- Page 1 M404 ADSL/2/2+ Single Port Ethernet Modem M405 ADSL/2/2+ Single Port Ethernet/USB Modem User’s Manual...
-
Page 2: Table Of Contents
Step 2. Connect the Ethernet cable ..........................6 Step 3. Attach the power connector ...........................7 Step 4. Turn on the M404/M405 and power up your systems ..................7 Step 5. Configure the M404/M405 through the WEB interface .................7 Step 6. Save the configurations and Reboot.......................7 CONFIGURATION..............................8... - Page 3 Manual Ver1.0 ..........................45 ANAGEMENT TILITIES ............................45 ACKUP ETTINGS ............................46 PDATE ETTINGS ............................47 ESTORE ETTINGS ............................47 PDATE IRMWARE TR-069 C ..............................48 LIENT ..............................49 EBOOT ..............................49 YSTEM CONNECTION STATUS............................52 LAN ................................52 WAN ................................52 ATM ................................54 ADSL ................................54 ................................55 OUTE ARP................................56 DHCP................................56 ...............................57 UMMARY DIAGNOSTICS AND HELP ..........................58 APPENDIX A –...
-
Page 4: Introduction
This User’s Manual will guide you through the installation and configuration of your M404/M405 modem. System Requirements Before installing your M404/M405 modem, make sure that you have the following: ADSL service up and running on your telephone line, with at least one public Internet •... -
Page 5: Installation
Manual Ver1.0 2. Installation In addition to this document, your M404/M405 should arrive with the following: • One power adapter and power cord One Ethernet cable with RJ-45 connector • One USB A-B cable (M405 Only) • • One Telephone cable with RJ-11 connector •... -
Page 6: Rear Panel
Step 1. Connect the ADSL cable and optional telephone Connect one end of the phone cable to the RJ-11 connector on the rear panel of the M404/M405. Connect the other end to the ADSL outlet provided by your service provider (normally MODEM port of the included splitter). -
Page 7: Step 3. Attach The Power Connector
Manual Ver1.0 Step 3. Attach the power connector Connect the AC power adapter to the power connector on the M404/M405 and plug in the adapter to a wall outlet or power extension. Step 4. Turn on the M404/M405 and power up your systems Press the Power switch on the back panel of the M404/M405 to the ON position. -
Page 8: Configuration
The default IP address of M404/M405 is 192.168.1.254. 3.2 - Establish the Connection Enter the IP address (default: 192.168.1.254) of M404/M405 in the address line of your web browser. A Dialogue Box will pop up to request the user to login. (Figure 1) Figure 1. - Page 9 Manual Ver1.0 Figure 2. M404/M405 Home Page - 9 -...
-
Page 10: Quick Setup
Manual Ver1.0 4. Quick Setup The system administrator can configure the M404/M405 remotely or locally via a Web Browser. Network configuration needs to be planned and decided before starting the configuration procedure. Quick Setup allows system administrator to select the appropriate operation mode and configure the corresponding settings step by step to create a connection. - Page 11 Manual Ver1.0 PPP Username and Password This page is where you will enter the “PPP Username”, and “PPP Password”. Please contact you ISP for this information. Figure 4. Quick Setup – Username, Password and option forIP extension and Static IP WAN Setup –...
- Page 12 Manual Ver1.0 Device Setup This page is where you can configure the modem’s IP address and Default DHCP server range. Default is 192.168.1.254 Figure 6. Quick Setup – Device Setup – LAN and DHCP Server Summary Figure 7. Quick Setup – WAN Setup – Summary - 12 -...
-
Page 13: Ppp Over Atm (Pppoa) Configuration
Manual Ver1.0 The last page displays a summary of your settings. Click on the “Save/Reboot” button to complete the configuration. 4.2 - PPP over ATM (PPPoA) Configuration Configuration of PPPoA is similar to PPPoE. Select “PPP over ATM (PPPoA)” in “Connection Type”. - Page 14 Figure 10. Quick Setup – Connection Type Quick Setup – WAN IP Settings This page is where you either select for the M404/M405 to obtain the IP information automatically (sometime referred to as DHCP connection) or you can input the IP...
- Page 15 Manual Ver1.0 address if Static IP’s were assigned by your Internet Service Provider. Figure 11. Quick Setup – WAN IP Settings Quick Setup – Network Address Translation and IGMP This page is where you either select to enable NAT (Please enable this option for the M404/405 to route private (Local) IP address to your LAN clients).
