- Page 1 HD Component Video/PC VGA 4-Way Scaler / Converter Operation Manual...
- Page 2 6. Specifications 1. Introduction Ambery’s new 4-Way HD Component Video/PC VGA Scaler (model: AV-7) is a high- performance universal video scaler to set the new benchmark for all HD video applications Input Format RGBHV, YPbPr, YCbCr and computer image to HD conversion.
- Page 3 9. Supports last memory function., thus can memorized all customers' setting before Color 0-255 power off and recall those setting on next power on. 0-255 4-way video processing: VGA to VGA scaling, VGA to HDTV component Video, HD Green 0-255 Component Video to VGA/RGBHV, HD to HD scaling.
- Page 4 4. Operation 5. Operation Controls and Functions Front Panel Rear Panel Input connection: This AV-7 universal video scaler model supports both PC VGA type and HD Component video type inputs. For PC VGA input, please use the 15-pin D-sub cable to connect the output of a PC device to the input connector on the back of AV-7.
