Summary of Contents for Roadmate AN505
-
Page 1: User Manual
AN505 User’s Manual AN505 User Manual Android PND... -
Page 2: Table Of Contents
AN505 User’s Manual Content Precaution and Notice....................1 In the Box........................1 . Basic Introduction ....................... 1 1. Overview ..........................1 2. Accessory Operations......................1 2.1 Charging by AC adapter ....................1 2.2 Charging by car charger ....................2 2.3 Power supplied by built-in battery ..................2 2.4 Install the car mount system ....................2... - Page 3 AN505 User’s Manual 3.3 Sound ……………………………………………………………………………………24 3.4Display……………………………………………………………………………………25 3.5 Location and security…………………………………………………………………...26 3.6 Applications……………………………………………………………………………..27 3.7Accounts&sync…………………………………………………………………………..28 3.8 Privacy…………………………………………………………………………………...29 3.9Storage……………………………………………………………………………………29 3.10 Language & keyboard…………………………………………………………………29 3.11 Voice input & output…………………………………………………………………..30 3.12 Date & Time……………………………………………………………………………31 3.13 About device …………………………………………………………………………...31 3.14 Desktop function icon setting…………………………………………………………32 Specification........................35...
-
Page 4: Precaution And Notice
For your own safety, do not operate the controls of the PND while driving. Do not mount where the driver’s field of vision is blocked In the Box In the box you will find: AN505 GPS Car charger AC adapter(Optional) Bracket... -
Page 5: Basic Introduction
AN505 User’s Manual . Basic Introduction 1. Overview Indicator in red means the device is in charging, when LCD indicator the device is fully charged, it will turn green. Speaker Voice comes out from here. Reset button Reboot the device. -
Page 6: Charging By Car Charger
AN505 User’s Manual 2.2 Charging by car charger 1. Plug the car charger into the device’s USB port on its side panel. 2. Plug car charger’s the other end into the car igniter. 3. To avoid damage caused by instant current when igniting the car, please plug in the car charger after ignition. -
Page 7: Usb Cable Usage
AN505 User’s Manual clear plastic tab at the edge of the suction mount, to break the vacuum seal. Rotate screw to lock it onto car glass Use the two screws to adjust the Install the holder into angle and direction of the PND the Car cradle 2.5 USB Cable usage... -
Page 8: Functions Operation
AN505 User’s Manual . Functions Operation 1. Power On & Off 1.1. Power on Longtime press the power switch on the top panel to power on the device. Remarks: When the device is transported from one place to another, it could be powered on only after it adapts to the outside environment, because the great fluctuations in humidity and moisture may lead internal short circuit. -
Page 9: Navigation
AN505 User’s Manual 2.1 Navigation Double tap the icon “Navigation” to start the navigation program. Note: During navigation or other operations, quickly press the MENU button, “Main Menu” screen will be displayed. 2.2 Music Tap the icon “ ” on the Desktop, enter into the following interface:... -
Page 10: Gallery
AN505 User’s Manual Backward playing Stop Forward playing Playing list Random playing Repeat playing 2.3 Gallery Tap the icon “ ” on the Desktop, and enter into the following interface: Tap the” flash (9)”, enter into the following interface:... - Page 11 AN505 User’s Manual Tap the photo, enter into the following photo interface: Zoom in Zoom out Slideshow Menu Delete Rotate right...
-
Page 12: Video
AN505 User’s Manual Rotate left Crop Set as Details Return to the previous menu 2.4 Video This Video support following format: MKV AVI RM RMVB MP4 MOV VOB DAT FLV 3GP,etc. Tap the icon “Video” on the Desktop, and enter into the following interface:... -
Page 13: E-Book
AN505 User’s Manual Backward playing Forward playing Stop Video format:16 9 /4 3/ recovery Exit Media volume - Media volume + Menu Tap the icon “ ”, set play mode, and enter into the following interface: Tap “Play mode”, select single, repeat or return. As below interface: 2.5 E-book... - Page 14 AN505 User’s Manual Click “ ”, and enter into the following interface: Click the upper right corner, turn to next page, as blow interface: 2.6 FM Transmitter Click the “ ” button, and enter into the following interface:...
-
Page 15: Sound Recorder
AN505 User’s Manual click “-”, frequency will decrease 0.1MHZ click “+”, frequency will add 0.1MHZ FM frequency FM is on, the speaker is muted. 2.7 Sound Recorder Tap the icon “ ” on the desktop, and enter into the following interface:... -
Page 16: Clock
AN505 User’s Manual Tap the icon “ ” on upper right corner and enter into “Advanced panel” interface: 2.9 Clock Tap the icon “ ” on the desktop, and enter into the following interface:... -
Page 17: Calendar
AN505 User’s Manual Enter into Alarms interface Enter into Gallery interface Enter into Music interface Return to the main menu Tap the icon “ ”, enter into the “Alarm” interface: 2.10 Calendar Tap the icon “ ” on the desktop, enter into the calendar interface:... -
Page 18: Email
AN505 User’s Manual 2.11 Email 1. Tap the icon “ ” on the desktop, enter into following email interface: 2. Fill up email address and password, enter into following Inbox interface. 3. Click an email, check the email content. 4. If need reply email, enter into following interface. -
Page 19: Browser
AN505 User’s Manual 2.12 Browser 1. Tap the icon “ ” on the main menu, enter into following interface: 2. Fill up website, enter into following Inbox interface. 3. Surfing web page, click zoom out or zoom in buttons to decrease or increase the... -
Page 20: Market
AN505 User’s Manual 2.13 Market 1. Tap the icon “ ” on the main menu, enter into following interface: “ 2. The first time to enter into Market”, please create an account or sign in a Google account. 3. Enter into “Market”:... - Page 21 AN505 User’s Manual 4. Enter into “APP”, select your desired application files and download them. 5. Enter into “Games”, select your desired games and download them. 6. Enter into “search”, select your desired files and download them.
