BT-1 User's Guide
Getting Connected (For BT-1L only)
1
1. Connect the power supply to the BT-1L and a power outlet.
2. Using the supplied 1/8" to 1/8" audio cable, connect one end to the audio output on the
BT-1, connect the other end to your powered speaker or audio system.
3. Install the antenna by aligning it to the center of the antenna input and turn clockwise.
NOTE: Do not connect 6-pin
connector and 5V power
adapter simultaneously.
1
4
Connector
Antenna
1. Remove the expansion port cover plate from your compatible host unit.
2. Find the 6-pin cable and connect its connector to the 6-pin connector on the back of the BT-1.
3. Slide the BT-1 into the port and secure with the screws.
4. Install the antenna by aligning it to the center of the antenna input and turn clockwise.
2
1. When powered, the BT-1/L will automatically be discoverable in
2. Go to the Bluetooth settings on your Bluetooth device and pair
3. Use the volume knob to adjust volume of bluetooth audio output.
4. Enjoy your music!
2
Installation (For BT-1 only)
Pairing
BT-1
pairing mode (indicated by the blinking LED).
the device labeled VOCOPRO. This will cause the LED to remain lit
signaling a successful pairing.
NOTE: If you are prompted for a password, use: 0000.
3
Connector
3
VOL
LINE
BLUETOOTH
OUT
MUSIC RECEIVER
Antenna
