- Page 1 Instruction Manual SMG303(BK/P/BL) Portable CD + Graphics Karaoke Center Please read before first using this unit. THE SINGING MACHINE® is a registered trademark of The Singing Machine Co., Inc.
-
Page 2: Important Safety Information
SMG303-v4_Layout 1 5/6/14 5:58 PM Page 1 WARNINGS Important Safety Information WARNING: TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. 1. Read these Instructions. CAUTION 2. Keep these Instructions. 3. Heed all Warnings. -
Page 3: Control Locations
SMG303-v4_Layout 1 5/6/14 5:58 PM Page 2 CONTROL LOCATIONS FRONT VIEW LED DISPLAY AND INDICATORS ON/OFF LED PROGRAM LED PLAY/PAUSE LED REPEAT LED CDG LED STOP button PLAY/PAUSE button REPEAT button ON/OFF button Auto Voice control SKIP button ON/OFF button... -
Page 4: Rear View
SMG303-v4_Layout 1 5/6/14 5:58 PM Page 3 CONTROL LOCATIONS REAR VIEW Handle INSTALLATION OF BATTERIES Battery Door DC OPERATION 1. Slide the battery door in the direction of the arrow to reveal the battery compartment. Insert eight (8) “C” size alkaline batteries (not included) as indicated on the diagram. -
Page 5: Making The Connections
CONNECTING TO YOUR TV Your Singing Machine is designed to connect to your TV the same way you would connect most video cameras, DVD players or video game consoles. Please follow the steps below to display lyrics on the TV screen: 1. -
Page 6: Operation
LOADING A DISC Open the CD door, place a disc in the compartment and gently close the CD door.The LED on your Singing Machine will display the number of tracks recorded on your disc. In the event a CD is not placed in the compartment, the Display will show “NO”. -
Page 7: Mic Volume
OPERATION REPEAT To repeat the track currently playing, press the REPEAT button once; the REPEAT LED will flash. To repeat all tracks, press the REPEAT button twice; the REPEAT LED will light up and stay lit. Press the PLAY/PAUSE button to begin. To clear the repeat function, press the REPEAT button again;... -
Page 8: Troubleshooting Guide
SMG303-v4_Layout 1 5/6/14 5:58 PM Page 7 TROUBLESHOOTING GUIDE If you have followed the instructions and are having difficulty operating the unit, locate the PROBLEM in the left column below. Check the corresponding POSSIBLE CAUSE and SOLUTION columns to locate and remedy the problem. - Page 9 SMG303-v4_Layout 1 5/6/14 5:58 PM Page 8 TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Lyrics do not appear on Video cable is not connected Follow direction in the “MAKING THE the TV screen. properly to the TV. CONNECTIONS” section. TV does not have video line input.
-
Page 10: Specifications
SMG303-v4_Layout 1 5/6/14 5:58 PM Page 9 SPECIFICATIONS AUDIO SECTION OUTPUT POWER (MAXIMUM) ................1 Watt + 1 Watt (RMS) OUTPUT IMPEDANCE.........................8 Ohms CD PLAYER SECTION FREQUENCY RESPONSE .....................100Hz - 20kHz SIGNAL-TO-NOISE RATIO....................50dB (A-WTD) NUMBER OF PROGRAMS............20 Step Random Access Programming SAMPLING SYSTEM ....................8 Times Over Sampling... - Page 11 303-1405-ENG04 The Singing Machine Company, Inc. 6301 NW 5th Way, Suite 2900, Fort Lauderdale, FL 33309, USA © 2014 PRINTED IN CHINA Visit Our Website: www.singingmachine.com...
