Engine compartment main fuse panel

Description Fuse rating
ALT 150A
BATT 1 50A
BATT 2 30A
BATT 3/RAD FAN 40A
IGN 1 40A
IGN 2 40A
ECU MAIN 30A/20A
FRT HTR 40A
RR HTD 40A
RR HTR 40A
ABS 1 40A
ABS 2 40A
C/FAN 30A
F/FILTER 30A
ECU/TCU 10A
HORN 10A
BURNER 20A
F/PUMP 15A
ALT 10A
H/LP HI 15A
A/CON 10A
FRT DEICER 15A
TAIL LH 10A
Fuse(A/CON, FRT DEICER), Fusible link(FRT HTR, RR HTR, RR HTD, C/FAN, F/FILTER, ABS 1/2),
Generator, E/R fuse & relay box RH
Fuse(DR LOCK, FRT FOG LP , B/ALARM, Power connector(AUDIO-1, ROOM LP))
Fuse(FUEL LID, P/WDW LH/RH, HAZARD), Multipurpose check connector
Fuse(STOP LP , BWS), Radiator fan relay(G4KC)
Ignition switch(ACC, IG1)
Ignition switch(IG2, START), Start relay
Engine control relay
Front blower relay
Rear defogger relay
Rear blower relay
ABS control module(G4KC)
ABS control module(G4KC)
Condenser fan relay 1
Fuel filter heater relay(DIESEL)
TCM, ECM (Gasoline)
Horn relay
Fuel fired heater control module(D4CB)
Fuel pump relay(G4KC)
Generator(D4BH)
Head lamp(HIGH) relay, Head lamp(LOW) relay
A/C relay
Windshield defogger relay (if equipped)
Head lamp LH(Position lamp), Rear combi lamp LH, License lamp LH
Protected component
