MCB1750 Evaluation Board
MCB1750 Features
100MHz LPC1758 ARM Cortex™-M3
processor-based MCU in 80-pin LQFP
On-Chip Memory: 512KB Flash & 64KB RAM
Color QVGA TFT LCD
10/100 Ethernet Port
USB 2.0 Full Speed - USB, USB-OTG, & USB Host
2 CAN Interfaces
2 Serial Ports
SD/MMC Card Interface
5-position Joystick and push-button
Analog Voltage Control for ADC Input
Amplifier and Speaker
52 GPIO pins
Debug Interface Connectors
20 pin JTAG
10 pin Cortex debug
20 pin Cortex debug + ETM Trace

System Requirements

PC with one available USB port
Windows 2000, XP and Vista
One CD-ROM drive
ULINK family USB-JTAG Adapter
(optional)
The Keil MCB1750 Evaluation Board introduces
the new NXP LPC1750 family of ARM Cortex-M3
processor-based devices, allowing you to create
and test working programs for this advanced
architecture. The MCB1750 has a wide range of
interfaces making it a great starting point for
your next Cortex-M3 project.
(0.1 inch connector)
(0.05 inch connector)
(0.05 inch connector)
for high-performance Debug/Download
MCB1758
