- Page 1 AVXMTGHR1D 7” LCD MONITOR WITH BUILT-IN DVD PLAYER FOR REAR SEAT ENTERTAINMENT PUSH OPERATION MANUAL / INSTALLATION GUIDE 128-8944B...
-
Page 2: Important Notice
Important Notice Installation of headrest products require careful planning and preparation. Be extremely careful of seats that have airbags built into them. Keep wiring away from any air bag wiring (usually identified by yellow connectors and yellow wire jackets). Damage to air bag wiring can result in personal injury to vehicle occupants. -
Page 3: Specifications
Headphone Audio Output 0.03W @ 32 ohms Video Output 1.0Vp-p @ 75 ohms 10V~16V DC Power Source Dimension (L x W x H) 147mm x 275mm x 200mm 5.7in x 10.8in x 7.8in Specifications subject to change without notice. AVXMTGHR1D... - Page 4 MATERIAL TO USE IN THIS PACKAGE: 1) AVXMTGHR1D System Monitor with DVD Player (AVXMTGHR1D) (1pc) NOTE: The AVXMTGHR1D monitor has been designed to be interchangeable from one headrest to the other. The headrests will still have the Green and Red Din cables on...
-
Page 5: Headrest Cover Replacement
4.Place the monitor cable into the space on the right side of the headrest and lower the monitor into position to align the two Philips screws with the screw holes in the headrest. Close the screen and press the PUSH button to secure the screen. Push 5.Tighten screws Tighten Philips Screws AVXMTGHR1D... -
Page 6: Vehicle Preparation
The mounting method, and the location will vary from vehicle to vehicle, so this manual will only focus for the installation of the AVXMTGHR1D Monitors in the supplied configuration. The best location for the AVXMTGHR1D System components is: a. -
Page 7: Wireless Fm Modulator
9) Connect all the components together (electrically) and verify proper operation of all the system functions. Wireless FM Modulator The AVXMTGHR1D is equipped with a built-in wireless FM Modulator, that allows you to listen to the DVD audio signal by tuning your vehicle’s radio to the selected frequency, ( 87.7MHz, (... - Page 8 AVXMTGHR1D WIRING DIAGRAM Headrest Monitor PUSH GREEN 12V+VDC Video Out Yellow Ground- Video In Yellow Audio Out Right Red Audio In Right Red Audio Out Left White Audio In Left White 8 Pin (M) Din Cable Red with RCA Cable...
-
Page 9: Controls And Indicators Diagram
AVXMTGHR1D CONTROLS AND INDICATORS DIAGRAM (FRONT VIEW) LCD PANEL PUSH POWER/SOURCE VOLUME /NEXT PLAY/PAUSE SYSTEM MENU VOLUME PREVIOUS STOP SCREEN RELEASE IR SENSOR IR HEADPHONE TRANSMITTER LENS PULL DOWN HEADPHONE JACK AUX IN JACK AUX IN PHONE SD CARD READER... -
Page 10: Remote Control Operation
3. Align the battery holder with the remote control and push until the holder clicks. Remote Control Function Description POWER SOURCE DVD SOURCE MUTE VOLUME ENTER PREV NEXT PAUSE PLAY STOP SETUP REPEAT SUBTITLE AUDIO ZOOM SYSTEM MENU DISC MENU DISPLAY FMM ON/OFF CHANNEL SELECT AVXMTGHR1D... - Page 11 DVD player options such as OSD Language, Video, Rating etc. Refer to the settings and adjustment section for more information. 9. REPEAT Button Allows the user to repeat a selected track, folder, title, chapter, or all. AVXMTGHR1D...
- Page 12 The type and number of subtitle languages vary from disc to disc. 18. AUDIO Button Press to display and select the available AUDIO languages in DVD mode. Each time you press the button, the language changes. NOTE: The audio languages vary from disc to disc. AVXMTGHR1D...
- Page 13 DVD Source. Press to change source in sequence of DVD > USB > SD Card NOTE: The DVD Source button is used to access MP3 and audio CDs when these discs are in the disc compartment. AVXMTGHR1D...
- Page 14 The screen mode select feature allows the user to change the screen format (aspect ratio from 4:3 or to 16:9). SCREEN MODE 16:9 The IRT can be set to Channel A or Channel B for use with optional wireless headphones. The IRT function can also be set to off. AVXMTGHR1D...
-
Page 15: Settings And Adjustments
ENTER to confirm the selection. 5. Repeat steps 3 and 4 to set the options that reside on the same menu page. 6. To change to another menu page, use the cursor buttons ( ) then, repeat steps 2 through 5. AVXMTGHR1D... -
Page 16: General Page
LAST MEMORY. Press the cursor button to open the sub menu that contains the different options available. Press the cursor button highlight the desired option, and press ENTER to confirm the selection. Use the cursor button to return to the options. AVXMTGHR1D... -
Page 17: Audio Setup Page
TREBLE BOOST. Press the cursor button to open the sub menu that contains the different options available. Press the cursor button highlight the desired option, and press ENTER to confirm the selection. Use the cursor button to return to the options. AVXMTGHR1D... -
Page 18: Preference Page
Press the cursor button to open the sub menu that contains the different options available. Press the cursor button to highlight the desired option, and press ENTER to confirm the selection. Use the cursor button return to the options. AVXMTGHR1D... -
Page 19: Audio Menu
DISC MENU. Press the cursor button to open the sub menu that contains the different options available. Press the cursor button to highlight the desired option, and press ENTER to confirm the selection. Use the cursor button to return to the options. AVXMTGHR1D... - Page 20 DEFAULT. Press the cursor button to open the sub menu that contains the different options available. Press the cursor button to highlight the desired option, and press ENTER to confirm the selection. Use the cursor button to return to the options. AVXMTGHR1D...
-
Page 21: Exit Setup Page
ENTER to display the contents in the folder. Press the cursor button to move the highlight to the desired file in the folder and press ENTER to begin playback of the highlighted file. AVXMTGHR1D... - Page 22 MP3 format with very little loss of quality, while taking up much less space. CD-R discs that have been encoded in MP3 format can be played on the DVD player. The DVD player plays the songs in the order they were burned on to the disc. AVXMTGHR1D...
- Page 23 ENTER to begin playback of the highlighted file. The system will always default to the DVD when the system detects a disc in the DVD player. AVXMTGHR1D...
-
Page 24: Dvd Basics
Region 2- Japan, Europe, South Africa, Middle East, Greenland Region 3- S. Korea, Taiwan, Hong Kong, Parts of South East Asia Region 4- Australia, New Zealand, Latin America (including Mexico) Region 5- Eastern Europe, Russia, India, Africa Region 6- China AVXMTGHR1D... -
Page 25: Troubleshooting
3. The feature is not available at the moment. 4. A title or chapter number that is out of range has been requested. Picture is distorted The disc might be damaged. Try another disc. " It is normal for some distortion to appear during " AVXMTGHR1D... - Page 26 DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY. person or representative is authorized to assume for the Company any liability other than expressed herein in connection with the sale of this product. Audiovox Electronics Corporation, 150 Marcus Blvd., Hauppauge, New York 11788 1-800-645-4994 128-6429F AVXMTGHR1D...
- Page 27 NOTES...
- Page 28 © 2011 Audiovox Electronics Corp., Hauppauge, NY 11788 128-8944B...