-
Page 22: Explorer
AN505 User’s Manual 7. Check the download states, finished application will be showed on desktop. 2.14 Explorer 1. Tap the icon “ ” on the desktop, select SD Card , Internal Memory or USB , operate files. following interface: 2: Select a file , you can edit it as... -
Page 23: Apk Installer
AN505 User’s Manual 2.15 APK Installer 1. Tap the icon “ ” on the desktop, and enter into the following interface: 2. Install: install APK files from Internal Memory or SD card 3. Manage: manage all application on desktop. -
Page 24: Gps Info
AN505 User’s Manual 3.1 You can select one application, operate as following interface: - Launch run the application - Export export the application to TF card - Uninstall uninstall the application - Cancel cancel the operation 2.16 GPS info 1. Tap the icon “... -
Page 25: Wireless & Networks
AN505 User’s Manual 3.1 Wireless & networks Tap the icon “ ” on the settings, and enter into the following interface: a. Tap “Wi-Fi settings , enter into following interface, system will automatically find WIFI networks. b. Setting IP address and connect: Automatic &... - Page 26 AN505 User’s Manual Don’t tick off “ Use static IP”, enter into following “automatic distribution IP address” interface Tick off “ Use static IP”, enter into following “manual distribution IP address” interface to save. After setting, Tap the icon “...
-
Page 27: Usb
AN505 User’s Manual Tap the WIFI network name, e.g. “PVE5”. Fill in password, then connect. After connected, it will shows“ ”on desktop. 3.2 USB Tap the icon " " and enter into the following “USB mode” interface:... -
Page 28: Sound
AN505 User’s Manual Select “OTG” or “Device only”, then pull down the status bar, enter into following interface: USB storage : tap “USB connected”, turn on USB storage, enter into following interface: Synchronous : click “USB debugging connected”, tick off “stay awake” and “Allow mock locations”, device will synchronous with PC. - Page 29 AN505 User’s Manual a. [Silent mode]: tick off the silent mode, device will be in silent state. b. [Volume]: set the Ringtone, Media, Alarm volume as following interface: C. [Notification ringtone]: set ringtone as following interface: d. [Audible touch tones]: play tones when using dial pad e.
-
Page 30: Display
AN505 User’s Manual 3.4 Display Tap the icon “ ” on the settings, and enter into the following interface: Brightness a. [ ]: adjust the screen brightness as following interface: Auto-rotate screen ]: tick off auto-rotate screen, when rotate device, the screen will change direction. -
Page 31: Location And Security
AN505 User’s Manual 3.5 Location and security Tap the icon “ ” on the settings, and enter into the following interface: [Use wireless networks] see location in applications using wireless networks. [Use GPS satellites] when locating, accurate to street level. -
Page 32: Accounts&Sync
AN505 User’s Manual Manage applications, Running services, and storage use: Battery use: Development: 3.7Accounts&sync Tap the icon “ ” on the settings, and enter into the following interface:... -
Page 33: Privacy
AN505 User’s Manual Add account: Remove account: 3.8 Privacy Tap the icon “ ” on the settings, and enter into the following interface: Factory data reset:... -
Page 34: Storage
AN505 User’s Manual 3.9 Storage Tap the icon “ ” on the settings, and enter into the following interface: 3.10 Language & keyboard Tap the icon “ ” on the settings, and enter into the following interface Select language:... -
Page 35: Voice Input & Output
AN505 User’s Manual Keyboard settings: 3.11 Voice input & output Tap the icon “ ” on the settings, and enter into the following interface Text-to-speech settings:... -
Page 36: Date & Time
AN505 User’s Manual 3.12 Date & Time Tap the icon “ ” on the settings, and enter into the following interface 3.13 About device Tap the icon “ ” on the settings, and enter into the following interface... -
Page 37: Desktop Function Icon Setting
AN505 User’s Manual 3.14 Desktop function icon setting Tap the icon “ ” on the upper right corner, and enter into the following interface Add and Delete desktop function Icon Tap the icon “ ”, add to home screen. Select Shortcuts... - Page 38 AN505 User’s Manual Choose Widget: Select Folder: Delete or Remove: Long press icon, then draw it to other place or recycle bin. Tap the icon “ ”, select wallpaper from gallery, live Wallpaper setting: wallpaper or wallpaper.
- Page 39 AN505 User’s Manual Saves as wallpaper: C) Edit: Tap the icon “ ”, and enter into below interface: Edit or remove the screen and all the content:...
-
Page 40: Specification
AN505 User’s Manual Specification Cortex-A8 1.2GHz Memory Flash 4G/8G/16 MLC Flash Memory RAM DDR3 512M Up to 1G Screen 5” TFT LCD screen, 800*480 pixel, with five points capacitive touch screen Navigation Dual navigation system (GPS +GLONASS) ,cold start only takes 40s... - Page 41 AN505 User’s Manual www.roadmategps.co.za...
