- Page 1 2500-PWR24 VDC Power Supply Installation & Operations Manual RP8500225 N56 W24720 N. Corporate Circle Sussex, WI 53089 Ver. 2 Made in the USA 800-451-1460 262-246-4828 (fax) www.area-of-refuge.com 3 Year Warranty 03/13...
- Page 2 We take great pride in our products, service and support. Our #1 mission is customer satisfaction. When evaluating emergency communication systems, you can rely on Rath to continually provide Innovative Thinking, Design and Value. If you have any questions or comments, just give us a call.
- Page 3 24 Volt Power Supply Installation: • Locate a suitable mounting location for the supply • Mount the Power Supply using 6 mounting screws (not provided) and punch out conduit knockouts for wire runs • For each Call Box you must run an 18 gauge, 2 wire set down to the Power Supply •...
- Page 4 Power Supply to Call Box Wiring Diagram Note: A three prong plug is included 120 vac with the Power Supply 24 Volt 0 vac Power Supply 2100-_____ Conduit with electrical can also be Call Box attached to the Power Supply Ground Wiring requirements for Power Supply to Call Box 1) Minimum requirement is: 18 awg, 1 pair wire...
- Page 5 Mounting Dimensions 8.30 in Back 0.60 in 1.50 in 1.50 in 8.30 in Side Side Bottom www.area-of-refuge.com pg. 4...
-
Page 6: Technical Support
Troubleshooting Problem Possible Cause & Fixes • Make sure the power switch is set to the On position on the power supply Green Power LED • Make sure the power supply is connected to a good 120vac power source are not illuminated: •...
