Summary of Contents for Badger Meter 345WT
- Page 1 Installation & ® Badger Wireless Modbus/Pulse Model 345WT Transceiver Operation Manual 941700-0017 BadgerMeter, Inc. 10-08...
- Page 2 Step 2 - Mount the Model 345WT on the wall or other ap- sensors. Make sure to obtain the pulse output scale, propriate location. or multiplier for each device you will be using.
- Page 3 Signal Strength Test The sum of the value of the switches is the address. In the When the Model 345WT is operating, the Test button can be example to the right, address 52 is set by placing switch 4, 16 used to report the signal strength received by the Model 345WT and 32 to the on position.
- Page 4 On Modbus systems that do not allow you to read 32 bit values, you can calculate the pulse count as follows: Step 4: Power up the Model 345WT. The Green Alive LED should light up and stay on solid.
