- Page 1 AEC-67160M Ultra160 PCI Ultra160 SCSI Adapter for Macintosh User’s Manual Ver:1.0 © Copyright 2001 ACARD Technology Corp.
- Page 2 ACARD and SCSIDE are the trademarks of ACARD Technology Corp. IBM is a trademark of the International Business Machine Corporation. Apple and the PowerMac Logo are registered trademarks of Apple Corporation.
-
Page 3: Table Of Contents
AEC-67160M Ultra160 SCSI Adapter Table of Contents Chapter 1 Introduction ............4 1.1 Introduction ..................4 1.2 Features ....................5 1.3 Specifications ..................5 1.4 Board layout ..................6 Chapter 2 Hardware Installation........... 7 2.1 Installing the Ultra160 SCSI Adapter ..........7 2.2 Installing Internal Drives .............. -
Page 4: Chapter 1 Introduction
AEC-67160M Ultra160 SCSI Adapter Chapter 1 Introduction 1.1 Introduction ACARD technology corp. dedicate to make SCSI interface to be a standard interface in Macintosh with stable function, high transfer rate and very low cost. The ACARD SCSI adapter AEC-67160M is specificity designed to speed up the high perform hard disk drive for server, Internet and RAID system or 3D image, medical imaging, CAD/CAM designer. -
Page 5: Features
AEC-67160M Ultra160 SCSI Adapter 1.2 Features ! ! ! ! ! PCI Bus Master frees CPU from I/O task loading ! ! ! ! ! Synchronous transfer rate up to 160MB/sec ! ! ! ! ! Powerful advanced setup function... -
Page 6: Board Layout
AEC-67160M Ultra160 SCSI Adapter 1.4 Board layout AEC-67160M Board Layout 68-pin Ultra160 LVD SCSI internal connector 68-pin Ultra160 LVD SCSI external connector AEC-67160M: CN1: Connect to the 68-pin Ultra160 SCSI flat cable to connect the SCSI devices. CN2: Connect to the 68-pin Ultra160 SCSI round cable to connect the... -
Page 7: Chapter 2 Hardware Installation
AEC-67160M Ultra160 SCSI Adapter Chapter 2 Hardware Installation 2.1 Installing the Ultra160 SCSI Adapter Step 1: Turn off the Mac computer. Step 2: Plug out the power core and all the connection of external devices from your system. Step 3: Referring your original case user’s manual to see how to... -
Page 8: Installing External Drives
AEC-67160M Ultra160 SCSI Adapter Note: Usually, a color wire on the edge of cable indicates pin 1 of connector, and a mark also shown on the adapter board. Step 3: Find out pin 1 of the connector on your device. -
Page 9: Installing Both External And Internal Drives
AEC-67160M Ultra160 SCSI Adapter 2. Connecting more than one devices One of the SCSI features is that you can connect two or more devices simple by place them one after another to the host SCSI adapter serially. Step 1: Make sure the external SCSI cable is match to the numbers of pin of external SCSI adapter and devices. -
Page 10: Chapter 3 System Installation
AEC-67160M Ultra160 SCSI Adapter Chapter 3 System Installation The following example is connected Hard Drive to ACARD’s AEC-67160M SCSI adapter to show a proper way of software configuration. Assume that we set an SCSI ID number “0” to AEC-67160M. 3.1 Mac OS 9 installation 1. - Page 11 AEC-67160M Ultra160 SCSI Adapter 7. Choose the hard disk you connect to AEC-67160M, then press “Initialize” button. 8. Then you can start to install an new Mac OS on the hard drive. Note: Some of Hard Driver may not be supported (see as below), please refer to your original Hard Drive manufacture to see the solution.
-
Page 12: Mac Os 10.1 Installation
AEC-67160M Ultra160 SCSI Adapter 3.2 Mac OS 10.1 installation 1. Be sure your hardware had install correctly. 2. Insert Mac OS X CD-ROM to your Macintosh. 3. Power on your Macintosh and press ‘C’ key. 4. After Mac OS X Boot up, select “Installer” from the top selection tools. - Page 13 AEC-67160M Ultra160 SCSI Adapter 8. Then click on the right down of “Partition” button to initialize the hard drive. 9. Then you can start to install an new Mac OS X on the hard drive. Note: For more information about Mac OS X installation guide, please...
