... - Page 24 Cloud Camera user manuals refer Camera list 1. Choose the camera in the camera list. 2. Start time: Choose the start time. 3. Finish time: Choose the finish time. 4. Choose the station. 5. Inquire. 24 ...
-
Page 25: Date / Time
Cloud Camera user manuals 9. Date / Time : Date : The date of the Camera can be manually modified. Time: Time of the Camera can be manually modified. Automatically synchronized with the time server: When checked , Camera time is automatically synchronized with the server time. Time server address : the address of the time server. Click Apply to save your changes. System maintenance 10. : 25 ... -
Page 26: Online Upgrade
Cloud Camera user manuals Online upgrade : If have the latest software, will prompt <update> ,click update, the Camera will upgrade the software online. Note: Software upgrading is a certain risk to the camera, when software upgrading cannot cut off the network and power, or the machine will be dead. Restore the default settings : click the Restore button, the Camera will be restored to the factory default settings, will cancel the manual camera settings. Restart the device : Click the reset button to restart the Camera. Click Apply to save your changes. 11. Others : : Speed: PTZ speed parameter settings, the greater the value, the faster the PTZ. Audio : Speaker: Setting the sound size of the camera speakers, using the mouse to drag the slide bar,the greater the value, the greater of the sound . Microphone: Setting the sensitivity of the camera microphone, using the mouse to drag the slide bar , the greater the value, the more sensitive of the microphone ,the more sound receiving from external environment, the greater of the computer voice, listen to the voice of the computer end, the greater of the environment noise accordingly. 26 ... -
Page 27: Equipment Flip
Cloud Camera user manuals Equipment flip : When checked,the picture for up/down ,left/right and the PTZ will collover,is suitable for backwards setting. Power frequency: have 50 Hz and 60Hz.User can choose the Hz according to the local power frequency. Click Apply to save your changes. Troubleshooting This chapter provides solutions to problems that may be arised in the IP CAMERA installment and running. If you encounter the problems, please read the following descriptions. (The following example is based on Windows ® Vista ™ and XP Description .If you are using a different operating system, your computer screen is similar with the following example.) 1. What is remote access? What can I do? Through remote access, you can use a web browser from any PC connected to the Internet to access the Camera. So even if you are not at home, you can watch the Camera images, and manage the Camera settings. To enable remote access, you can simply follow the Quick Installation Wizard. If you are not connected on the camera, make sure the following items: ..The green LED Camera on SETATE2 green light flashes (every three seconds shine 5 times ) ..Network connection is working properly ... Router's LAN & WAN connection is working properly. ... The router has enabled UPnP. ... The router can get a public network IP. ... The router has been upgraded to the latest firmware version. ... You have tried to restart the router by unplugging the power and then plug it again After the completion of the inspection of the above, you can re‐landing. 2. Why photo Camera's network connection unreliable? The network cable may be a problem.To make Sure the cable is working, PING the known address of the device in network. If the cable connection is correct and your ... - Page 28 Cloud Camera user manuals such as hubs or switches. Make sure the power for all devices are connected and working properly. 3. Why Network Camera work locally, but the remote does not work? This may be caused by the firewall protection , check network firewall with your system administrator. The firewall may need to make some configuration changes, in order to access to the network Camera externally from your local LAN,. For more detailed information, please refer to the relevant sections of the Cameras installed in the router backend. Ensure that the network Camera does not conflict with any Web server running in ...
- Page 29 Cloud Camera user manuals 8. PIR poor perfomance, how to improve the quality? ‐ Need direct induction sensors, it does not apply to the room for multiple obstacles, or glass window barrier items. ‐ High temperature sensing performance than the low temperature slightly lower, this is the normal, non‐sensor damage. ‐ Only for indoor enclosed space, and installation location should avoid the glass doors and windows, direct sunlight, car headlights, alien infrared interference. ‐ Should be avoided in the air conditioning vent and vents or air purifiers, humidifiers similar equipment, etc. ‐ Susceptible to RF radiation interference, away from the place of the wireless device equipped with a high‐power. ‐ This sensor main detects the lateral movement , the longitudinal movement ...
-
Page 30: Wireless Infrastructure
Cloud Camera user manuals 2 under flashing every Did not get to the IP address 3seconds STA2 (red light) 2 under flashing every Connected on the router, but 3seconds not connected to external networks 5 under flashing every Wired is connected to external STA2 (green) 3seconds networks, and can be accessed remotely 7 under flashing every Wireless connection on the 3seconds outside network, remote access Wireless Infrastructure Wireless IP CAMERA products are based on industry standards for your home, ... - Page 31 Cloud Camera user manuals IPC1 is the world's leading camera, you can use smart phone access remote monitoring and get smooth video, and equipped with real P2P technology. IPC1 products are at reasonable prices and excellent performance. The wireless network is how does it work? Similar with the wireless phone ,the wireless network transmit data from point A to point B via wireless signal. However, for wireless network there are some restrictions on how you can access the network. You must be within the coverage of the wireless network, in order to connect to your computer. The wireless network is divided into two different types : wireless local area network (WLAN) and wireless personal area network (WPAN). Wireless local area network (WLAN) In a wireless local area network, the access point (AP) as the computer device to access the network.Access point has a small antenna, whether through radio signals to and from the transmission data.Indoor access point shown in the drawing, the signal can reach a distance of 300 feet. In outdoor,the signal distance of access point can reach 30 miles at most, can be used such as a factory floor, industrial areas, college and high school campuses, airports, golf courses, as well as many outdoor occasions. Which kind of person are suitable for wireless network? Wireless network technology be more and more popular in recent years, almost everyone is using it ,No matter for the home, office and business, D‐Link can offer the wireless solution . Home • provide broadband access for everyone at home • browse the web, view email, instant messaging, etc. • No cable connection in the room around • Simple and easy to operate SOHO (Small Office and Home Office) • Everything will be in your hands when you are at home as well as in the office. • Remotely access your office from home . •Share an Internet connection and a printer with multiple computers . • Do not require a dedicated office space Where to use the wireless network ? Not just confined to the home and office, wireless technology has being ...
