Summary of Contents for Octet Matrix Audio DE7
- Page 1 Octet Matrix Audio DE7 High Definition Bookshelf Speaker User’s Guide...
-
Page 2: Table Of Contents
Table of Contents Introduction ......................3 Features ......................3 Specifications ...................... 4 DE7 Speaker Placement/Mounting ..............6 Final Verification & Optimization ................ 7 Channel & Phase Verification ..................... 7 Warranty ......................8 Resources ......................9 Page 2 Copyright© 2011 Octet Matrix Audio... -
Page 3: Introduction
Introduction Thank you for purchasing the Octet Matrix Audio DE7 high definition speaker system. The information in this User’s Guide, along with the audio tracks on the CD, will help you optimize your new speaker set up so that your will obtain the highest level of performance from them. -
Page 4: Specifications
15" wide x 15-1/2" tall x 22" deep Shipping dimensions (pair) (381mm x 394mm x 559mm) Cabinet Material 3/4" MDF Baffle Material 1" MDF Available in Piano Black Laquer, Cherry Veneer, Cabinet Finish and Maple Veneer finishes Page 4 Copyright© 2011 Octet Matrix Audio... - Page 5 Page 5 Copyright© 2011 Octet Matrix Audio...
-
Page 6: De7 Speaker Placement/Mounting
Do not place the rear of the speaker closer than 4” to the wall, or the air load will detune the port and adversely affect the DE7’s low frequency performance. When mounting to a wall, make sure that the mounting brackets and the wall structure (preferably a wooden stud) can support a 15 lb. -
Page 7: Final Verification & Optimization
2) Insert the Octet Matrix Audio set up CD into a CD player, DVD player, or Blu-ray player. If the CD doesn’t start playing automatically, point the player to track 1 and then hit play. -
Page 8: Warranty
Octet Matrix Audio products are guaranteed to be free from defects in materials and workmanship for a period of 2 years from the original date of purchase. Octet Matrix Audio will repair or replace defective products during this period at no cost to the original end user. -
Page 9: Resources
Darkwood Designs – Audio Level Meters by Paul Mitchell – various audio level meters & tools http://www.darkwood.demon.co.uk/PC/meter.html ARTA - Audio Measurement and Analysis Software – free to use without saving results. Low cost, high feature acoustic analysis software. http://www.fesb.hr/~mateljan/arta/index.htm Page 9 Copyright© 2011 Octet Matrix Audio...