- Page 16 Manual Ver1.0 Quick Setup - Device Setup This page is where you can configure the modem’s IP address and Default DHCP server range. Default is 192.168.1.254 Figure 13. Quick Setup – Device Setup – LAN and DHCP Server Quick Setup - Summary Figure 14.
-
Page 17: Ipoa (Ip Over Atm) Configuration
Manual Ver1.0 4.4 - IP over ATM (IPoA) Configuration Click on “Quick Setup” in the left frame and follow the steps below to create an IPoA connection. Here you can either select DSL Autoconnect (Modem will attempt to find the correct VPI/VCI settings) or Uncheck the box to manually input the VPI/VCI settings. - Page 18 Figure 17. Quick Setup – WAN IP Settings Quick Setup – Network Address Translation and IGMP This page is where you either select to enable NAT (Please enable this option for the M404/M405 to route private (Local) IP address to your LAN clients). - 18 -...
- Page 19 Manual Ver1.0 Figure 18. Quick Setup – Network Address Translation and IGMP Quick Setup - Device Setup This page is where you can configure the modem’s IP address and Default DHCP server range. Default is 192.168.1.254 Figure 19. Quick Setup – Device Setup – LAN and DHCP Server Quick Setup –...
-
Page 20: Bridging
Manual Ver1.0 The last page displays a summary of your settings. Click on the “Save” button to complete the configuration. 4.5 - Bridging (Transparent/Pass-through) Configuration Click on “Quick Setup” in the left frame and follow the steps below to create a Bridge connection. - Page 21 Manual Ver1.0 Figure 22. Quick Setup – Connection Type Quick Setup – Enabling Bridge Mode For this page, please check the box “Enabled Bridge Service” and click “Next” Figure 23. Quick Setup – Enabling Bridge Mode - 21 -...
- Page 22 Manual Ver1.0 Quick Setup – Summary Figure 24. Quick Setup – WAN Setup – Summary The last page displays a summary of your settings. Please click the “Save” button to complete the configuration process. - 22 -...
-
Page 23: Advanced Setup
Manual Ver1.0 5. Advanced Setup Advanced Setup allows system administrator to configure the following topics: Routing Security Internet Time Access Control Services IPSec Certificates 5.1 - WAN Figure 25. Advanced Setup – WAN - 23 -... -
Page 24: Lan
Connections. 5.2 - LAN Figure 26. LAN Setup page Input the IP Address and Subnet Mask of your M404/M405. (Default: 192.168.1.254) Check the box if you want to enable UPnP and/or IGMP Snooping. Disable/Enable DHCP Server, and change the starting and ending IP address of your server pool if needed. -
Page 25: Nat
Click on “Add” to enter configuration page to add your own rule(s). Some common used servers (Web, FTP, Mail, …etc.) are already pre-defined for the M404/M405. User can simply select the desired server from the pull-down menu and assign the IP address of the local PC. - Page 26 Manual Ver1.0 Figure 28. Advanced Setup – NAT – Virtual Servers Port Triggering Some applications require that specific ports in the Router's firewall be opened for access by the remote parties. Port Trigger dynamically opens up the “Open Ports” in the firewall when an application on the LAN initiates a TCP/UDP connection to a remote party using the “Triggering Ports”.
- Page 27 Manual Ver1.0 Figure 29. Advanced Setup – NAT – Port Triggering Click on “Add” to enter the configuration page to add your own rule(s). Some games, video conferencing, remote access applications and other software might require that specific ports in the Router's firewall be opened for access. You can configure the port settings from this screen by selecting an existing application or creating your own (Custom application) and click “Save/Apply”...
-
Page 28: Routing
Routing – Default Gateway If the “Enable Automatic Assigned Default Gateway” checkbox is selected, the M404/M405 will accept the first received default gateway assignment from one of the PPPoA, PPPoE or MER/DHCP enabled PVC(s). If the checkbox is not selected, enter the static default gateway AND/OR a WAN interface. - Page 29 Manual Ver1.0 Figure 32. Advanced Setup – Routing – Default Gateway Routing – Static Route Click on “Add” to create a new Static Route. Up to 32 entries can be configured. - 29 -...
- Page 30 Place a check in the “Enabled” checkbox next to the interface to complete the configuration. Click the “Save/Apply” button to save the configuration. To start/stop RIP for the M404/M405, select the “Enabled/Disabled” radio button for “Global RIP Mode”. - 30 -...
