Page 1
User and Installation Guide Guide d’Utilisateur et d’Installation 5.8 GHz DIGITAL Wireless Speaker Kit 5.8 GHz NUMÉRIQUE Amplificateurs Sans Fil Model 1600 / Modèle 1600...
EN - Contents Unpacking ... 2 Connecting the transmitter Connecting the amplifiers Placing the transmitter and amplifiers Operating the transmitter Operating the amplifiers Troubleshooting ... 8 Technical specifications Safety information ... 11 Your warranty ... 12 FR - Table des matières Déballage ...
Do not connect the large AC adapter to the transmitter. Copyright (C) 2010 Amphony. All rights reserved. The information contained herein is subject to change without notice. Revisions may be issued to advise of such changes and/or additions.
Page 4
User and Installation Guide Using the transmitter RCA audio input: Transmitter Using the transmitter speaker audio input: Transmitter SPEAKER OUT Audio Source DC 9V AC adapter AUDIO LINE OUT Audio Source DC 9V AC adapter DC 9 V 250 mA Power outlet DC 9 V 250 mA...
Therefore, it is recommended to connect power to the amplifier prior to connecting the speakers. Speaker connections: Amplifier for left speaker Model 1600 Left speaker Connect the right speaker to the amplifier for the right speaker similarly. Page 4...
User and Installation Guide Placing the transmitter and amplifiers For best reception, we recommend that each amplifier be placed within the line of sight from the transmitter. If possible, each amplifier should be placed right side up with its front toward the transmitter. The transmitter should be placed at an elevation such that there are no obstacles between the transmitter and amplifiers (line of sight) in an area where there will be the least amount of traffic.
User and Installation Guide Operating the transmitter After powering up the transmitter, the transmit light will go on for approximately five seconds while the transmitter initializes. After initialization, the transmit light will go out. Initially, set the transmitter volume control to a middle setting. Once audio is detected at the audio input, the transmit light will go on and the transmitter will transmit the audio signal.
If no audio signal is received for more than 2 minutes, the amplifiers will go into standby mode (power-down mode). Amplifier volume control Model 1600 DC 36V Page 7...
User and Installation Guide Troubleshooting Problem Possible Cause The transmit light Faulty AC adapter does not go on after or faulty power outlet DC power is applied to the transmitter The transmit light No audio present at goes out after a few audio input seconds and does not light again...
Page 10
Transmitter range is Strong interference extremely short Too many obstacles For more information, including a detailed troubleshooting guide, visit the Amphony web site at: www.amphony.com Solution In some cases, there may be strong interference preventing proper reception of the audio signal which can be caused by 5.8 GHz cordless...
User and Installation Guide Technical Specifications Transmitter: Audio transmission method: Digital Transmitter frequency: 5.8 GHz Error correction: 1/2 rate FEC Audio sampling method: 128 times oversampling Transmitted data rate: > 3 Mbps Transmitter operating range: max. 200 ft. line of sight, max. 50 ft. through walls and ceilings Amplifiers: Output power: 2 x 150 W (2 x 80 Wrms) Frequency response: 2 Hz …...
• Do not attempt to service the unit yourself. If liquid or any metal objects such as paper clips, wire or staples accidentally fall inside, disconnect the product from the power source immediately, and consult an authorized service center. • Please refer any service to an authorized Amphony service center. ATTENTION!
This warranty extends only to the original user of the equipment (“you”, ”your”) and is limited to the purchase price of each part. Amphony and its affiliated companies (”we”, ”our”, ”us”) warrant this Wireless Transmitter / Amplifier Set against defects in materials or workmanship as follows.
Page 15
Guide d’Utilisateur et d’Installation Utilisez les données audio RCA du transmetteur: Transmetteur Utilisez les données audio haut-parleur du transmetteur: Transmetteur SPEAKER OUT Source Audio Page 14 DC 9V AUDIO LINE OUT Source Audio DC 9V DC 9 V 250 mA Prise de courant DC 9 V 250 mA...
éviter un lourd claquement durant la mise en route. Branchement des Haut-parleurs: Amplificateur gauche pour haut-parleur gauche Model 1600 Haut-parleur gauche Branchez l’haut-parleur droit à l’amplificateur droit de la même façon. DC 36V Un adaptateur de courant électrique...
Guide d’Utilisateur et d’Installation Emplacement du transmetteur et des amplificateurs Pour la meilleure réception, nous recommandons que chaque amplificateur soit aligné directement vers le transmetteur. Si possible, chaque amplificateur devrait être placé du côté verso et vers le transmetteur. Le transmetteur devrait être placé à une hauteur qui évite les obstacles entre le transmetteur et l’amplificateur (alignement direct) dans un endroit où...
Guide d’Utilisateur et d’Installation Fonctionnement du transmetteur Après avoir branché le transmetteur, la lumière de transmission s’allume pour environ cinq secondes durant l’initialisation. Après l'initialisation, la lumière s’éteint. Au début, réduisez le volume au mi-niveau. Lorsque l’audio est détectée par le transmetteur, la lumière de transmission s’allume et transmet le signal audio.
Tournez le volume de chaque amplificateur a un niveau désiré des haut-parleurs de façon qu’ils soient équilibrés. Lorsque l’audio n’est plus reçue pour plus de deux minutes, le transmetteur entrera dans le mode repos (power-down mode). Contrôle de volume des amplificateurs Model 1600 DC 36V Page 18...
Guide d’Utilisateur et d’Installation Tableau de problèmes/solutions PROBLÈME Aucune lumière ne s’allume après avoir branché le transmetteur dans l’alimentation de courant La lumière du transmetteur s’éteint après quelques secondes et ne se rallume Manque de son dans les amplificateurs L’Audio est distordue L’Audio des haut- parleurs est trop...
Page 21
Guide d’Utilisateur et d’Installation PROBLÈME RAISON POSSIBLE L’Audio coupe par Fortes interférences intermittence ou grésille L’Alimentation est instable L’audio est lourd Fortes interférences Le volume du transmetteur est réglé au minimum Le signal audio est trop faible La portée du Fortes interférences transmetteur est très courte...
Guide d’Utilisateur et d’Installation Spécifications technique Transmetteur: Transmission audio: Numérique Fréquence de transmission: 5.8 GHz Niveau de bruit: typ. 93 dB Correction d’erreur: 1/2 rate FEC Echantillonage audio: 128 times oversampling Taux de transmission données: > 3 Mbps Portée: Max. 60 m sans obstacle, max. 20 m à travers les murs Niveau d’entré...
• N'essayez pas de réparer l'appareil vous-même. Si un liquide ou autre objet en métal tels que trombones, fil de fer, agrafes tombent accidentellement dans l'appareil, débranchez le immédiatement du courant d'alimentation, et consultez un centre de service autorisé. Veuillez s'il vous plait vous rendre au prés d'un centre de service autorisé par Amphony.
Cette garantie limitée n’est pas transférable (« vous », « votre ») et est limitée au prix d’achat de chaque pièce. Amphony Corp. et ses compagnies affiliées (« nous », « notre ») garantissons ce amplificateurs sans fil est exempt de tout défaut ou vice de fabrication comme suit.
