Instruction Manual
Chordette
Thank you for purchasing the Chordette Toucan headphone amplifier. In order to get
the most from your product please take a few moments to read these instructions.

Connections

Analogue source components can be connected via the unbalanced RCA phono input
or by the true balanced XLR input. Only one type of analogue connection can be
used. Most source components can be connected in this way. For convenience you
can also connect and stream music from a personal computer using the USB input.
Crossfeed Filter Switch
TOUCAN
High Definition Headphone Amplifier
Headphone Output
Left unbalanced input
Left balanced input
Right balanced input
Right unbalanced input
USB input
12V DC power input.
Connect to the wall
adapter provided.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOUCAN and is the answer not in the manual?

Questions and answers

Summary of Contents for Chordette TOUCAN

  • Page 1 TOUCAN Chordette High Definition Headphone Amplifier Thank you for purchasing the Chordette Toucan headphone amplifier. In order to get the most from your product please take a few moments to read these instructions. Connections Analogue source components can be connected via the unbalanced RCA phono input or by the true balanced XLR input.
  • Page 2 USB input Using USB digital audio Connect your personal computer via an A to B type USB cable. The Toucan will automatically be recognised by the computer as a USB DAC. All audio from the computer will be streamed to the Toucan so you can listen via the headphones. (In some cases you may need to change the computer audio settings to set the playback device as USB Audio).
