All manuals and user guides at all-guides.com VisionNet 708 User’s Manual VisionNet 708 ADSL Ethernet Modem...
Page 2
A l l R i g h t s R e s e r v e d . No part of this publication may be reproduced or distributed in any form or by any means, or stored in a database or retrieval system, without the prior written permission of DQ Technology, Inc.
C h a p t e r 3 . I n s t a l l a t i o n O f V i s i o n N e t 7 0 8 ▣ Installation VisionNet 708 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 5...
Page 4
Chapter 1. Introduction This chapter provides the brief concept of ADSL, and the external form and specification of VisionNet 708. This chapter covers the following topics: ◈ W h a t i s A D S L ◈ V i s i o n N e t 7 0 8 L a y o u t a n d L E D D e s c r i p t i o n...
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l ◈ What is ADSL ADSL (Asymmetric Digital Subscriber Line) is a technology for transmitting digital information at a high bandwidth on existing phone lines to homes and businesses. Unlike regular dialup phone service, ADSL provides continuously available, "always on"...
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l ◈ V isionNet 708 Layout and LED Description VisionNet 708 (Front view)
Page 7
S t a t u s D e s c r i p t i o n ① POWER VisionNet 708 power status It’s On when VisionNet 708 is connected to PC which is working. ② USB is awake USB connected PC which is working ③...
Page 8
VPI: 0~255 , VCI :0~65,535 <<Notice >> The connection speed of VisionNet 708 may vary depending on your ADSL service, the ADSL line condition, your PC specification and the distance between ADSL modem and Central Office of your local ADSL service provider.
Before Installation This chapter provides basic safety information before installation. Please read this chapter very carefully before installation. This chapter covers following topics : ◈ Safety Check ◈ The climate condition Check ◈ System Requirements Check ◈ VisionNet 708 Package Check...
☞ VisionNet 708 must be located in safe space such as near non-grounded extension cable, torn power cable and very close to the power outlet. ☞ VisionNet 708 generates the heat when it is operating. It must not be exposed to heat trap conditions.
A D S L M o d e m M a n u a l ◈ System Requirements Check Before installing and using VisionNet 708, please the following topics must be checked first. ★ P C O p e r a t i n g S y s t e m ☞...
A D S L M o d e m M a n u a l ◈ V isionNet 708 package Check When opening VisionNet 708 Package, please check the following items in the Package. VisionNet 708 (ADSL Ethernet Modem) User’s manual...
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l Chapter 3. Installation of VisionNet 708 This chapter provides the brief concept of ADSL, and the external form and specification of VisionNet 708.
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l ◈ Installation VisionNet 708 Start Internet Explorer to view or reset the configuration of the ADSL And type 10.0.0.2 at [Open] and click [OK] button.
Page 15
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l ⑴ ADSL Home Page : appearing home page of VisionNet 708 ADSL and Device, DSL, WAN Interfaces, LAN Interfaces, Services Summary...
Page 16
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l ⑵ DSL : You can find the connecting of ADSL and CRC, HEC ⑶ ATM VCC : Circumstance in ATM VCC Configuration you can set the Value of VPI VCI...
Page 17
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l ⑷ Bridging : You should use Enable when you do the EoA(Bridge Mode) in Bridge configuration.
Page 18
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l ⑸ LAN : You can find and adjust the IP Address and Subnet Mask of LAN in LAN Configuration, the IP Address and Subnet Mask of USB in USB Configuration.
Page 19
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l ⑹ NAT : If you use the ADSL in Router, [NAT] should be in condition “Enable” - NAT Configuration ⑺...
Page 20
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l IP(IPoA) (Provided by ISP) ⑻ Commit & Reboot : It is Saving the adjust of ADSL click the [commit] button.
Page 21
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l ⑼ PPP : PPP Configuration set the PPPoA & PPPoE of ADSL. After adjusting you should click the [Submit] button, and change the [Commit&Reboot], you should saving the configuration in circumstance of Commit and Reboot...
Page 22
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l ⑽ User Password Configuration : This page is modify [User Password] of ADSL. You be sure that click [Submit] button, and save that you did in [Commit & Reboot]. 1 .
Page 23
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l 1-1. Click [WAN] tap. Click “PPP ” in upward row of this page, and you can find [ A d d ] button in next page.
Page 24
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l 1-2. modifying in [ P P P I n t e r f a c e - A d d ] .page l ATM VC : aal5-1(setting value in ATM VC Provided by ISP) l Protocol : Choice PPPoA or PPPoE l [ U s e D h c p &...
Page 25
All manuals and user guides at all-guides.com A D S L M o d e m M a n u a l 1-3. You do such like “1-2”, you can see fixed page such like below. 1-4. When Oper. Status Linked Up, you can use internet program freely.
