43-444.fm Page 1 Friday, August 13, 1999 8:31 AM
Cat. No. 43-444
90-Memory Automatic Desktop Dialer
Your RadioShack Automatic Desktop Dialer gives you easy ac-
cess to frequently called telephone numbers. Three levels of
memory storage let you store up to 90 numbers and quickly dial
each with the press of just a button or two. The dialer comes
with a 7-foot modular cord. Its features include:
32- or 33-Digit Memory — lets you store up to 32 digits (tone
mode) or 33 digits (pulse mode) in each memory location.
Quick-Reference Card — reminds you where each number is
stored.
Chain-Dialing — you can dial up to 16 stored numbers in se-
quence for banking services or long distance.
Touch-Tone or Pulse Dialing — lets you use your dialer with
either tone or pulse service.
Note: Your dialer requires 2 AAA batteries (not supplied) for
power.
Your dialer is ETL listed to UL standards and meets all applica-
ble FCC standards.
© 1998 Tandy Corporation.
All Rights Reserved.
RadioShack is a registered trademark used by Tandy Corporation.
Advertisement
Table of Contents
Related Manuals for Radio Shack Automatic Desktop Dialer
Summary of Contents for Radio Shack Automatic Desktop Dialer
- Page 1 43-444.fm Page 1 Friday, August 13, 1999 8:31 AM Cat. No. 43-444 90-Memory Automatic Desktop Dialer Your RadioShack Automatic Desktop Dialer gives you easy ac- cess to frequently called telephone numbers. Three levels of memory storage let you store up to 90 numbers and quickly dial each with the press of just a button or two.
- Page 2 43-444.fm Page 2 Friday, August 13, 1999 8:31 AM WARNING: To reduce the risk of fire or shock hazard, do not expose this product to rain or moisture. CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER OR BACK.
-
Page 3: Read This Before Installation
43-444.fm Page 3 Friday, August 13, 1999 8:31 AM READ THIS BEFORE INSTALLATION We have designed your dialer to conform to federal regulations, and you can connect it to most telephone lines. However, each device that you connect to the telephone line draws power from the telephone line. -
Page 4: Installing Batteries
43-444.fm Page 4 Friday, August 13, 1999 8:31 AM INSTALLING BATTERIES Your dialer uses two AAA batteries (not supplied) for power. For the best performance and longest life, we recommend alkaline batteries, such as RadioShack Cat. No. 23-555. Cautions: • Use only fresh batteries of the required size and recom- mended type. -
Page 5: Connecting The Dialer
43-444.fm Page 5 Friday, August 13, 1999 8:31 AM 3. Replace the cover, then reinsert and tighten the screw. When the indicator flashes continuously while you are STORE dialing or storing a number, replace the batteries. Cautions: • Always remove old or weak batteries. Batteries can leak chemicals that can destroy electronic parts. -
Page 6: Storing A Number In Memory
43-444.fm Page 6 Friday, August 13, 1999 8:31 AM of the supplied line cord to your dialer’s jack and plug the LINE other end into the telephone line jack. STORING A NUMBER IN MEMORY Note: The dialer stores numbers based on the dialing mode (touch-tone or pulse dial) your phone is set to use. - Page 7 43-444.fm Page 7 Friday, August 13, 1999 8:31 AM 2. Lift the telephone’s handset and press on the dialer. STORE indicator lights. STORE Note: If you are using a speakerphone, you can turn the speakerphone on and off instead of lifting and replacing the handset in this procedure.
- Page 8 43-444.fm Page 8 Friday, August 13, 1999 8:31 AM • To store a number in a bottom (gray) memory location, press then the memory button. LEVEL 3 A beep sounds and the indicator turns off. STORE 5. Replace the telephone’s handset and write the name asso- ciated with the number you stored in the appropriate white, shaded, or gray space next to the memory button.
-
Page 9: Dialing A Number In Memory
43-444.fm Page 9 Friday, August 13, 1999 8:31 AM make the test call during the late evening or early morning hours to avoid peak demand periods. Also, remain on the line to explain the reason for your call. DIALING A NUMBER IN MEMORY Lift the telephone’s handset then: •... -
Page 10: Maintenance
43-444.fm Page 10 Friday, August 13, 1999 8:31 AM REPLACING/ERASING A STORED NUMBER To replace a stored number, simply store a new number in its place. To erase a stored number and leave that memory location emp- ty, follow the steps listed in “Storing a Number in Memory,” on Page 6 except do not enter a number in Step 3. -
Page 11: The Fcc Wants You To Know
43-444.fm Page 11 Friday, August 13, 1999 8:31 AM THE FCC WANTS YOU TO KNOW In the unlikely event that your dialer causes problems on the phone line, the phone company can temporarily disconnect your service. If this happens, the phone company attempts to notify you as soon as possible and advises you of your right to file a complaint with the FCC. - Page 12 43-444.fm Page 12 Friday, August 13, 1999 8:31 AM Limited One-Year Warranty This product is warranted by RadioShack against manufacturing defects in material and workmanship under normal use for one (1) year from the date of purchase from RadioShack company-owned stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED HEREIN, RadioShack MAKES NO EXPRESS WARRANTIES AND ANY IM- PLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DURATION OF THE...
