Page 1
OWNER’S MANUAL LED TV *LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. LN52** www.lg.com P/NO : MFL67688553(1306-REV00) Printed in Korea...
TABLE OF CONTENTS TABLE OF CONTENTS SETTING UP THE TV Attaching the stand Tidying cables MAKING CONNECTIONS Antenna Connection HDMI Connection Adapter Connection USB Connection CI module Connection Euro Scart Connection COMMON LANGUAGE LIST English Italiano LANGUAGE SPECIFICATIONS COMMON...
SETTING UP THE TV SETTING UP THE TV Image shown may differ from your TV. Attaching the stand (Only 32LN52**) P5 x 25 Stand Body Front Stand Base CAUTION y When attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to protect (Only 42LN52**) the screen from scratches.
SETTING UP THE TV Tidying cables 1 Gather and bind the cables with the Cable (Only 32LN52**) holder. Cable holder Cable holder hole M4 x 14 2 Fix the Cable holder firmly to the Cable holder hole. (Only 42LN52**) CAUTION y Do not move the TV by holding the cable holder, as the cable holders may break, and injuries and damage to the TV may...
MAKING CONNECTIONS MAKING CONNECTIONS Italiano Collegare il televisore all’antenna centralizzata con un cavo RF (75 Ω). This section on MAKING CONNECTIONS mainly NOTA uses diagrams for the 32LN520B models. Antenna Connection y Utilizzare uno sdoppiatore del segnale per usare più di 2 televisori. y Se la qualità...
MAKING CONNECTIONS HDMI Connection English Transmits the digital video and audio signals from an external device to the TV. Connect the external device and the TV with the HDMI cable as shown. NOTE y It is recommended to use the TV with the HDMI connection for the best image quality.
MAKING CONNECTIONS Adapter Connection USB Connection DC IN DC Adapter (*Not Provided) English Connect a USB storage device such as a USB flash memory, external hard drive, or a USB English memory card reader to the TV and access the MY 1 Connect the antenna cable to the antenna MEDIA menu to use various multimedia files.
MAKING CONNECTIONS CI module Connection Italiano Consente la visione dei servizi codificati (a pagamento) in modalità TV digitale. Questa funzione non è disponibile in tutti i paesi. NOTA y Verificare che il modulo CI sia inserito nello slot della scheda PCMCIA nel verso corretto.
MAKING CONNECTIONS Euro Scart Connection Italiano Consente la trasmissione dei segnali audio e video da un dispositivo esterno al televisore. Collegare il dispositivo esterno e il televisore con il cavo Euro Scart come mostrato nell’illustrazione di seguito. Tipo di uscita Modalità...
Page 10
A-10 MAKING CONNECTIONS English Italiano Connect various external devices to the TV Collegare diversi dispositivi esterni al televisore e and switch input modes to select an external modificare la modalità di ingresso per selezionare device. For more information of external device’s un dispositivo esterno.
Page 11
OWNER’S MANUAL LED TV *LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. www.lg.com...
TABLE OF CONTENTS TABLE OF CONTENTS LICENSES OPEN SOURCE SOFTWARE NOTICE SAFETY INSTRUCTIONS ASSEMBLING AND PREPARING Unpacking Parts and buttons - Using the Joystick button Lifting and moving the TV Mounting on a table Mounting on a wall REMOTE CONTROL USING THE USER GUIDE MAINTENANCE Cleaning your TV...
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com.
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS Please read these safety precautions carefully before using the product. WARNING y Do not place the TV and/or remote control in the following environments: - A location exposed to direct sunlight - An area with high humidity such as a bathroom - Near any heat source such as stoves and other devices that produce heat - Near kitchen counters or humidifiers where they can easily be exposed...
Page 15
SAFETY INSTRUCTIONS y Bend antenna cable between inside and outside building to prevent rain from flowing in. This may cause water damaged inside the Product and could give an electric shock. y When mounting TV onto wall make sure to neatly install and isolate cabling from rear of TV as to not create possibility of electric shock/fire hazard.
Page 16
SAFETY INSTRUCTIONS y Do not allow any impact, shock or any objects to fall into the unit, and do not drop anything onto the screen. You may be injured or the product can be damaged. y Never touch this product or antenna during a thunder or lighting storm. You may be electrocuted.
