- Page 1 RE-PI HDMI Power Inserter OPERATION MANUAL...
-
Page 2: Safety Precautions
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 3: Table Of Contents
Table of Contents 1. Introduction .................. 1 2. Applications ................. 1 3. Package Contents ..............1 4. System Requirements ..............1 5. Features ..................1 6. Specifications ................2 7. Operation Controls and Functions ..........3 Left Panel ..............3 Right Panel .............. -
Page 4: Introduction
1. Introduction The HDMI Power Main allows users to add extra power to HDMI connections. When cascading video over long distances, or when the source device (such as a DVD/Blu Ray player or PS3) cannot provide enough power, your often left confused about what to do, because without enough power your video signal will not be stable and you cannot increase your operating distance. -
Page 5: Specifications
6. Specifications Input Port 1 x HDMI (Female type) Output port 1 x HDMI (Female type) Input Cable Distance 1080p 8bit (8M), 12bit (5M) Output Cable Distance 1080p 8bit (8M), 12bit (5M) ESD Protection Human Body model: ± 8kV (air-gap discharge) ±... -
Page 6: Operation Controls And Functions
7. Operation Controls and Functions 7.1 Left Panel HDMI input: Connect the HDMI input port to the HDMI output port of your ① source equipment such as HDMI switcher/HDMI Splitter/HDMI Matrix. 7.2 Right Panel HDMI output: Connect the HDMI output port to the HDMI input port of ①... -
Page 7: Connection And Installation
8. Connection and Installation... -
Page 8: Acronyms
Acronyms Acronym Complete Term HDMI High-Definition Multimedia Interface... - Page 9 www.cypeurope.com...
