Summary of Contents for Marantz SR110

  • Page 1 Model SR110 User Guide Receiver...
  • Page 2: Note To Catv System Installer

    CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS READ BEFORE OPERATING EQUIPMENT This product was designed and manufactured to meet strict Grounding or Polarization-This video product is equipped quality and safety standards. There are, however, some installa- with a polarized alternating-current line plug (a plug having tion and operation precautions which you should be particularly one blade wider than the other).
  • Page 4 Object and Liquid Entry-Never push objects of any kind into When the video product exhibits a distinct change in this video product through openings as they may touch performance-this indicates a need for service. dangerous voltage points or short-out parts that could Replacement Parts-When replacement parts are required, result in a fire or electric shock.
  • Page 5 NEWS/TA RANDOM REPEAT STANDBY DISPLAY MUTE OPEN VOLUME VOLUME BAND TUNER MEMO MUTE TIMER PHONES DISPLAY ENTER TIMER SLEEP SYSTEM REMOTE CONTROLLER RC110SR MODEL NO. SR110 ANTENNA FM 75Ω SPEAKER REMOTE CONTROL SYSTEM LEFT SELECTOR SYSTEM INT. RIGHT RIGHT LEFT...
  • Page 6: Equipment Mains Working Setting

    Program Timer/Sleep Timer EQUIPMENT MAINS WORKING SETTING ABOUT THE WOW Your Marantz product has been prepared to comply with the WOW is a proprietary new algorithm from SRS Labs, which household power and safety requirements that exist in your p r o c e s s e s a s t e r e o s i g n a l t o p r o v i d e e x t r a o r d i n a r y area.
  • Page 7: Control Button On The Remote Control Unit

    Power switch function is selected. Press this switch to turn the power of the unit ON. If components of Marantz AV system are connected through the REMOTE !3 1 button CONTROL bus, this will turn these components ON. Press this...
  • Page 8: Operation Of Remote Control Unit

    1. REMOTE CONTROL The distance between the transmitter of the remote control unit and the IR SENSOR of the SR110 should be less than about 5 meters. If the transmitter is pointed to a direction other than the IR SENSOR or if there is an obstacle between them, remote control may not be possible.
  • Page 9: Front Panel Door

    Never remove this lens. If you remove this lens, the receiver F REMOTE CONTROL jacks cannot receive the infrared signal from remote control when Connect to a component equipped with remote control jacks. the SR110’s door is closed. (Refer to page 3.) m JOG control G System control switch The JOG control can be used in the AMP, TUNER and TIMER This switch selects the system operation mode.
  • Page 10: Band Button

    , AMP button ⁄ 5 PHONES jack The JOG control can be used in the TUNER, AMP or TIMER For connecting a pair of stereo headphones. When the modes. Press to change the mode of JOG control to AMP mode. headphones are connected to this jack, the speaker sound is 5 seconds after the previous JOG operation is finished, the mode turned off.
  • Page 11: System Operation

    Press the power switch q/z to turn the power off and into type pin lead provided. the standby mode. To operate the SR110 in the SYSTEM mode, the leads from the The SR110 receiver and all the components connected to it other components must be connected to the SR110.
  • Page 12: Am Loop Antenna

    FM FEEDER ANTENNA FM EXTERNAL ANTENNA SPEAKER SYSTEM F-type (for U version) / IEC type (for N version) converter plug (attached) When using the FM antenna attach to this apparatus MODEL NO. SR110 ANTENNA FM 75Ω SPEAKER REMOTE CONTROL SYSTEM LEFT...
  • Page 13: Basic Operations

    TO ADJUST TONE CONTROL (BASS AND TREBLE) BASIC OPERATIONS The Bass and Treble frequencies can be controlled by JOG control. NORMAL PLAY Press the AMP button , three or four times to set the mode Press the power switch q/z to turn the power ON. of JOG control m to TONE control mode.
  • Page 14: Tuner Operation

    TUNER OPERATION PRESET MEMORY OPERATION The SR110 receiver can store up to 30 stations selected in the TO LISTEN TO THE TUNER FM and AM bands. 5 2, 4 The preset memory function allows frequency, receiving mode (STEREO or MONO) and also station name to be stored in the memory.
  • Page 15: Memory Backup

    When up to 30 stations have been preset, the auto preset memory function automatically stops. To stop in mid-operation, press the MEMO button ⁄2 or the “0” button e on the remote control. Note: If you operate the auto preset memory again, new received frequency is stored into the preset memory 01 to 30.
  • Page 16 PROGRAMME TIMER SETTING PRESENT TIME SETTING You can play marantz CD player CD110, when it is connected To operate the timer program, you must set the present time. with remote control bus correctly. The clock time can be set 12-hour or 24-hour system.
  • Page 17 • SR110 can save the present time for 5 minutes if the AC plug is pulled out the AC outlet. If the AC plug is plugged into the AC outlet within this period (5 minutes), the present 1 Turn the JOG control m to adjust the volume level.
  • Page 18 CANCEL TIMER SETTING Press the power switch q/z to turn the power of the unit TIMER Press the TIMER button ⁄0 on the front panel until “Timer ON/OFF” is displayed. Turn the JOG control m to select “OFF”. Press the JOG button m. Important “TIMER”...
  • Page 19: Troubleshooting

    If the fault cannot be remedied after the following checks, please consult your dealer or nearest Marantz service agent. Sound comes from only one side. Check the connections of the loudspeaker which is not working.
  • Page 20: Technical Specifications

    TECHNICAL SPECIFICATIONS FM TUNER SECTION Frequency Range ......................... 87.5 - 108.0 MHz Usable Sensitivity ............................0 dBµ Signal to Noise Ratio ......................Mono/Stereo 70/65 dB Distortion ..........................Mono/Stereo 0.2/0.3 % Stereo Separation ..........................1 kHz 40 dB Image Rejection ..........................98 MHz 80 dB Tuner Output Level ....................