-
Page 32: Wireless Security
Cloud Camera user manuals networks are becoming increasingly popular, more and more public places begin offering wireless access to attract people. The wireless connection in public places is usually called "hot spots". Use a wireless card in your laptop, you can be in distant places such as: airports, hotels, cafes, libraries, restaurants and conference center with wireless network. The wireless network is easy to install, if you first installed, you will need to work hard to understand where to start. This is why we want to provide some of the installation steps and tips to help you complete the installation process . Tips When you install a wireless network, please note the following: Place your router or access point in the center position Verify that your router / access point on the center position of the network, in order to get the best results. Try to place the router / access point to the highest point in the room, so that the signal can be distributed to your room.If your home is a two‐story building, you need to install the repeater signal expanding coverage. Eliminate interference Household appliances, such as cordless phones, microwaves, and televisions as far as possible from the router / access point. This will greatly reduce the electrical interference caused by the work of the same frequency. Security Prevent your next door neighbors or intruders connect to your wireless network. Open the router's WPA or WEP security features to protect your wireless network.Please refer to the product manual to set the properties detailed information. Wireless Security This section describes the different levels of security you can use to protect your data from intrusion. . ipc1 provides the following security types: • WPA‐PSK (pre‐shared password) • WEP (Wired Equivalent Privacy) ... - Page 33 Cloud Camera user manuals What is WEP? WEP means Wired Equivalent Privacy. It is based on the IEEE 802.11 standard, using the RC4 encryption algorithm. WEP for data encryption on your wireless network to provide security, so that it can protect the security of transmission from one wireless device to another. To access the WEP network, you must know the key. The key is the string you create. Using WEP, you must specify the level of encryption. The type of encryption determines the key length.128‐bit encryption key is longer than 64.Key input HEX (16 hex ‐0‐9, AF) or ASCII (American Standard Information Interchange Code ‐ alphanumeric characters) format string definition. ASCII format allows you to enter the easy‐to‐remember string. ASCII string used on the network transmitted converted into HEX. Righteousness four keys can be given, mainly You can easily change the key. What is WPA? WPA or Wi‐Fi Protected Access, is a Wi‐Fi standard, designed to improve the security features of WEP (Wired Equivalent Privacy). Compared with WEP,WPA has two major improvements: Improve data encryption through the Temporal Key Integrity Protocol (TKIP).TKIP scrambles the keys using a hashing algorithm and, by adding integrity‐checking feature, ensures that the keys have not been tampered with.WPA2 is based on 802.11i, using the Advanced Encryption Standard (AES) instead of TKIP. User authentication through the Extensible Authentication Protocol (EAP), usually missing in WEP.WEP‐based computer hardware MAC address to restrict access to the wireless network is relatively easy listening and steal. EAP is built on a more secure public key encryption system to ensure that only through authorized network users can access the network. WPA‐PSK/WPA2‐PSK uses a passphrase or key to authenticate your wireless connection. The key is an alphanumeric password, 8‐63 characters long. The password can include symbols (!?* & _) And spaces. This key must be entered on your wireless router or access point the same key. Complete the quick installation the IP CAMERA guide installation, you can use the IP address has been assigned the Camera.A local IP address for your PC and one or more shared network through a router, so assigned to the IP address of the network ...
-
Page 34: Technical Parameters
Cloud Camera user manuals Technical parameters Specification IPC2 Sensor 1/4 "color CMOS sensor Display Resolution 1280 * 720 pixels (1,000,000 pixels) Image sensor Shot f: 3.6mm, F: 2.4 Minimum illumination 0.5Lux Perspective 65 degrees Input / Output Built‐in MIC and SPEKER, two‐way voice intercom Audio Audio frequency Compression G.711/G.726/AAC/ADPCM Video compression mode MJPEG/MPEG4/H.264 Lighting frequency 50Hz, 60Hz Image frame Video rate 1‐30fps ... - Page 35 Cloud Camera user manuals Button A reset button, a function button Wireless interface 1 WIFI external antenna interface External alarm I / O External alarm I / O port PTZ rotation Other angle Horizontal: 320 ° & Vertical: 120 ° LED indication Power / network signal / function indicator Operating Temperature 0 ° ~ 55 ° C (32 ° F ~ 131 ° F) Operating Environment Humidity 10% ~ 80% RH (non‐condensing) Storage temperature ‐10 ° C ~ 60 ° (14 ° F ~ 140 ° F) Dimensions Specification (L*W*H) 112 (L) *114 (W) *157mm (H) Weight 400g (Containing rack) Central processor 2.0GHz or above (recommended 3.0GHz) Memory 256MB or more (Recommended 1.0GB) ...
