Husky 1/2” Operating Instructions Manual

Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Description
This is a rocking dog type impact
wrench designed for DIY projects and
general purpose applications such as
maintenance, car repair, and lawn and
garden equipment. Not intended for
assembly line applications or heavy
duty usage. Do not operate tool with
air pressure above 95 PSI.
Unpacking
When unpacking this product, carefully
inspect for any damage that may have
occurred during transit. Make sure any
loose fittings, bolts, etc., are tightened
before putting this product into service.

Specifications

Avg SCFM & PSI . . . .5.1 @ 90 PSIG
(20% usage)
Continuous SCFM . .25.4 @ 90 PSIG
(100% usage)
Max. RPM . . . . . . . . .7000
Max Torque . . . . . . .250 ft.lb
Working Torque . . .60-200 ft.lb
Impact Mechanism
Type . . . . . . . . . . . . .Rocking Dog
Bolt Capacity . . . . . .1/2"
Air Inlet . . . . . . . . . .1/4" NPT (Female)
Drive . . . . . . . . . . . . .1/2" Sq
Weight . . . . . . . . . . .5 lbs.
General Safety
This product is a part of a high pressure
system and the following safety pre-
cautions must be followed at all times
along with any other existing safety rules.
1. Read all manuals
included with this
product carefully. Be
thoroughly familiar
with the controls and the proper
use of the equipment.
2. Only persons well acquainted with
these rules of safe operation should
be allowed to use the air tool.
DANGER
!
Do not exceed maximum
operating pressure of the air
tool (90 PSI). The air tool
could explode and result in death or
serious personal injury.
3. Do not exceed any pressure rating
of any component in the system.
4. Disconnect the air tool from air
supply before changing tools or
attachments, servicing and during
non-operation.
5. Always wear safety
glasses during
operation.
6. Do not wear loose
fitting clothing, scarves, or neck ties.
Loose clothing may become caught
in moving parts and result in serious
personal injury.
7. Do not wear jewelry when
operating any tool. Jewelry may
become caught in moving parts and
result in serious personal injury.
8. Do not depress trigger when
connecting the air supply hose.
9. Always use attachments designed
for use with air powered tools. Do
not use damaged or worn
attachments.
1/2" Impact
Wrench
WARNING
!
impact quality sockets only. Hand tool
MANUAL
sockets are "glass-hard" and will
shatter and can cause serious personal
injury if used with air tools.
10. Never trigger the tool when not
applied to a work object.
Attachments must be securely
attached. Loose attachments can
cause serious injury.
11. Protect air lines from damage or
puncture.
12. Never point an air tool at oneself or
any other person. Serious injury
could occur.
13. Check air hoses for
weak or worn condition
before each use. Make
sure all connections are
secure.
WARNING
!
Release all pressure from the system
before attempting to install, service,
relocate or perform any maintenance.
14. Keep all nuts, bolts and screws tight
and ensure equipment is in safe
working condition.
15. Do not put hands near or under
moving parts.
WARNING
!
exposure to vibration, work in
awkward positions, and repetitive
work motions can cause injury to hands
and arms. Stop using any tool if
discomfort, numbness, tingling, or pain
occur, and consult a physician.
Do not use hand-
tool sockets. Use
Do not misuse this
product. Excessive
IN271200AV 3/02
