Syscom Video HD SDI DVR User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HD SDI DVR
USER'S MANUAL
RoHS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD SDI DVR and is the answer not in the manual?

Questions and answers

Related Manuals for Syscom Video HD SDI DVR

Summary of Contents for Syscom Video HD SDI DVR

  • Page 1 HD SDI DVR USER’S MANUAL RoHS...

  • Page 3: Fcc Compliance Statement

    FCC COMPLIANCE STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 4 - 3 -...
  • Page 5 1080P resolution both in live and playback. Unlike megapixel IP cameras and NVR, it doesn’t require IP related expertise and can be installed under coaxial cabling. HD SDI DVR with H.264 compression HD video over coaxial cable : No latency & no loss of frame...

  • Page 6: Table Of Contents

    CONTENTS 1. Product Overview 1.1 Packing Contents ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 1.2 Front ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 1.3 Rear ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 2. Installing Product 2.1 Installing HDD ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 2.2 Connecting Camera and Audio Device ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 2.3 Connecting Monitor ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 2.4 Connecting Optional Device ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 2.5 Connecting Network ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙...
  • Page 7 5.2.4 Event ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5.2.5 Storage ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5.2.6 Network ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5.2.7 System ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5.3 Search ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5.3.1 Search by Time ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5.3.2 Search by Event ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5.3.3 Thumbnail Search ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5.3.4 Backup ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5.3.3 Search mode ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5.4 Other function ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5.4.1 PTZ ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙...

  • Page 8: Product Overview

    1. Product Overview - 7 -...

  • Page 9: Packing Contents

    1.1 Packing Contents When you first open the product, please check out whether there are all contents as follows. If any of these items is missing or damaged, contact your supplier immediately before using the product. DVR product Remote control & Battery Power adaptor and cable Software CD USB mouse...

  • Page 10: Front

    1.2 Front Number Name Function USB port Connect USB device (mouse or USB stick/HDD) PWR : Light on when power is on LED indicator REC : Light on when DVR is recording NET : Light on when a user is connected via network Mode Change screen split mode Menu...

  • Page 11: Rear

    1.3 REAR – 4channel Number Name Function DC 12V Connect power adaptor provided with the product SENSOR Sensor input port ALARM Alarm output port RS-485 PTZ camera control by RS-485 communication AUDIO IN/OUT Connect audio in or out device (such microphone or speaker) VIDEO OUT Composite video out (BNC type) VGA output...
  • Page 12 1.3 REAR – 8 channel Number Name Function DC 12V Connect power adaptor provided with the product SENSOR Sensor input port ALARM Alarm output port RS-485 PTZ camera control by RS-485 communication AUDIO IN/OUT Connect audio in or out device (such microphone or speaker) VIDEO OUT Composite video out (BNC type) VGA output...

  • Page 13: Installing Product

    2. Installing Product HD SDI 4ch DVR SYSTEM CONFIGURATION - 12 -...

  • Page 14: Installing Hdd

    2.1. Installing HDD 1 internal HDD can be installed inside the product. If HDD was not installed in the product, please install HDD first as follows. Be careful not to be harmed by sharp edges of the product. (1) Loosen screws on both sides and back to (2) Lift the end of top cover and pull out from detach the product cover.

  • Page 15: Connecting Camera And Audio Device

    2.2. Connecting camera and audio device Connect coaxial cable (BNC type) into VIDEO IN port on rear of the product. HD SDI cabling specification: SMPTE 292M standard, 5C-HFBT or above Connect RCA cable from microphone into AUDIO IN port on rear of the product. Connect RCA cable into AUDIO OUT port on rear of the product and into audio device.

  • Page 16: Connecting Optional Device

    2.4. Connecting Optional device You can connect and control the PTZ device supporting RS-485 communication. 2.5. Connecting Network Connect LAN cable (RJ45) to Ethernet port on rear of the product. LAN cable (RJ45) 2.6. Connecting power supply Connect provided power cable to AC-DC adaptor. Connect the adaptor to DC power port on rear of the product.

