- Page 1 User and Installation Guide iFini y t Digital Wireless Indoor / Outdoor Speaker...
-
Page 2: Table Of Contents
Contents: Unpacking ..................Connecting power ................Selecting the audio channel ............Turning on speaker power .............. Pairing the speaker and transmitter ..........Setting the speaker volume and treble ........... Troubleshooting ................Technical specifications ..............Safety information ................Limited warranty ................ -
Page 3: Unpacking
Important Note: In order to operate your wireless speaker, you need an Amphony iFinity audio transmitter (sold separately). If you have purchased a full set, the transmitter is already part of the set and is packaged separately. Please refer to the transmitter user guide for operation instructions. - Page 4 User and Installation Guide iFini y t Network Mono DC 36V Left Right Pairing Treble Volume AC adapter DC 36 V Power outlet Connecting power Page 2...
-
Page 5: Selecting The Audio Channel
User and Installation Guide iFini y t Network Mono DC 36V Left Right Pairing Treble Volume Channel-select switch Selecting the audio channel Slide the audio-channel switch to the audio channel which you want the speaker to receive. You can either receive the left audio channel, the right channel or a mix between both channels (mono). -
Page 6: Turning On Speaker Power
User and Installation Guide iFini y t Network Network status light Mono DC 36V Left Right Pairing Treble Volume Turn to minimum Volume control On/Off switch Turning on speaker power Turn the speaker volume control to the minimum position. Next, slide the on/off switch into the “On“ position. The network status light should start flashing. -
Page 7: Pairing The Speaker And Transmitter
User and Installation Guide iFini y t Network Network status light Mono DC 36V Left Right Pairing Treble Volume Pairing button Pairing the speaker and transmitter To receive audio from the transmitter, set the transmitter into pairing mode by pushing the transmitter pairing button. Then, push the pairing button of the speaker within 5 minutes. -
Page 8: Setting The Speaker Volume And Treble
User and Installation Guide iFini y t Network Mono DC 36V Left Right Pairing Treble Volume Treble control Volume control Setting the speaker volume and treble Now slowly increase the volume control. Use the treble control to adjust the treble of your speaker. Please follow the instructions in the transmitter user guide for adjusting the transmitter properly to your audio source in order to maximize the dynamic range of your speaker. -
Page 9: Troubleshooting
User and Installation Guide Troubleshooting Please check the network status light of the speaker and then choose from the following problems: Problem Possible Cause Solution No Sound - Network AC adapter not Check AC adapter for status light is OFF plugged in properly proper fit Speaker not... -
Page 10: Technical Specifications
User and Installation Guide Technical Specifications Amplifier: Bi-amplification: two separate Class-D amplifiers Amplifier Power: 150W peak, 80W rms Drivers: 5" woofer, 1" tweeter Crossover: Active Frequency response (-6 dB): 60 Hz - 18 kHz Amplifier distortion (THD): 0.06% @ 50 Watts Power efficiency: Max. -
Page 11: Safety Information
User and Installation Guide IMPORTANT SAFETY INFORMATION ATTENTION! READ THESE SAFETY INSTRUCTIONS CAREFULLY AND HEED ALL WARNINGS IN THIS MANUAL. POWER SOURCE To avoid product malfunction, and to protect against electric shock, fire or personal injury, please observe the following: •... - Page 12 • Do not attempt to service the unit yourself. If liquid or any metal objects such as paper clips, wire or staples accidentally fall inside, disconnect the product from the power source immediately, and consult an authorized service center. • Please refer any service to an authorized Amphony service center. Page 10...
-
Page 13: Limited Warranty
This warranty extends only to the original user of the equipment (“you”, ”your”) and is limited to the purchase price of each part. Amphony and its affiliated companies (”we”, ”our”, ”us”) warrant this Wireless Speaker against defects in materials or workmanship as follows. - Page 14 Note: No responsibility is assumed for the presence of interference outside of Amphony’s control which may prevent proper operation.
- Page 15 Copyright (C) 2011 Amphony. All rights reserved. The information contained herein is subject to change without notice. Revisions may be issued to advise of such changes and/or additions. All product names, trade names, or corporate names mentioned in this document are acknowledged to be the proprietary property of the registered owners.