-
Page 31: Security
Manual Ver1.0 5.5 - Security Two functions are supported in Firewall: Outgoing IP Filtering and MAC Filtering. Firewall – Outgoing IP Filtering By default, all outgoing IP traffic from LAN is allowed, but some IP traffic can be BLOCKED by setting up filters. Choose “Add” to configure outgoing IP filters. To remove, check the item and click “Remove”. - Page 32 Manual Ver1.0 Figure 36. Advanced Setup – Security – Add new Outgoing IP Filter Security – WAN Access Control WAN Access Control allows users to create time of day restrictions to a specific LAN device connected to the Router. Click “Add” to configure restriction rules. To remove, check the item and click “Remove”.
- Page 33 Manual Ver1.0 Figure 37. Advanced Setup – Security – WAN Access Control The MAC Address of the current “browser” will automatically display on the “Browser’s MAC Address” box. To restrict another LAN device, click the “Other MAC Address” button and enter the MAC address of that LAN device. To find out the MAC address of a Windows-based PC, go to the command prompt window and type “ipconfig /all”.
-
Page 34: Dns
Manual Ver1.0 Figure 38. Advanced Setup – Security – Add new Parental Control restriction 5.6 - DNS DNS Server - 34 -... - Page 35 Dynamic DNS The Dynamic DNS service allows you to give a dynamic IP address a static hostname in any of the domains. This function allows your M404/M405 to be more easily accessible from various locations of the Internet. Choose “Add” to configure Dynamic DNS.
- Page 36 Manual Ver1.0 Select your Dynamic DNS service provider from ‘D-DNS provider’, and enter your registration information. Click “Save/Apply” to save the configuration. Figure 41. Advanced Setup – DNS – Add Dynamic DNS - 36 -...
-
Page 37: Dsl
Manual Ver1.0 5.7 - DSL This page allows you to choose which handshake protocols you want your M404/M405 to look through when training. Uncheck any of the listed protocols that have “Enabled” at the end of it to have the modem skip that protocol when synchronizing with your ADSL line. -
Page 38: Internet Time
Manual Ver1.0 5.8 - Internet Time The M404/M405 can synchronize its internal time with an Internet time server when available. To enable this function, check “Automatically synchronize with Internet time servers”. Select First and Second NTP time server from the pull down menu. Or select “Other”... - Page 39 Manual Ver1.0 Figure 44. Advanced Setup - Access Control - Service IP Addresses The IP Address Access Control mode, if enabled, permits access to local management services from IP addresses contained in the Access Control List. If the Access Control mode is disabled, the system will not validate IP addresses for incoming packets.
- Page 40 Access to your router is controlled through three user accounts: admin, support, and user. admin: has unrestricted access to change and view the M404/M405 configuration. support: is used to allow an ISP technician to access the M404/M405 for maintenance and to run diagnostics.
-
Page 41: Ipsec
Figure 46. Advanced Setup - Access Control – Passwords 5.10 - IPSec The M404/M405 also has the ability to create a VPN (Virtual Private Network) tunnel using IPSec as the security measure. VPN allows user to remotely connect to a network using their Broadband connection. -
Page 42: Certificate
Manual Ver1.0 Click the “Add” button create a new VPN connection Figure 48. Advanced Setup – IPSec Add 5.11 - Certificate This page allows user to authenticate their VPN session using certificate. Some VPN network requires this. There are two sections: Local and Trusted CA. LOCAL option: A maximum of 4 certificates are supported. - Page 43 Manual Ver1.0 Figure 49. Advanced Setup - Certificates Figure 50. Advanced Setup – Local – Create Certificate Figure 51. Advance Setup – Certificates – Local Import Trusted CA option: This is used to verify peer certificates. Please click on “Import Certificate”...
- Page 44 Manual Ver1.0 Figure 52. Advanced Setup – Certificates- Trusted CA Figure 53. Advanced Setup – Certificates - Trusted CA – Import Certificate - 44 -...
