INSTRUCTION MANUAL
IMPORTANT INFORMATION: Please read these instructions care-
GB
fully and make sure you understand them before using this unit.
Retain these instructions for future reference.
BETRIEBSANWEISUNG
WICHTIGE INFORMATION:
Lesen Sie diese Hinweise zur Handha-bung des Geräts aufmerk-
DE
sam durch. Verwenden Sie es erst, wenn Sie sicher sind, daß Sie
alle Anweisungen verstanden haben und gut aufbewahren.
MANUEL D'INSTRUCTIONS
RENSEIGNEMENTS
IMPORTANTS: Avant d'utiliser cet appareil, veuillez lire aten-
FR
tivement les instructions et assurez-vous de les avoir com-
prises. Conservez les instructions pour référence ultérieure.
HANDLEIDING
BELANGRIJKE IMPORTANTS: Lees deze handleiding aan-
NL
dachtig en zorg dat u ailes begrijpt alvorens de kettingzaag te
gebrulken en be-waar ze voor toekomstige raadpleging.
BRUKERHÅNDBOK
VIKTIG INFORMASJON: Les disse anvisningene nøye
NO
og forsikre deg om at du forstår dem før du bruker
enheten og oppbevar dem for sen-ere bruk.
OHJEKIRJA
TÄRKEÄÄ TIETOA: Lue nämä ohjeet huolellisesti ja
FI
varmista, että olet ymmärtänyt ne, ennen kuin alat käyttää
tätä laitetta ja säilytä myöhempää tarvetta varten.
BRUKSANVISNING
VIKTIG INFORMATION: Läs instruktionerna noggrant och
SE
försäkra dig om att du förstår dem innan du använder
utrustningen och spara dem för framtida behov.
BRUGERHÅNDBOG
VIGTIGE OPLYSNINGER: Læs instruktionerne
DK
omhyggeligt, før du bruger enheden og gemme til senere
henvisning.
MANUAL DE INSTRUCCIONES
INFORMACIÓN IMPORTANTE: Lea atentamente las instruc-
ES
ciones y asegúrese de entenderlas antes de utilizar esta apara-
to. Conserve las instrucciones para la referencia en el futuro.
MANUAL DO OPERADOR
INFORMAÇÕES IMPORTANTES: Queira ler cuidadosa-
PT
mente estas instruções e tenha certeza de entendë las
antes de usar a serra e guarde para consulta futura.
LIBRETTO D'ISTRUZIONI
INFORMAZIONI IMPORTANTI: Leggere le istruzioni
IT
attentamente e capirle bene prima di usare l'utensile.
Conservare per ulteriore consultazione.
HASZNÁLATI ÚTMUTATÓ
Jótállást vállalni csak rendeltetésszerüen használatba vett
HU
gépekre tudunk. Kérj ü hogy a gép használatba vétele elött
gondosan olvassa el a kezelési utasításokat.
EΓXEIPI∆IO XEIPIΣMOE
ΣHMANTIKEΣ
ΠΛHPOΦOPIEΣ: ∆ιαβάστε πρoσεxτιxά αvτές τις οδηγίες
GR
xαι Φρovτίστε vα τις xαταvoήσετε αvτ τo µηχάvηµα xαι
Φuλάξτε το για vα το σuµβοuλεύεστε στο µέλλοv.
CZ
INSTRUKCJA OBS≥UGI
Gwarancja traci waΩnoß∫ w przypadku uΩywania
PL
urzådzenia do celów innych niΩ wymienione w instrukcji
obs≤ugi. Prosimy o uwaΩne przeczytanie instrukcji oraz o
stoowanie si™ do zalece~ i wskazówek w niej zawartych.
NÁVOD NA OBSLUHU
Dôleæitá informácia: Pred
pouæitím stroja si starostlivo preËítajte tento návod na
SK
obsluhu a uistite sa æe ste mu dôkladne porozumeli.
Návod starostlivo uschovajte pre potrebu v budúcnosti.
ИНCTPYKЦИИ
BAЖHЫE CBEДEHИЯ:
RU
Bнимaтeльнo пpoчитать инстрyкции и хрoщo их
пoнять, пepeд тeм как пoльзoвaтьcя блoкoм.
Хpaнить инcтpyкции для дaльнейшиx кoнcyльтаций.
KASUTUSJUHEND
TÂHTIS INFORMATSIOON: Lugege
EE
kasutusjuhend enne seadme kasutamist kindlasti põhjalikult
läbi ning veenduge, et olete kõigest täpselt aru saanud.
LV

