Thank you for choosing this high quality camera, before attempting to
connect or operate this product, please read these instructions completely
DIGITAL COLOR VIDEO CAMERA
ON-SCREEN-DISPLAY
OPERATING MANUAL
WARNING
:
TO REDUCETHE RISK OF FIRE OR ELECTRONIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE AND DO NOT REMOVE COVER OR BACK.
CAUTION
:
1.CONNECT 24VAC UL LISTED CLASS 2 POWER SUPPLY.
2.INSTALL THE CAMERA UNDER UNSTABLE LIGHT SOURCE
MAY CAUSE THE ABNORMAL FUNCTION.
3.ONLY USE CAMERA UNDER CONDITIONS WHERE
TWMPERATURES ARE BETWEEN
FIELS INSTALLATION MARKING:
THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED
SERVICE PERSON AND SHOULD CONFORM TO ALL LACAL
CODES
HIGH RESOLUTION
AC24V12VDC Model
AC85 〜 265V
-10°C to 50°C.
P02-KL-007-C
Advertisement
Table of Contents
Related Manuals for oxic AC24V12VDC
Summary of Contents for oxic AC24V12VDC
- Page 1 Thank you for choosing this high quality camera, before attempting to connect or operate this product, please read these instructions completely DIGITAL COLOR VIDEO CAMERA ON-SCREEN-DISPLAY HIGH RESOLUTION AC24V12VDC Model AC85 〜 265V OPERATING MANUAL WARNING TO REDUCETHE RISK OF FIRE OR ELECTRONIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE AND DO NOT REMOVE COVER OR BACK.
- Page 2 1. General This a color CCD video camera employs a 1/3 inch charge coupled device solid-state imaging device with 470/410 k or 310/270k picture elements, This unit is equipped with a newly developed DSP (Digital Signal Processor) for processing the video signal. This superior and high sensitive series ensure to meet any strike 24 hours’...
- Page 3 3. Name of Parts and Functions DC12V/AC24 MODEL AC 85V ~ 265V AC 85V ~ 265V AC 85V ~ 265V 2P-PLUG MODEL AC CORD MODEL 3P-PLUG MODEL -3 -...
- Page 4 C (CS) mount adapter if a CS mount lens is to be used, remove the C mount ring Holder screw hole Standard photographic pan-head screw size (1/4” – 20) Flange focal lock screw Flange focal lock screw Thumbwheel locking screw and provided screwdriver Back focus thumbwheel...
- Page 5 4. USER OSD SETTING SETTING SWITCHES AND FUNCTIONS 1.UP Button-This button is used to move the cursor upwards. Use this button to select item. 2.LEFT Button –This button is used to move the cursor left. Use to select or adjust the parameters of the selected item.
-
Page 6: Setting Menu And Functions
5. SETTING MENU AND FUNCTIONS SETUP MENU 1. Press the ENTER key to enter main CAMERA ID menu. LIGHT CNTL WHITE BAL 2. Press UP/DOWN key to select the D/N CNTL item for adjusting. PICTURE VIDEO DISPLAY COLOR POS 3. Press the ENTER key to enter the OPD WINDOW sub menu of selected item. -
Page 7: Auto Exposure Mode
Repeat the step above until all characters are input or edited. Move the cursor to ← → to edit a specific character in editing data area. Move the cursor to BLANK (between “z” and “ ”) character position then press enter to erase the character Move the cursor to POSI, then press ENTER, the camera id will display on screen, move the camera... - Page 8 6.2.1. BLC setting LEFT/RIGHT key to turn Back Light Compensation function ON/OFF Press ENTER key to display BLC sub menu HIST BLC—ON/OFF The HIST BLC (histogram) is good for BLC SETUP MENU when the subject has only a slightly HIST BLC BLC LEVEL darker luminance and moving around WINDOWS BLC...
- Page 9 6.2.2. Av:Pk setting (for all AE mode) AES MENU Adjust the Av:Pk value by press the LEFT or Av:Pk RIGHT key. AGCMAX 36 dB RESPONSE Greater Av. value for average photometric AGCMIN 01 dB method, the electronic convergence is SHUTLIM 1/100000 automatically adjusted with the average video RETURN...
-
Page 10: White Balance
1/500, 1/1000, 1/2000, 1/5000, 1/10000, 1/20000, 1/50000, 1/100000 AUTO IRIS-SHUT MENU 6.2.6. Shutter speed (for Auto iris + shutter mode) Av:Pk Move the cursor to SHUTSPEED position on AGCMAX 30 dB RESPONSE AUTOIRIS+SHUT mode sub menu, press LEFT AGCMIN 00 dB SHUTSPEED 1/60 or RIGHT key for shutter speed setting. -
Page 11: Day/Night Control
2. AWB—Conventional white balance PUSH TO LOCK MENU 3. PTL—Push to lock white balance PUSH 4. Manual—Manual white balance RETURN 5. Preset—Fixed color temperature for Indoor, Outdoor, Fluorescent, User setting. MENU WHITE BAL MENU PRESET MENU R GAIN WB FIX INDOOR B GAIN 3200K... -
Page 12: Day Mode
(D/N SWITCH TIME) SCHEDULE SCHEDULE MENU D → N TIME HOUR : This function can set the time to change the MIN : Day/Night mode. N → D TIME HOUR : MIN : CHOICE D/N TYPE: Press ENTER key to CHOICE D/N TYPE switch D or N mode to conform to your setting RETURN... -
Page 13: Pattern Menu
4. Pedestal level setting Move the cursor to PESESTAL position, while observing the color video monitor or waveform monitor / oscilloscope , press LEFT/RIGHT key to adjust the pedestal level. 5. Chroma suppress effect level setting This parameter is for control the timing of minimal lighting level when the camera picture swaps from color into monochrome. - Page 14 2. Move the cursor to Y GAMMA for different gamma correction, set the value to 04 equal to gamma .45, the value of 01 around gamma = 0.9, Value 07 equal to 0.1. 3.The default setting for Y KNEE is 00, there are 6 knee curve selectable. 4.
-
Page 15: Specifications
6.6.4. SYSTEM MIN Setting minute of current time (0 to 60) 6.4.5. SYSTEM TIME (DISPLAY/HIDE) Show or Hide current time on screen when the camera working. 7. SPECIFICATIONS Image device 1/2” or 1/3” interline transfer Super/Exview HAD CCD Signal system PAL or NTSC standard Picture elements PAL: 542(H) x 582(V), NTSC: 542(H) x 492(V) - Page 16 4. Sync system selection, phase adjustment 5. Picture Chroma, Hue, Brightness, gamma, aperture correction, color suppress 6. Color -Negative, Positive, Monochrome – Negative, Positive. 7. Color pattern generator 8. OSD menu lock 9. Auto Demo Schedule 10. D&N Filters Removable: Auto Detect, Day/Night, D/N by , D/N by External 11.
