Boiler dimensions
Series Angus Max-04 Angus Max-05 Angus Max-06 Angus Max-07 Angus Max-08 Angus Max-09 Angus Max-10
L (mm) 673
Boiler packaging dimensions
Series Angus Max-04 Angus Max-05 Angus Max-06 Angus Max-07 Angus Max-08 Angus Max-09 Angus Max-10
L (mm) 730
Notice: Please obey to the meanings of the symbols on packaging for health care
773 873
830 930
973 1073
1030 1130
INSTALLATION, OPERATION AND MAINTENANCE MANUAL 2
fig. 02
1173 1273
fig. 03
1230 1330