  • Page 17: Controlling Dvr

    3.Controlling DVR 3.1. Remote control – Basic description 1) REC : Instant record button 2) DVR ID 3) Number button : Input channel number 4) AUDIO : Audio ON / Mute 5) BACKUP : Access directly to backup menu 6) MENU : Access to main menu 7) OSD : Show or Hide OSD 8) PTZ : Control Pan/Tilt/Zoom camera.

  • Page 18: Remote Control - Additional Description

    3.2. Remote control – Additional descriptions 3.2.1. Full screen mode - Press button. Whenever pressing button, screen will go to next screen. - Press desired numeric button of remote controller. 3.2.2. Quad screen mode - To see quad screen mode, press button.

  • Page 19: Mouse

    3.2.5. Digital-ZOOM DVR supports up to 10 times (x10) digital zoom Select ZOOM icon or ZOOM button on remote control Using mouse, drag certain area to enlarge image To disable to digital zoom mode, mouse right-click Normal mode Digital zoom mode x10 3.3.

  • Page 20: Operation

    4. Operation - 19 -...

  • Page 21: Turning On

    PLEASE MAKE SURE THAT THE HDD MUST BE INSTALLED AT FIRST FOR RECORDING BEFORE USING DVR. 4.1. Turning on Connect Power Adaptor provided with the product into power DC terminal. 4.2. Initial screen Log-in window will pop up after booting is over. Please move the pointer into password window with mouse or up/down key of remote controller, and then press enter button in remote control or right button of mouse.
  • Page 22 4.3.1. Icons in Live Display Mode In Live display mode, icons will be indicated to notify the system mode or status. Below are the icon categories, which are indicated on the monitor. Icon for system Icon for each channel Selects specific 1ch with full screen When Motion Detected Screen-Division mode When Sensor Activated...
  • Page 23 4.3.2. Controlling playback using the buttons In search mode, the status will be shown in the upper side of screen. You can control playback using the buttons. This icon shows the current status in playback. If you select ▶, the mark will be ▶, Current status The mark will be changed if you select another button Ex) If you select FF (fast-forward), ▶▶...

  • Page 24: Menu

    5. MENU 5.1. Access to menu Press MENU button on front keys/remote control or right-click using mouse. Before access to main menu, DVR asks you login ID and password. When you first start DVR, input ADMIN for ID and 0000 for password as Initial ID & password are ADMIN & 0000 respectively.

  • Page 25: Display

    5.2.1. DISPLAY Configurations related to OSD can be made in OSD menu. Sequence patterns of main and spot monitors can be programmed in LIVE-SEQ menu. 5.2.1.1. OSD Select OSD items that displays on monitor and select language. CAMERA NAME - Show camera name on screen. CAMERA NUMBER –...

  • Page 26: Camera

    5.2.1.3. SEQ-QUAD (Only for 8ch DVR) SEQ: DVR supports 2 sets of quad split sequence. SEQ 1 is CH1~CH4 and SEQ is CH5~CH8. Sequence time can be set by second and maximum time is 99 second. 5.2. 2. CAMERA General camera configurations such as camera name, color and covert can be made. Private zone on certain cameras can be designated.
  • Page 27 How to input letters or numbers on TEXT INPUT box Move the pointer to the name box (Blank) and click. Click letters or numbers with direction button. Click OK button after you complete input. 5.2.2.2. PTZ ID: Input ID of connected PTZ camera PROTOCOL: Select protocol type of PTZ camera BAUD: Select baud rate of PTZ camera This information can be found in manual of PTZ...

  • Page 28: Record

     NOTE: Before using this function, please make sure that camera supports preset. Total 64 preset points can be saved to each channel. You can enter position name to each saved preset position. 5.2.2.4. TOUR CAMERA: Select camera to set up scan point LIST: Create another SCAN list PRESET: Select desired preset potion CLEAR ALL: Cancel all saved scan points...
  • Page 29 5.2.3.1. PARAMETER Recording resolution CAMERA INPUT RESOLUTION 720P 1280 X 720 1080P 1920 X 1080 Resolution -Recording resolution is determined automatically by HD SDI camera input and cannot be changed. EVENT - Select the recording picture quality and frame rate for EVENT occasions. - Event occasions mean when motion is detected or alarm is triggered.
  • Page 30 REC OFF: No record, just monitor during selected hours. CONTINUOUS REC: DVR records continuously during selected days and hours. EVENT REC: DVR records only when Motion/Sensor/Video Loss is triggered during selected hours. CONTINUOUS + EVENT REC: DVR records continuously or by events during selected days and hours. If there is no event, it will record video as continuous mode and If there is event, it will record video as event mode as you set.

