- Page 1 INSTALLATION, OPERATION & MAINTENANCE MANUAL ® InverterFlex Series Indoor Ductless Mini-Split Heat Pumps B-VFH09MA-1 B-VFH12MA-1 B-VFH18MA-1 AITONS EQUIPMENT • Guelph, ON N1H 6H9 • 1-888-744-2911 • www.aitons.com...
-
Page 2: Table Of Contents
AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® TABLE OF CONTENTS Warnings and Cautions ....................... 3 ....................... 4 Operation of Wireless Remote Control ................5-9 Special Features of Wireless Remote Control ..............10 Battery Installation and Replacement ................10 Manual Operation ......................11 Operation Tips ........................ -
Page 3: Warnings And Cautions
AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® • Read the follow SAFETY PRECAUTIONS carefully before installation. • Electrical work must be performed by a licensed electrician. • Incorrect installation due to ignoring the instruction will cause harm or damage. ... -
Page 4: Indoor Unit
AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Indoor Unit Air Inlet Air Outlet The icons displayed: Cool Heat Power Set temp. (1) Remote controller (2) Front panel (3) Filter (4) Horizontal louver (5) Wall pipe bushing (6) Binding tape (7) Connection pipes (8) Condensate drain hose... -
Page 5: Operation Of Wireless Remote Control
AITONS EQUIPMENT VFH InverterFlex VFH InverterFlex - Ductless Mini-Split - Ductless Mini-Split ® ® Operation of wireless remote control Features and functions of wireless remote control No Te: Be sure that there are no obstructions between the unit’s receiver and remote control. Be careful not to drop the remote control;... - Page 6 AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Operation of wireless remote control Features and functions of wireless remote control X-FAN X-FAN button • By pressing X-FAN button in COOL or DRY mode, the icon is displayed and the indoor fan will operate for 2 minutes in order to dry the indoor unit after powering off the unit.
- Page 7 AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Operation of wireless remote control Features and functions of wireless remote control TIMER OFF TIMER OFF button • Press the Timer off button to create the timer off program. The Timer off icon will blink, indicating it is in programming mode. The set up process is the same as the timer on process - see Timer On for instructions.
- Page 8 AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Operation of wireless remote control Features and functions of wireless remote control Sleep Button: The sleep program allows for the most comfortable conditions while you sleep, as body temperatures change. To activate the sleep mode, press the sleep mode button. There are (3) different programmed settings to choose from Sleep 1 ( 1), Sleep 2 (...
-
Page 9: Operation Of Wireless Remote Control
AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Operation of wireless remote control Features and functions of wireless remote control • When the initial set temperature is between 82°F-85°F (28°C-29°C), the temperature will increase 1-2 degrees every hour until a 1-2 degree increase is achieved and that will be maintained for (7) hours. -
Page 10: Special Features Of Wireless Remote Control
AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Special features of the wireless remote Keypad Lock: Press + and - buttons simultaneously to lock or unlock the keypad. If the remote controller is locked, the icon will be displayed. If the keyboard is unlocked, the mark will disappear. Fahrenheit and Centigrade: While the unit is off, press the MODE and - buttons simultaneously to switch between °C and °F. -
Page 11: Manual Operation
AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Manual Operation Manual Operation When the remote controller is lost or damaged, please use the manual switch on the main unit. The unit will operate in AUTO mode based on the room temperature. -
Page 12: Operation Tips
AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Operation Tips Cooling o peration Principle: • Air conditioners absorb heat in the room and transmit it to the outdoor unit, so that the room temperature decreases. The cooling capacity will increase or decrease according to outdoor ambient temperature. -
Page 13: Care And Cleaning
AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Care and Cleaning CAUTION! Caution • Disconnect the power supply before performing any cleaning or maintenance. • Be sure water does not get inside the unit when cleaning. To avoid electrical shock and damage to the unit. -
Page 14: Troubleshooting
VFH InverterFlex - Ductless Mini-Split AITONS EQUIPMENT ® Troubleshooting Caution • The air conditioner is not user serviceable. Incorrect repair may cause electric shock or . Performing the following checks prior to contacting may save you time and money. Problem Troubleshooting •... - Page 15 AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Troubleshooting Phenomenon Troubleshooting Check these things before calling for service: The unit will not start up: • Is the power on? • Has the circuit breaker tripped? • Is the TIMER correctly used? Breaking off •...
- Page 16 AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Troubleshooting Problem Troubleshooting • In HEAT mode, when the temperature Indoor unit can not blow air: of indoor heat exchanger is very low, air blowing for 2 minutes. • In HEAT mode, when the outdoor temperature is low or humidity is high, frost will form on the outdoor heat exchanger.
-
Page 17: Installation Notices
AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Installation Notices: CAUTION! Caution 1. The unit must only be installed by authorized servicer and in compliance with this installation instruction. 2. Installation must be performed in accordance with the requirements of NEC or CEC and all local codes by authorized personal only. -
Page 18: Installation Of Location And Clearances
VFH InverterFlex - Ductless Mini-Split AITONS EQUIPMENT ® Installation Location and Clearances Selecting installation place • The indoor unit should be mounted as high up on the wall toward the ceiling, leaving a minimum of 6” Choose a location that places the outdoor unit as (150mm) of space between the ceiling and the top of the close to the indoor unit as possible. -
Page 19: Indoor Unit Installation
AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Wall Bracket should be Indoor unit installation 1. Wall Bracket Mounting A. There are two tabs on the back of the Fig. 5 indoor unit that hold the wall bracket onto screwdriver to release the wall bracket 9k, 12k Unit from the back of the unit. - Page 20 AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Installation of Indoor Unit 4. Refrigerant Line Installation A. Remove the knockout from the desired side of the unit that the line set will be routed from. The lines from the unit can be routed either left or right, left Knockout back or right back (Fig.
-
Page 21: Indoor Wiring
AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Installation of Indoor Unit INDOOR/OUTDOOR COMMUNICATING CABLE Indoor Wiring 1. Wiring must conform to all local and national electric codes 2. Lift the indoor unit’s panel up, remove the wiring cover and clamp as shown in (Fig.15). 3. -
Page 22: Initial Start-Up Checks
AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ® Initial Start-up Checks Operation of the unit will depend on the setting of the thermostat on the unit or the remote control. IMPORTANT! Both indoor and outdoor units must be completely installed. See outdoor installation instructions for the outdoor unit’s installation. - Page 23 AITONS EQUIPMENT VFH InverterFlex - Ductless Mini-Split ®...
- Page 24 VFH InverterFlex - Ductless Mini-Split Heat Controller ® AITONS EQUIPMENT • Guelph, ON N1H 6H9 • 1-888-744-2911 • www.aitons.com 12/2013...