Page 17
SAFETY INSTRUCTIONS y Do not install the product on places such as unstable shelves or inclined surfaces. Also avoid places where there is vibration or where the product cannot be fully supported. Otherwise, the product may fall or flip over, which may cause injury or damage to the product.
Page 18
SAFETY INSTRUCTIONS y Please follow the installation instructions below to prevent the product from overheating. - The distance between the product and the wall should be more than 10 cm. - Do not install the product in a place with no ventilation (e.g., on a bookshelf or in a cupboard).
Page 19
SAFETY INSTRUCTIONS y When moving or unpacking the product, work in pairs because the product is heavy. Otherwise, this may result in injury. y Contact the service centre once a year to clean the internal parts of the product. Accumulated dust can cause mechanical failure. y Refer all servicing to qualified service personnel.
ASSEMBLING AND PREPARING NOTE y Image shown may differ from your TV. y Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual. y The available menus and options may differ from the input source or product model that you are using.
Page 21
ASSEMBLING AND PREPARING Remote control, batteries (AAA) Owner’s manual (See p. 18) Adapter Power Cord (See p. A-7) Cable holder Stand Screws (Depending on model) 3EA, P5 x 25 (See p. A-4) (See p. A-3) Stand Screws 2EA, M4 x 14 (Only 32LN52**) 4EA, M4 x 14 Desk-mount Screw...
Page 22
ASSEMBLING AND PREPARING NOTE y Antenna Isolator Installation Guide - Use this to install TV in a place where there is a voltage difference between TV Set and GND of antenna signal. » If there is a voltage difference between TV Set and GND of antenna signal, the antenna contact might be heated and excessive heat might cause an accident.
ASSEMBLING AND PREPARING Parts and buttons Screen Speakers Remote control sensor Joystick button Power Indicator (* This button is located below the TV screen.) NOTE y You can set the power indicator light to on or off by selecting OPTION in the main menus.
ASSEMBLING AND PREPARING Using the Joystick button You can simply operate the TV functions by pressing or moving the joystick button up, down, left or right. Basic Functions When the TV is turned off, place your finger on the joystick Power On button and press it once and release it.
ASSEMBLING AND PREPARING Lifting and moving the TV y When transporting a large TV, there should be at least 2 people. y When transporting the TV by hand, hold the Please note the following advice to prevent the TV as shown in the following illustration. TV from being scratched or damaged and for safe transportation regardless of its type and size.
ASSEMBLING AND PREPARING Mounting on a table Securing the TV to a wall (This feature is not available for all models.) 1 Lift and tilt the TV into its upright position on a table. - Leave a 10 cm (minimum) space from the wall for proper ventilation.
When you attach the TV to other building wall, it may fall and result in severe injury. materials, please contact qualified personnel. Use an authorized LG wall mount and LG recommends that wall mounting be performed contact the local dealer or qualified by a qualified professional installer.
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching the ends to the label inside the compartment, and close the battery cover.
USING THE USER GUIDE USING THE USER GUIDE User Guide allows you to more easily access the detailed TV information. 1 Press SETTINGS to access the main menus. User Guide OPTION > To set language 2 Press the RED button to access the Customer Support menus.
MAINTENANCE MAINTENANCE Cleaning your TV Clean your TV regularly to keep the best performance and to extend the product lifespan. CAUTION y Make sure to turn the power off and disconnect the power cord and all other cables first. y When the TV is left unattended and unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges.
Turn the TV off/on using the remote control. to the PC (HDMI), y Reconnect the HDMI cable. ‘No signal’ or y Restart the PC with the TV on. ‘Invalid Format’ is displayed. EXTERNAL CONTROL DEVICE SETUP To obtain the external control device setup information, please visit www.lg.com...
Page 33
Manuale Utente TV LED *TV LED LG include uno schermo LCD con retroilluminazione LED. Leggere attentamente il presente manuale prima di utilizzare l’apparecchio e conservarlo come riferimento futuro. www.lg.com...