  • Page 31: Event

    5.2.4. EVENT Configurations regarding events can be made. 5.2. 4.1. MOTION CAMERA: Select camera for motion setup SENSITIVITY: Adjust motion sensitivity from 0~9 The higher number, the more sensitive detection ALARM-OUT: Check alarm-out 1 if you wish to trigger alarm out 1 when motion is detected. RECORD CH: Select channels which will record when motion is detected.
  • Page 32 5.2.4.2. SENSOR TYPE: Select NO(Normal open)/NC(Normal close) RECORD: Select camera channels which will record when sensor is activated. ALARM-OUT: Check alarm-out 1 if you wish to trigger alarm out 1 when sensor is activated. BUZZER: Set ON/OFF for buzzer when sensor is activated.
  • Page 33  NOTE: You can find SMTP server information usually from POP3/SMTP, IMAP/SMTP setup menu of the server. Otherwise, you need to ask the server manager.  EXAMPLE: If you have an account in Gmail, Input smtp.gmail.com in SERVER NAME and ID/PASSWORD of your Gmail account.
  • Page 34 E-Mail schedule: Select day & hour (Mouse drag/drop) Alarm-out schedule: Select day & hour (Mouse drag/drop) FTP schedule: Select day & hour (Mouse drag/drop) 5.2.4.7. MISC DWELL TIME: Dwelling time for alarm-out Maximum 9999 seconds. ALARM OUT: Select N/C or N/O. To deactivate, click ALARM OUT EVENT POPUP: Channel where event occurs pops up in full screen mode.

  • Page 35: Storage

    5.2.5. STORAGE 1 internal hard drives can be installed in the unit. Additionally 1 E-SATA hard drive can be attached to the unit using E-SATA port in the rear. 5.2.5.1. HDD FORMAT HDD must be formatted when installed in order to record properly. New HDD must be formatted before using it with DVR When format is completed, DVR will reboot automatically.
  • Page 36 Select ON in SMART TEMPERATURE THRESHOLD Set the limit temperature of HDD INSPECTION CYCLE Set the interval to check HDD temperature Options: Every 10 minutes, Hourly and Daily DAILY TIME In case you select “Daily” in inspection cycle, set time to check HDD temperature during a day. ALARM OUT Select alarm out ports which will activate when HDD temperature exceeds over set temperature...

  • Page 37: Network

    5.2.6. NETWORK 5.2.6.1. SETUP TYPE: Select network type among STATIC, DHCP and ADSL(PPPOE) DHCP: DVR automatically gets IP address, gateway and subnet mask. STATIC: Check your network environment and input IP address, gateway and subnet mask manually. ADSL: Input PPPOE ID and PASSWORD. MOBILE PORT: Port that is used for jpeg transfer Smart phone application uses this port.
  • Page 38 5.2.6.2. STREAM When dual stream is activated, DVR sends separate network stream of resolution, picture quality and frame rate. When dual streaming is set OFF, DVR should send stream according to resolution, picture quality and frame rate set in recording parameter. According to HD SDI video input resolution (1080P or 720P), 1080P supports 960*540 &...
  • Page 39  NOTE: To use DDNS function, you must first go to www.ddnscctv.com, www.dyndns.com www.no-ip.com on PC and create an account and make a domain (host) name.  NOTE: If DDNS connection fails, check if all information has been input correctly (especially USER ID and PASSWORD) and check network status.
  • Page 40  DDNS setup on DVR ① Move to SETUP  NETWORK  DDNS ② Select DDNSCCTV.COM (3 options : DDNSCCTV.COM, NO-IP.COM, DYNDNS.COM) ③ Input E-mail address & password you registered at http://ddnscctv.com on USER ID and PASSWORD. ④ Input domain name you registered at http://ddnscctv.com on HOSTNAME.