-
Page 14: Verify Hard Drive Initialize
AEC-67160M Ultra160 SCSI Adapter 3.3 Verify Hard Drive Initialize For Mac OS 9.x Environment You are going to make sure the computer “initialize” hard drive if successfully. When you initialize the hard drive successfully, on the Mac window will show a new “Untitled” hard drive icon. - Page 15 AEC-67160M Ultra160 SCSI Adapter Step 2. Under the “Apple System Profiler”, you will see the “System Profiler”. Choose “Devices and Volumes” to see the devices status. Step 3. Under “Devices and Volumes”, please choose “PCI” item. You will find the SCSI card installation status.
- Page 16 AEC-67160M Ultra160 SCSI Adapter For Mac OS X Environment You are going to make sure the computer “initialize” hard drive if successfully. When you initialize the hard drive successfully, on the Mac OS X window will show a new “Untitled” hard drive icon.
- Page 17 AEC-67160M Ultra160 SCSI Adapter Step 2. Find the “Application” sign on the top of the screen and click on to open next window. Step 3. Under the “Application”, find out the “Utilities” item and click on it.
- Page 18 AEC-67160M Ultra160 SCSI Adapter Step 4. Under the “Utilities”, you will see the “Apple System Profiler”. Click on “Apple System Profiler” to see the devices status. Step 5. Under “Devices and Volumes”, please choose “PCI” item. You will find the SCSI card installation status.
-
Page 19: Chapter 4 Troubleshooting
AEC-67160M Ultra160 SCSI Adapter Chapter 4 Troubleshooting If you install the AEC-67160M and it does not function properly, follow the troubleshooting below. 1. Check power supply. When starting to check the malfunction devices, you should check the power status (ON / OFF). -
Page 20: Appendix 1 Mac Os 10.0.X Installtion
AEC-67160M Ultra160 SCSI Adapter Appendix 1 Mac OS 10.0.x installtion 1. Mac OS X Boot up, login as root. 2. Find the Mac OS X “System” folder. 3. Under the “System”, find the “Library” and click it. - Page 21 4. Select “ACard671xSCSI.kext” and remove it to Trash. Put the new driver into “Exensions” folder, then restart the computer. Note: For the AEC-67160M driver to support Mac OS 10.0.x, download it from www.acard.com/eng/support/mac.html. For Mac OS 10.1 installation, refer to Chapter 3.2.
-
Page 22: Appendix 2 Optional Scsi-Ide Bridge Products
Overview The AEC-7720U/AEC-7720UW Ultra/Ultra Wide SCSI-IDE bridge is dedicate as general-purpose bridge of SCSI (Small Computer System Interface) to IDE (Integrated Device Electronics) interface. With ACARD micro-controller core built-in, it provides more flexibility and stability for highly exploring application. AEC-7720U/AEC-7720UW supports IDE devices such as hard disk drive, CD-ROM, CD-R, DVD-ROM, etc. - Page 23 AEC-67160M Ultra160 SCSI Adapter AEC-7720U Bridge Adapter JP1 - SCSI ID Switch connector CN1 - 40-pin female IDE port JP2 - TE jumper, default is ON CN2 - 50-pin SCSI connector JP3 - Activity LED jumper CN3 - 4-pin DC power connector...
-
Page 24: Appendix 3 Technical Support Form
AEC-67160M Ultra160 SCSI Adapter Appendix 3 Technical Support Form Email: support@acard.com http://www.acard.com Model: F/W Version: AEC- System Configuration Main Board vendor BIOS version SCSI adapter Chipset Memory Dispay card Other I/O card OS version Hard Disk Configuration Hard Disk Model/type... - Page 25 AEC-67160M Ultra160 SCSI Adapter...
