  • Page 1

    Installation and Operation Manual GX2-PSAC10D-R Power Supply...

  • Page 2

    CAUTION RISK OF ELECTRIC SHOCK CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Caution These servicing instructions are for use by qualified personnel only. To reduce the risk of electrical shock, do not perform any servicing other than that contained in the Installation and Troubleshooting Instructions unless you are qualified to do so.

  • Page 3

    Motorola, Inc. Motorola reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of Motorola to provide notification of such revision or change. Motorola provides this guide without warranty of any kind, either implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 4: Table Of Contents

    Powering ......................................3-2 Operation ......................................3-2 Fault Reporting....................................3-3 Appendix A Specifications Input Power.......................................A-1 Output Power....................................A-1 Physical Properties..................................A-1 Environmental ....................................A-1 Appendix B Menus Module Status Menu ..................................B-1 Module Info Menu.....................................B-2 Alarms .......................................B-2 Abbreviations and Acronyms GX2-PSAC10D-R Installation and Operation Manual...

  • Page 5

    Figures Figure 1-1 GX2-PSAC10D-R................................1-1 Figure 2-1 GX2-HSG* fully populated .............................2-1 Figure 2-2 GX2-PSAC10D-R front view............................2-2 Figure 2-3 GX2-PSAC10D-R top view ............................2-2 Figure 2-4 GX2-PSAC10D-R rear view ............................2-3 Figure 3-1 GX2-PSAC10D-R................................3-1 Figure 3-2 AC input connector ...............................3-2 Figure 3-3 GX2-PSAC10D-R block diagram ..........................3-2 Tables Table 3-1 LED fault indication ................................3-3...

  • Page 6: Redundancy

    The wide operational bandwidth of the platform enables you to offer more revenue-generating services. This manual describes the GX2-PSAC10D-R power supply that provides power for the equipment shelf (GX2-HSG*) and all application modules. The GX2-PSAC10D-R features include: Regulated +5.1, +12, and +3.7 VDC to the equipment shelf backplane...

  • Page 7: Using This Manual, Related Documentation, Document Conventions

    Appendix A Specifications provides general specifications for the GX2-PSAC10D-R. Appendix B Menus provides the GX2-PSAC10D-R menu structure and information on how to use the optional SDU with display. Abbreviations The Abbreviations and Acronyms list contains the full spelling of the short forms used and Acronyms in this manual.

  • Page 8: If You Need Help

    Motorola Online: The TRC is on call 24 hours a day, 7 days a week. In addition, Motorola Online offers a searchable solutions database, technical documentation, and low-priority issue creation and tracking. For specific toll-free numbers when calling from outside the United States, please refer to your product manual or our Web page.

  • Page 9: Calling For Repairs

    C a l l i n g f o r R e p a i r s If repair is necessary, call Motorola’s Repair Facility at 1-800-227-0450 for a Return for Service Authorization (RSA) number before sending the unit. The RSA number must be prominently displayed on all equipment cartons.

  • Page 10

    G X 2 - H S G * f u l l y p o p u l a t e d The GX2-PSAC10D-R provides +5.1, +12, and +3.7 VDC power to the GX2-HSG* and all application modules. The auto-sensing input-voltage feature recognizes 115 VAC or 230 VAC applications.

  • Page 11: Installation

    2 - 2 O v e r v i e w Figure 2-2 illustrates a front view of the GX2-PSAC10D-R: F i g u r e 2 - 2 G X 2 - P S AC 1 0 D - R f r o n t vi ew...

  • Page 12: Powering, Operation

    The unused compartment on the bottom of the GX2-HSG* can be used for redundant powering with the purchase of a second power supply. For redundancy, it is possible to use two GX2-PSAC10D-R's (as shown in Figure 3-1), two GX2-PSDC10Cs, or any combination of GX2-PS*10* power supplies.

  • Page 13: Unpacking

    U n p a c k i n g Unpack the GX2-PSAC10D-R and inspect it for damage. If damage is visible, set it aside in the original packing material and contact the Motorola Customer Service Department for further instructions.

  • Page 14

    Using the supplied cable, provide power from a source voltage of 105 VAC to 264 VAC to the AC input connector on the rear of the GX2-PSAC10D-R as illustrated in Figure 3-2: F i g u r e 3 - 2...

  • Page 15

    GX2-PSAC10D-R is reported to the GX2-CM100B and is accessible through the GX2-SDU or the Ethernet port on the front panel. Using the GX2-SDU, or a network management system, you can identify the cause of a fault in the GX2-PSAC10D-R. Refer to Appendix B, Menus, for information regarding the SDU menu structure.

  • Page 16: Input Power, Output Power, Physical Properties, Environmental

    S p e c i f i c a t i o n s Specifications for the GX2-PSAC10D-R are valid over the given operating temperature range. Refer to the current Motorola BCS product catalog for additional information not provided in this section. I n p u t P o w e r...

  • Page 17: Module Status Menu

    Using the optional SDU with display to access GX2-PSAC10D-R menus The menu structure Alarms Table B-1 identifies the procedure for navigating through the GX2-PSAC10D-R menus using the optional SDU with display: T a b l e B - 1 G X 2 - P S AC 1 0 D - R m e n u s Scroll to the top-level Press the up or down arrows to scroll to the PS1 or PS2 menu.

  • Page 18: Module Info Menu, Alarms

    B - 2 M e n u s M o d u l e I n f o M e n u ALIAS> User selected (default GX2-POWER SUPPLY) MODEL: GX2-PSAC10D-R S/N: 0123456789ABCDEF DATE CODE: mmddyyyy FW REV: HW REV: A l a r m s...

  • Page 19

    A b b r e v i a t i o n s a n d A c r o n y m s The abbreviations and acronyms list contains the full spelling of the short forms used in this manual: Community Antenna Television CATV decibels...

  • Page 20

    Visit our website at: www.motorola.com 538445-001-a 5/07...