Page 34
INDICE INDICE LICENZE AVVISO PER IL SOFTWARE OPEN SOURCE ISTRUZIONI DI SICUREZZA MONTAGGIO E PREPARAZIONE Disimballaggio Componenti e pulsanti - Uso del pulsante joystick Sollevamento e spostamento del TV Montaggio su un tavolo Montaggio a parete TELECOMANDO UTILIZZO DEL MANUALE UTENTE MANUTENZIONE Pulizia del televisore...
Page 35
LG Electronics fornisce anche il codice Open Source su CD-ROM a fronte del pagamento di una cifra a copertura dei costi che tale distribuzione comporta (come il costo del supporto, di spedizione e gestione) in seguito a richiesta inviata via e-mail a: opensource@lge.com.
ISTRUZIONI DI SICUREZZA ISTRUZIONI DI SICUREZZA Leggere attentamente queste istruzioni di sicurezza prima di utilizzare il prodotto. AVVISO y Non collocare il televisore e il telecomando nei seguenti ambienti: - In un luogo esposto alla luce diretta del sole - In un luogo dove è presente un elevato livello di umidità, ad esempio in bagno - Vicino a fonti di calore, ad esempio stufe o altri dispositivi che producono calore...
Page 37
ISTRUZIONI DI SICUREZZA y Piegare il cavo dell’antenna tra l’interno e l’esterno dell’edificio per impedire l’ingresso di gocce di pioggia. L’acqua può danneggiare il prodotto e provocare scosse elettriche. y Quando si monta il televisore sulla parete, assicurarsi di non far passare il cavo di alimentazione e quello dell’antenna dietro al televisore.
Page 38
ISTRUZIONI DI SICUREZZA y Evitare impatti d’urto sul prodotto o di far cadere oggetti all’interno del prodotto e sullo schermo. Vi è il rischio di lesioni alle persone o danneggiamenti al prodotto stesso. y Non toccare mai il prodotto o l’antenna durante un temporale. Si potrebbero subire scosse elettriche.
Page 39
ISTRUZIONI DI SICUREZZA y Non installare il prodotto in luoghi quali mensole instabili o superfici inclinate. Evitare inoltre luoghi soggetti a vibrazione o in cui il prodotto non sia sostenuto appieno. In caso contrario il prodotto potrebbe cadere o capovolgersi, con il rischio di lesioni gravi o danneggiamento del prodotto stesso.
Page 40
ISTRUZIONI DI SICUREZZA y Seguire le istruzioni di installazione riportate di seguito per evitare il surriscaldamento del prodotto. - Collocare il prodotto a una distanza minima di 10 cm dalla parete. - Non installare il prodotto in luoghi privi di ventilazione (ad esempio su una mensola o all’interno di un mobile).
Page 41
ISTRUZIONI DI SICUREZZA y A causa del peso dell’apparecchio, si raccomanda di spostarlo o rimuoverlo dal suo imballaggio in due persone. In caso contrario, si possono subire lesioni. y Contattare il centro servizi una volta l’anno per pulire le parti interne del prodotto.
MONTAGGIO E PREPARAZIONE NOTA y Il televisore raffigurato nell’immagine può essere diverso da quello in uso. y Il menu OSD (On Screen Display) del TV potrebbe risultare leggermente diverso da quello mostrato in questo manuale. y I menu e le opzioni disponibili possono essere diversi a seconda della sorgente in ingresso o del modello del prodotto utilizzati.
Page 43
MONTAGGIO E PREPARAZIONE Telecomando e batterie (AAA) Manuale Utente (Vedere pag 18) Adattatore Cavo di alimentazione (Vedere pag A-7) Supporto per cavi Viti del supporto (in base al modello) 3EA, P5 x 25 (Vedere pag A-4) (Vedere pag A-3) Viti del supporto 2EA, M4 x 14 (Solo 32LN52**) Vite per il montaggio...
Page 44
MONTAGGIO E PREPARAZIONE NOTA y Guida all’installazione dell’isolatore di antenna - Utilizzare l’isolatore per installare la TV in un luogo in cui è presente una differenza di tensione tra il set della TV e il GND di segnale dell’antenna. » Se tale differenza di tensione è presente, il contatto dell’antenna potrebbe scaldarsi e l’eccessivo calore potrebbe causare incidenti.