Advertisement

Table of Contents
loading

Summary of Contents for Husqvarna 953900767

  • Page 1 Husqvarna Outdoor Products Italia SpA Via Como, 72 23868 Valmadrera LC ITALIA Phone + 39 0341 203111 - Fax + 39 0341 581671 PN 249958 REV. 00 (10/06) INSTRUCTION MANUAL LIBRETTO D’ISTRUZIONI IMPORTANT INFORMATION: Please read these instructions care- INFORMAZIONI IMPORTANTI: Leggere le istruzioni fully and make sure you understand them before using this unit.
  • Page 2 22 3 2 Strokes engine totally Partner oil synthetic oil or McCulloch oil 50:1 40:1 2,5% 1 ltr 20 cm 1 ltr 25 cm...
  • Page 3 40-43-46-49cc 52cc 52 cc 40-43-46-49 cc 43/46/49/52 cc 0,095” 197” 5000mm 2.4mm 538249344 538248960 9” 531024905 230 mm 538248960 10” 531024902 255 mm 538248960 9” 531024906 230 mm 538248960 10” 531024903 255 mm 538248960 9” 538040998 230 mm 538242475 538240553 9”...
  • Page 4 1) ENGINE 2) SHAFT 3) THROTTLE TRIGGER 4) REAR CONTROL GRIP 5) BLADE 6) NYLON STRING HEAD 7) STOP SWITCH 8) FUEL ENRICHMENT LEVER 9) STARTER HANDLE 10) HARNESS RING 11) SPARK PLUG 12) AIR FILTER COVER 13) FUEL TANK CAP 14) MUFFLER SHIELD 15) FLEXIBLE SHAFT 16) DELTA HANDLE...
  • Page 5 • If you have never used a brush cutter before, practice using it for a while before actually starting to work with it.
  • Page 6 • possible contact with flying debris. Never use a brush cutter without its safety pole guard correctly in place. Only use blades or nylon string heads clearly marked with a maximum speed of at least 10,500 min Use only original or approved accessories and spare parts, which you can purchase from our official distributors.
  • Page 7 Stand in a stable position on your feet. Keep the grips clean and dry. Do not use the brush cutter while standing on a ladder or other unstable support. You should always be able to control your balance. Never...
  • Page 8: Fuel Mixture

    Shaft fastener 1 2 3 4 12 Use the shaft fastener every time you start the machine, fastening the connector to the supporting device. This way, the shaft will be held in place while your hands are busy with the starting procedure.
  • Page 9 Never store the engine with fuel in the tank in a poorly ventilated place where the fumes produced by the gasoline could propagate and reach a fire, E1. Setting the motor on the frame Position the motor so that the fuel cap faces upward and the bracket for fastening it to the frame is on one side.
  • Page 10: Starting And Stopping The Engine

    Lower washer - e) Spacer - f) Rotating mower gauge - g) Blade locking screw (length mm 34,5). Assembly of sawtooth blade and blade guard 2 3 4 10 When using the sawtooth blade, remove the guard for the line cutter head and grass cutting blade and replace the flange guard (A) with the sawtooth blade guard (H).
  • Page 11: Routine Maintenance

    1 2 3 4 7 9 10 After every use In order to avoid overheating the motor, remove any dust and dirt from the slots on the cylinder cover and finds of the cylinder using a wooden scraper. Clean the backpack (if you wish, you can wash the padding after removing it from the frame).
  • Page 12: Environmental Information

    Drawing out the string During cutting, the nylon string wears naturally causing an increase in the speed of the engine and a reduced cutting capacity. When this happens, to bring out more string bump the head against the ground: release the throttle trigger to reduce the engine speed to less than 8000 rpm.
  • Page 13 The undersigned, authorized by Husqvarna Outdoor Products Italia SpA, declares that the following prod- ucts model /TYPE: BC011, BC012 starting from the serial numbers produced from 2006 on, manufac- tured by Husqvarna Outdoor Products Italia SpA, Valmadrera, Italia, comply with European Directive: 98/37/EEC (Machine Directive), 93/68/EEC (EEC Marking Directive) &...

This manual is also suitable for:

953900768953900791Elite 2.010 bp