-
Page 45: Management Utilities
System Administrator can do the M404/M405 settings backup, update, and restore default here. The settings can be saved from M404/M405 to PC. The saved setting file can also be loaded from PC to M404/M405. These 2 functions can help the system administrator to manage large amount of M404/M405 efficiently. -
Page 46: Update Settings
6.2 - Update Backup Settings To update the configuration, click on “Browse” and a Choose-File-window will pop up. Locate the saved file and click on “Update Backup Settings”. The M404/M405 will modify its settings based on the update file. Figure 56. Management Utilities – Update Settings... -
Page 47: Restore Settings
Figure 57. Management Utilities– Restore Default Settings 6.4 - Update Firmware The new software could be updated from the Local PC connected to M404/M405 via Ethernet cable. Click on “Browse” to locate the new software image file in the PC. And then Click on “Update Software”... -
Page 48: Tr-069 Client
6.5 - TR069 Server This feature allows your Internet Service Provider’s ACS (Auto Configuration Server) to provision your M404/M405 remotely. Actions such as configuring the modem settings, diagnostic, and collecting data can be accomplish with this feature. The information for the settings to be entered in the fields must be provided by your Internet Service Provider. -
Page 49: Save/Reboot
Manual Ver1.0 6.6 - Save/Reboot Click “Reboot Router” to reboot M404/M405. The M404/M405 would automatically save the configuration before reboot, so that modified settings would take effect after reboot. Figure 60. Management Utilities – Save / Reboot 6.7 - System Log This allows System Administrator to view the System Log and configure the System Log options. - Page 50 Manual Ver1.0 Figure 61. Management Utilities – System Log Click on “Configure System Log” to configure the log options. There are 8 events of “Log Level” and “Display Level”: Emergency, Alert, Critical, Error, Warning, Notice, Informational, and Debugging. If the log mode is enabled, the system will begin to log all the selected events.
- Page 51 Manual Ver1.0 Figure 62. Management Utilities – System Log Configuration Click on “View System Log” to see the router log based on your configuration - 51 -...
-
Page 52: Connection Status
Manual Ver1.0 7. Connection Status 7.1 - LAN This page displays the status of packets transmitted and received on the M404/M405 LAN interfaces. Figure 63. Connection Status – LAN 7.2 - WAN The WAN Connection Status is broken into 2 parts: 1. - Page 53 Manual Ver1.0 Figure 64. Connection Status – WAN Connection Figure 65. Connection Status – WAN Status - 53 -...
-
Page 54: Atm
This page displays the M404/M405 ADSL connection information and status, such as Rate (Kbps), SNR, ES (Error Second)…etc. This information is useful when there are problems with your ADSL connection (The M404/M405 DSL LED light does not stay solid for example) -
Page 55: Route
Manual Ver1.0 Figure 67. Connection Status – ADSL 7.5 - Route This page displays the M404/M405 routing table. - 55 -... -
Page 56: Arp
Manual Ver1.0 Figure 68. Connection Status – Route 7.6 - ARP (Address Resolution Protocol) This page displays the M404/M405 ARP table. Figure 69. Connection Status – ARP 7.7 - DHCP This page displays the lease time for PC’s or devices connected to the router... -
Page 57: Summary
Figure 70. Connection Status - DHCP 7.8 - Summary This page displays the summary of the M404/M405 hardware, software and connection information. Line Rate shows the speed that you are currently connected to your ISP. In the figure below the M404/405 is currently connected at a Download speed of 3000 Kbps or 3 Mbps with an Upload speed of 512 Kbps or 0.5 Mbps. -
Page 58: Diagnostics And Help
Manual Ver1.0 8. Diagnostics and Help This page allows users to test the Ethernet port connection, DSL port connection, and connection to the Internet Service Provider. If a test displays a fail status, click “Return Diagnostic Tests” at the bottom of the page to make sure the fail status is consistent. If the test continues to show fail, click “Help”... -
Page 59: Appendix A - Specifications
9. Appendix A – Specifications A1. Hardware Specifications Local Interface One 10/100BaseT Ethernet port (IEEE 802.3, RJ-45 connector) • • One USB 1.1 port (M405) WAN ADSL Line Interface Complies with G.dmt (G.992.1) Annex A • Complies with G.lite (G.992.2) and T1.413 •... - Page 60 Manual Ver1.0 • DNS relay • UPnP • IGMP-Proxy Configuration and Network Management • DHCP server for IP management • HTTP (Web Server) for configuration and firmware upgrade • TFTP Server • FTP Server Firewall • NAT ALGs • IPSEC pass-through •...
-
Page 61: Appendix B - Warranties
Manual Ver1.0 10. Appendix B – Warranties DQ Technology adheres to the strictest Quality Assurance processes to ensure that our products are free from defects prior to shipping. DQ Technology provides a standard 1 year limited warranty for all products and provides an extended warranty option for North American customers. -
Page 62: Appendix C - Regulations
Manual Ver1.0 Appendix C – Regulations C1. FCC Part 15 Notice Warning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 to the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment. -
Page 63: Contact Information
Manual Ver1.0 Contact Information You can help us to serve you better by sending us your comments and feedback. Listed below are the addresses, and telephone and fax numbers of our offices. You can also visit us on the World Wide Web at www.dqusa.com for more information.
