Nexto Di Video storage pro plus User Manual

Portable storage for professional video cameras

Advertisement

Quick Links

VIDEO STORAGE pro+
Portable Storage for Professional
Video Cameras
User Guide
Version 10/10
NextoDI Co., Ltd.
www.nextodi.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Video storage pro plus and is the answer not in the manual?

Questions and answers

Summary of Contents for Nexto Di Video storage pro plus

  • Page 1 VIDEO STORAGE pro+ Portable Storage for Professional Video Cameras User Guide Version 10/10 NextoDI Co., Ltd. www.nextodi.com...
  • Page 2 NVSPRO+ supports professional video cameras from various manufacturers, and memory formats such as SxS, CardBus Memory Card (including P2/P2E) and ● Backup your data. Under no conditions is NextoDI, Inc. liable for loss of or Compact Flash (CF) Card. damage to a computer; or loss of, or damage to, a program, records, or Please read this manual before using the product.
  • Page 3: Table Of Contents

    16. BAD SECTOR RECOVREY .............. 17. ADVANCED FUNCTIONS ..............CAPACITY CHECK ................SELF TEST ..................BUZZER ..................FIRMWARE UPDATE ..............DELETE TMP FOLDER ..............LANGUAGE SETTING ..............Table of Contents 18. BURNING A BLU-RAY DISC ............19. EXAMPLES OF BASIC FUNTIONS ..........
  • Page 4: Product Description

    10. Firmware upgrade The NVSPRO+ can synchronize the contents of a folder with the folder on an When NextoDI develops new functionality—or offers support for new video eSATAp/USB external hard drive. This allows you to make a secondary copy of formats--firmware is provided to users through the website’s download page.
  • Page 5: Contents Of The Nexto Video Storage Pro

    2. Contents of the NEXTO VIDEO STORAGE pro+ 11. Language selection 1. Main Package The NVSPRO+ supports various languages. You can select a language from the menu ③ of the NVSPRO+. For details, see chapter 17. ⑥ 12. Buzzer on/off 145.0 GB XCopy Ready The NVSPRO+ uses a buzzer to note the results of various operations.
  • Page 6: Symbols Used In This Document

    In case of any damage due to failure to observe these operating ② Leather case for attaching external eSATAp hard drive to NVSPRO+ instructions, the warranty is voided. NextoDI does not assume liability for consequential damages. Nor do we assume liability for damage ③...
  • Page 7: Device Diagram

    5. Device Diagram Warning ● The case of the hard disk must not get damp or wet. ⑨ Protect the device from humidity and water, from sun, excessive heat (>113°F) or cold (<32ºF), dust and dirt. ● When the product is brought from a cold place into a warm room, condensation may form.
  • Page 8: About The Rechargeable Battery

    If the battery operation time gets shorter, it may be time to replace the battery. When the battery is charged, the red LED turns off. Consult your authorized NEXTODI dealer to replace the internal battery. If there is an error when charging, the LED blinks. If this happens, unplug the AC adapter unit and plug it in again.
  • Page 9: Nvspro+ Interface

    8. NVSPRO+ Interface 1. Turning NVSPRO+ on/off 2. Key operation Press the power key on the right side of device The NVSPRO+ is operated by a single control key which can be used in five for more than 2sec in order to switch NVSPRO+ different ways.
  • Page 10: Formatting The Hard Drive

    9. Formatting the Hard Drive 4. The LCD Display The hard disk in the NVSPRO+ should already be formatted with the"FAT32" file system. Only one (or the first) partition can be used. Do not attempt to format the NVSPRO+ disk with a computer. Use only the format function on the NVSPRO+.
  • Page 11: Using The Nvspro+ As A Hard Drive

    ME, XP and 2000 operating systems. Drivers for Windows 98 systems can be available. For MAC OS, hard drives are Back downloaded from the NextoDI website. To download drivers, go to formatted with the file system HFS+ (MAC http://www.nextodi.com/support 149.0 GB OS Extended).
  • Page 12 PC Connection Hardware”. Then disconnect the cable from your NVSPRO+ and your computer. For MAC Drag and drop the NEXTODI icon to the trash. Then disconnect the cable from your NVSPRO+ and your computer. USING THE NVSPRO+ AS A HARD DRIVE...
  • Page 13: Data Backup(Copy) And Verify

    11. Data Backup(Copy) and Verify Three options are available for copy using up/down key selection. This chapter represents the ‘Copy’ and ‘Verify’ functions. Insert a memory card into the corresponding memory slot. The slot for the Cardbus Fast Copy Make new folder and copy all the memory card data into the folder. memory card (including P2/P2E cards) is located on the top side of the NVSPRO+.
  • Page 14: Video/Photo Preview

    12. Video/Photo Preview 4. Status The NVSPRO+ shows stored video or photo files after backup depending on the file 102.3 GB format. A preview of both the internal and external device (SxS/P2/CF/USB/ESATA) Current operation status is shown is supported. Users can also choose to delete the backup folders on the LCD display.
  • Page 15 Back (3) Preview Images (4) Selectable command Reference ● See http://www.nextodi.com/manual for supporting preview format. Reference ● The preview of the NVSPRO+ is a “best effort” preview. The preview speed differs depending on the video format. ● See http://www.nextodi.com/manual for supporting preview format.
  • Page 16 3. Delete the backup data 4. Preview from an external device Select “Delete This Backup” from the Preview 149.0 GB The NVSPRO+ supports the preview of video files 20090601.000 menu. stored on an eSATAp/USB external hard drive—as Preview 55 Files / 528 MB well as video files stored on memory cards such as: Select a Source SxS, CardBus (including P2/P2E) and CF.
  • Page 17: Using An External Hard Drive

