- Page 1 MRC-2U-UM 3/28/11 8:47 AM Page 1 Operation and Installation Manual MRC-2U Universal Watertight Marine Radio Controller with Speed Indicators...
-
Page 2: Table Of Contents
Clearing All the Aquavibe Marine Remote Controller Codes ....... . -
Page 3: Introduction
MRC-2U-UM 3/28/11 8:47 AM Page 3 Introduction Please carefully read all of the information in this manual. Familiarity with operation and installation proce- dures will help you obtain the best possible performance from your new Marine Radio Controller. Safety Information... -
Page 4: General Operations
MRC-2U-UM 3/28/11 8:47 AM Page 4 General Operations Selecting a Source/Mode: To select a play source, press the SRC button until the desired source/mode is selected. Volume: Increase the volume by pressing the VOL + button. Increase the volume by pressing the VOL - button. -
Page 5: Removing The Remote
MRC-2U-UM 3/28/11 8:47 AM Page 5 Removing the Remote Removing the Remote from Holder: Release Tab Press the release tab and slide out the remote. To reinstall, slide the remote into the holder until it snaps into place. Remote Installation... -
Page 6: Wiring Diagram
MRC-2U-UM 3/28/11 8:47 AM Page 6 Wiring Diagram Antenna Wire Do Not Cut or Connect Note: Receiver’s housing is not waterproof and must be mounted in a dry location. Red Wire +12 Volt Switch Black Wire Ground Infrared Emitter Attach to radio’s infrared receiver. -
Page 7: Learning The Radio's Remote Code
MRC-2U-UM 3/28/11 8:47 AM Page 7 Learning the Radio’s Remote Code First, see if your radio is in the Manufacturer’s Code Look-Up Table below. If your radio is listed in the table go to “Automatic Code Learning”. If you can not find your radio in the list go to “Manual Code Learning”. - Page 8 MRC-2U-UM 3/28/11 8:47 AM Page 8 Automatic Code Learning (continued) Step 5 Step 6 5 Times Try each button on the remote to make sure each To exit programming push the switch on/off 5 times button has been learned properly. If the remote or wait 15 seconds and the system will automatical- does not function properly proceed to “Manual...
- Page 9 MRC-2U-UM 3/28/11 8:47 AM Page 9 Manual Code Learning (continued) Step 4 Flashes 2 Times Using the RF Marine Remote press the corre- The LED will flash 2 times indicating the “VOL- sponding “VOLUME UP” button to assign this UME UP” button of the radio remote has been function.
-
Page 10: Learning An Additional Aquavibe Marine Remote Controller Code
8:47 AM Page 10 Learning an Additional Aquavibe Marine Remote Controller Code The Aquavibe Marine Remote Controller is already pre-programmed to the receiver. No programming is necessary. If you want to program additional Aquavibe Marine Remote Controllers follow the instructions below. -
Page 11: Clearing All The Aquavibe Marine Remote Controller Codes
MRC-2U-UM 3/28/11 8:47 AM Page 11 Clearing All the Aquavibe Marine Remote Controller Codes Step 1 Step 2 Solid LED Hold Turn on the power to the receiver’s Press and hold the button on the receiver until the LED turns housing. -
Page 12: Warranty
Defective merchandise should be returned to the original point of purchase or secondly, to Magnadyne Corporation, 1111 W. Victoria Street, Compton CA 90220. Return Authorization must be obtained before sending, or merchandise may be refused. MRC-2U-IM/UM Rev. A © Copyright 2008 4-28-08...