MONTAGGIO E PREPARAZIONE Componenti e pulsanti Schermo Altoparlanti Sensore telecomando Pulsante joystick Indicatore di alimentazione (* Questo pulsante si trova sotto lo schermo del TV). NOTA y È possibile impostare la spia dell’indicatore di alimentazione selezionando OPZIONE nei menu principali.
MONTAGGIO E PREPARAZIONE Uso del pulsante joystick È possibile attivare le funzioni del TV, premendo o spostando il pulsante joystick verso l’alto, verso il basso, a destra o sinistra. Funzioni di base Quando il TV è spento, posizionare il dito sul pulsante Accensione joystick, premere una volta, quindi rilasciare il pulsante.
MONTAGGIO E PREPARAZIONE Sollevamento e spostamento y Per trasportare un televisore di grandi dimensioni occorrono 2 o 3 persone. del TV y Durante il trasporto, tenere il televisore come mostrato nell’illustrazione di seguito. Prima di sollevare o spostare il televisore, leggere le seguenti indicazioni per evitare di graffiare o danneggiare l’apparecchio e per un trasporto sicuro a prescindere dal tipo e dalle dimensioni.
MONTAGGIO E PREPARAZIONE Montaggio su un tavolo Fissaggio della TV alla parete (Funzione non disponibile su tutti i modelli.) 1 Sollevare ed inclinare il televisore in posizione verticale su un tavolo. - Lasciare uno spazio (minimo) di 10 cm dalla parete per assicurare una ventilazione adeguata.
Utilizzare un supporto per montaggio a LG consiglia di far eseguire il montaggio a parete parete autorizzato da LG e contattare da un installatore qualificato esperto. il rivenditore locale o il personale qualificato.
Page 50
TELECOMANDO TELECOMANDO Le descrizioni nel presente manuale si basano sui pulsanti del telecomando. Leggere attentamente il presente manuale e utilizzare correttamente il televisore. Per sostituire le batterie, aprire il coperchio del vano batterie, inserire le batterie (AAA da 1,5 V) rispettando le polarità come indicato dall’etichetta all’interno del vano e chiudere il coperchio.
Page 51
UTILIZZO DEL MANUALE UTENTE UTILIZZO DEL MANUALE UTENTE La guida utente consente di accedere più facilmente a informazioni dettagliate sul televisore. 1 Premere SETTINGS per accedere ai menu Manuale dell’utente OPZIONE > Per impostare la lingua principali. 2 Premere il pulsante ROSSO per accedere ai SETTING ...
MANUTENZIONE MANUTENZIONE Pulizia del televisore Pulire regolarmente il televisore per mantenerne le prestazioni ottimali e per estenderne la durata nel tempo. ATTENZIONE y Make sure to turn the power off and disconnect the power cord and all other cables first. y When the TV is left unattended and unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges.
Riavviare il PC con la TV accesa. viene visualizzato il messaggio “Nessun segnale” o “Formato non valido”. IMPOSTAZIONE DI UN DISPOSITIVO DI CONTROLLO ESTERNO Per informazioni sulla configurazione di un dispositivo di controllo esterno, visitare il sito Web www.lg.com...
75 Ω Impedenza antenna esterna Dichiarazione di conformità La società LG Electronics Italia S.p.A. dichiara che il televisore a colori LG 32LN520B-ZA / 32LN5200-ZA / 32LN5203-ZA / 32LN5204-ZA / 42LN520B-ZA / 42LN5200-ZA / 42LN5203-ZA / 42LN5204-ZA è fabbricato in conformità alle prescrizioni del D.M. n°548 del 28/08/95, pubblicato sulla G.U.
SPECIFICATIONS SPECIFICATIONS Product specifications may be changed without prior notice due to upgrade of product functions. 32LN52** 42LN52** 32LN520B-ZA 42LN520B-ZA MODELS 32LN5200-ZA 42LN5200-ZA 32LN5203-ZA 42LN5203-ZA 32LN5204-ZA 42LN5204-ZA With stand (mm) 738 x 493 x 209 969 x 625 x 234 Dimensions (W x H x D) Without stand(mm)
Page 60
Please contact LG First. If you have any inquiries or comments, please contact LG customer information centre. Customer Information Centre Country Country Service Service 0 810 144 131 0900 543 5454 015 200 255 800 187 40 Record the model number and serial number of...