    (via the USB adapter cable) the NVSPRO+ will not need to be connected to ● The capacity of the eSATAp hard drive should be larger than 100GB. the AC power adapter. (Other Nexto backup devices include the NextoDI ● The NVSPRO+ only supports the eSATAp (Power over eSATA) hard drive which eXtreme ND2700, the Nexto Video Storage ND2725, etc.)
  • Page 18: Making Two Copies In A Single Backup(Multi-Copy)

    14. Making Two Copies In A Single Backup (Multi-Copy) Copying a memory card to both the internal hard drive and an external eSATAp/ When Multi-Copy is in progress, do not remove 98.7 GB USB hard drive at the same time makes two copies of data in a single operation. the memory card or disconnect the USB The “Multi-copy”...
  • Page 19: Making A Secondary Copy(Sync)

    15. Making A Secondary Copy (Sync) The “Sync” function synchronizes data between the [NVSPRO] folder of the (3) Sync function NVSPRO+ and the [NEXTO] folder of an external eSATAp/USB hard drive connected on the “eSATA/USB Host” connector via eSATAp or USB cable. This function 102.3 GB A user can select two modes of duplication, compares the folders stored in the [NVSPRO] folder of the NVSPRO+ and the...
  • Page 20: Bad Sector Recovrey

    [S] to move to Delete This Backup the next step. ● The "Bad Sector Recovery" feature is supported with previewable video codec Sector Recovery only. Select Back ● See http://www.nextodi.com/manual for a list of supported preview formats. BAD SECTOR RECOVREY BAD SECTOR RECOVREY...
  • Page 21: Advanced Functions

    Back Self Test This function does not fix errors. If an error is detected during the self-test, consult 149.0 GB your authorized NEXTODI dealer. Select “HDD Info” submenu from the “HDD HDD Management Management” menu. Delete If the copy function fails, a TMP folder will be generated.
  • Page 22: Self Test

    Error found during quick test. Further use of NVSPRO+ may result in loss of backup data. HDD Smart Test 149.0 GB Consult your authorized NEXTODI dealer for service. This HDD may have Self Test The User can choose between a quick test or some errors.
  • Page 23 149.0 GB Select “FULL TEST” from the self test menu. NVSPRO+ may result in the loss of backup data. HDD Full Test Consult your authorized NEXTODI dealer for Self Test 0 Bad Clusters Found. service. Check it again at PC.
  • Page 24: Buzzer

    3. Buzzer v1.0 If a valid firmware file is not contained in 149.0 GB The Buzzer is on. Select “BUZZER “from the main Firmware Update the specified device, the NVSPRO+ indicates Preview menu to turn the buzzer sound on/off with by an error.
  • Page 25: Delete Tmp Folder

    5. Delete TMP folder 6. Language setting Select “HDD Management” from the main The user can select the preferred language 149.0 GB 149.0 GB menu. using this function. Preview Preview HDD Management HDD Management Sector Recovery Sector Recovery Select “Language” submenu from the main Buzzer Buzzer menu.
  • Page 26: Burning A Blu-Ray Disc

    18. Burning a Blu-ray Disc A user can connect a USB Blu-ray drive to the NVSPRO+ through an eSATA/USB 2. Burning the Blu-ray Disc host port. The NVSPRO+ supports the burning of Blu-Ray Discs--or the preview of Blu-ray Discs-- without the use of a computer. Only the BD-R or BD-RE is ①...
  • Page 27 The LCD screen on the NVSPRO+ shows the 102.3 GB 29.6GB Selected The selected folder will be highlighted and a completion of the Disc burning. The USB cable can 20090701.000 BD Burn Success check mark will be shown at the head of folder now be removed 20090630.000 name.
  • Page 28: Examples Of Basic Funtions

    19. Examples of Basic Functions 1. Copying from an SxS card 98.7 GB (5) If the copy is successfully completed, the result Copy Success will be shown on the LCD. Remove the SxS card to return to the initial “XCopy ready”mode. (1) Turn on the NVSPRO+ by pressing the power Copy Done button for more than 2 seconds.
  • Page 29: Auto-Generation Of Index File

    20. Auto-Generation of Index Files The NVSPRO+ automatically generates HTML index files which contain metadata 4. Copying from an IKEGAMI GFPAK and thumbnails of each video file. The NVSPRO+ supports copying from the IKEGAMI GFPAK using the “eSATA/ This function can be turned on or off from the 149.0 GB Preview USB-Host”...
  • Page 30: Troubleshooting Tips

    21. Troubleshooting Tips IF THE POWER ON THE NVSPRO+ CANNOT BE TURNED OFF VIA THE This index file is in HTML format and can be accessed via a computer using the web browser. The HTML file (NEXTOIDX.HTM) is stored in the root directory of the ON/OFF BUTTON: NVSPRO+.
  • Page 31: Battery Disposal

    22. Battery Disposal Batteries/rechargeable batteries containing harmful substances are marked with the following symbols: Cd=cadmium, Hg=mercury, Pb=lead. You can return batteries/rechargeable batteries free of charge to any authorized disposal station in your area, in our stores or in any other store where batteries/rechargeable batteries are sold.