  • Page 41: System

    5.2.7. SYSTEM Configurations for time, user and etc. can be made. Software version can be checked and upgrade process can be made. 5.2.7.1. CONFIG System setting values from one DVR can be copied to others. Insert USB device into USB port of DVR to import (load) or export (save) the setting values. CONFIG IMPORT &...
  • Page 42 SERVER IP: Input IP or domain name of time server. Click TEST if connection with time server is OK. DVR checks time server for correct time every 1 hour.  Example: time.bora.net (OK), http://time.bora.net (NOT OK) CHANGE TIME: Change time manually 5.2.7.3.
  • Page 43 R : 01 Not working Active ID : 02 Working R : 02 R : 03 Not working 5.2.7.4. USER There are 2 fixed users, ADMIN & NETUSER. Their name & access authority cannot be changed. Additionally, you can create up to 20 more users and give different access authority level to each user. USER –...
  • Page 44 5.2.7.5. UPGRADE You can check version information of software and firmware upgrade can be done. USB upgrade: Upgrade using USB device Network upgrade: Upgrade via network  USB UPGRADE Please select USB upgrade in upgrade window ① Copy provided firmware file to your USB memory stick ②...

  • Page 45: Search

    5.2.7.6. TURN OFF DVR Select TURN OFF DVR and software of DVR will be shutdown. In order to completely shut down DVR, turn off the power switch in the rear. 5.3. SEARCH Time search using calendar/time bar and event search using event logs are supported. - 44 -...

  • Page 46: Search By Time

    5.3.1. SEARCH BY TIME Select date on calendar Select hour & minute on time bar Data on minutes is displayed by ALL and each channel Click “PREVIEW” button after selecting minute and channel no. on then playback of that channel starts on the small window.

  • Page 47: Backup

    CH: Select channel number to view. TIME: Select time to start “Thumbnail search” INTERVAL: Select time interval from 1 sec, 10sec to 1 minute & 1 hour. VIEW: Capture image by selected interval starting from selected time shows up If 1 hour is selected, each screen shows by 1 hour of the same channel.

  • Page 48: Search Mode

    *Bookmark Backup You are able to make a backup file bookmarked in playback mode by clicking “Backup icon” or delete from the list. 5.3.5. SEARCH MODE When DVR is in search mode, you can play, pause, rewind & fast-forward (x2, x4, x8, x32 and x128) If you move mouse cursor at the bottom of screen, time bar pops up and you can drag and move the time in the bar.

  • Page 49: Other Function

    5.4. Other functions 5.4.1. PTZ When you press button of remote control or select PTZ in main menu, screen will be changed to FULL screen mode and you can control PTZ camera. Select another channel on the PTZ control menu or press numeric button of remote control then target camera will be changed.

  • Page 50: Audio

     NOTE: OSD Control function supports only for “PELCO-D” protocol 5.4.2. Audio Before using this function, make sure audio in/out device has been installed correctly. Audio out works only in 1CH full screen mode Test audio by TEST ON/OFF button 5.4.3.

  • Page 51: Osd Off

    5.5. OSD OFF Select OSD OFF then OSD (icons or time) will disappear/appear. Please see the page 22 to get more information. [SETUP->DISPLAY->OSD] 5.6. REC Select REC button on main menu, on remote control or on front panel. Then, all channels will record regardless of previous recording schedule setup.

  • Page 52: Specification

    Specification MODEL HD SDI 4CH DVR HD SDI 8CH DVR Compression Algorithm Video : H.264, Audio : G726 Operating System Embedded Linux Multi-Operation Pentaplex (Live, Recording, Playback, Backup, Network) Input Video Input Signal HD SDI HDMI Video Out Composite Input Audio Output 1 (HDMI, RCA)

  • Page 53: Trouble Shooting

    Trouble shooting In the event of a product malfunction, please check the following list for a usual and possible solution before requesting service. 1. Product is not turned on. Check out whether the power is being supplied well. 2. Product continues displaying “Loading” or “Starting UI….” Check the product can boot without HDD If product continues displaying “Loading”...
