Summary of Contents for Sportsman Tournament 214
- Page 1 TOURNAMENT 214 Owners Manual...
- Page 2 WELCOME TO THE SPORTSMAN TEAM! Here at Sportsman boats, we take great pride in producing the finest, most well designed, saltwater fishing and pleasure boats on the market today. Our designs incorporate the most modern technology while applying good old “Common Sense”...
- Page 3 TOURNAMENT 214 Length 21’4” Beam 8’ Max HP 200 HP People Capacity Fuel Capacity 64 Gallons Rear Aerated Livewell 2 x 20 Gallons Forward Fish Box 22 Gallons Console Cooler 10 Gallons Draft 10” Deadrise @ Transom 15 Degrees Approx Dry Weight...
- Page 4 21’4” 8’...
- Page 5 2014 Tournament 214 - Standard Features •10 Year Fully Transferable Hull Warranty •Grip Tex Yacht Style Non-Skid •NMMA Certified using ABYC Standards •Horn •Advanced Fiberglass Stringer System (no wood) •Hydraulic Steering •10 Gallon Livewell Front Seat of Console •Integrated Rub Rail Navigation Lights •12 Volt Power Plug...
- Page 7 United States Coast Guard (USCG), but goes further and meets the standards set by the ABYC (American Boat and Yacht Counsel). All Sportsman models have been designed, constructed and thoroughly tested to meet or exceed these standards. For more information on the 2014 model year standards, you may visit http://www.nmma.org/certification/programs/boats/...
- Page 8 PROPELLER MAKE: # OF BLADES: important to you should DIAMETER / PITCH: MODEL: PART #: you need to contact your OPTIONAL EQUIPMENT / OPTION PACKAGES Dealer or Sportsman Boats for technical assistance and/or service. TRAILER INFORMATION MAKE: MODEL: SERIAL #: GVRM:...
- Page 9 Type IV throwable PFD. Always wear a PFD when boating. In some states, children are required to wear a PFD at all times. Check your local regulations. SOUND SIGNALING DEVICES Your Sportsman boat is equipped with an electric horn which meets the USCG requirements for a sound signal device. VISUAL DISTRESS SIGNALS USCG approved visual distress signals are required for day and night use when operating on US waters.
- Page 10 Therefore, your Sportsman manual has been written to include a number of safety instructions and notices in order to help you operate your boat safely and maintain it. These instructions are in the form of WARNING, and DANGER statements.
- Page 11 Your Owner’s Manual was written to include safety instructions to ensure safe operations. Safety alerts symbols are used to show potential personal injury hazards. Your boat produces carbon monoxide and uses flammable fuel. Carbon monoxide can cause brain damage or death. Carbon monoxide is colorless, odorless and extremely dangerous.
- Page 13 Master 214 has a 7 Person Capacities, below shows the standing and seated position...
- Page 14 Your electrical system:...
- Page 16 Bilge Pump Located on the hull bottom at the stern of your boat. Water is pumped out at a through hull fitting located at the starboard aft of the hull. Pump may be accessed by lifting the total access hatch. You may turn your bilge pump on manually with your bilge switch located on the switch panel at the helm of your boat.
- Page 17 All-round/Anchor light: Is a white light placed over the highest unobstructed point of the vessel, showing an unbroken light over an arc of the horizon of 225 degrees and fixed to show from anywhere ahead, to just behind the beams of the vessel. Sidelights: Your Masters 214 has rub rail navigational lights installed in the bow gunnel.
- Page 18 Your 214 comes with (2 ) 20 gallon aft livewells and a 10 gallon console livewell. The pumps are located next to the bilge in the hull of your boat. Open the total access hatch for easy access. You may operate your livewells by opening the high speed pickup valve in the bilge area of your boat.
- Page 19 The 214 comes with a 64 gallon fuel tank. The gasoline fuel system consists of a fuel tank, fuel tank vent, anti- siphon valve, engine fuel supply line, fuel fill, and a carbon canister. Your boat contains a new EPA certified fuel system.
- Page 20 Refueling vapors bypass canister and vent through a vented fill to the fuel pump. This line is then closed with a sealed cap after refueling and diurnal vapors are forced through the canister. This approach provides the least restriction during refueling.
- Page 21 Raw water washdown is an option on your new 214. Rinsing your boat immediately with a powerful water jet washdown makes a fine addition to almost any boat. The raw water system supplies water by a hose connected to a pump with a shut off valve on your high speed pick up in your bilge compartment.
- Page 22 Your 214 may be equipped with the optional Infinity PRV250 marine receiver. This compact receiver is capable of Bluetooth audio streaming and features AM/FM radio. Built to last in the harsh marine environment, the Infinity PRV250 incorporates a waterproof faceplate and a 50W by 4 amplifier.
- Page 23 Fresh water is an option on the 214 • The freshwater fill deck fitting is located on the starboard side of the console next to you Recessed Shower . • Pressurize the freshwater system by turning On the freshwater pump switch on the helm. •The freshwater pump switch is marked ACCESSORY 2 on the helm switch panel.
- Page 24 Underwater light option on the 214. They can be operated with the ACCESSORY 1 switch. These High-Intensity LED Underwater Lights are totally waterproof. A broad flood light effect is created by the engineered optics of the convex light face.
- Page 25 214 Pro-Guide Option Package Includes: Under Gunnel Rod Racks with mats to protect your reels. Poling Platform with Push Pole Holders. Caution: Boats w/ jack plate application always be aware of the Motor Cowling hitting the Poling platform. Also to be aware of the Hydraulic steering hitting the jack plate.
- Page 26 Trim Tabs Included with the Pro Guide option Package on your 214. They are attached to the bottom edge of the transom. When the helm control is pressed, the trim tabs move into position. Water-force on the trim tab surface creates upward pressure, raising the stern and lowering the bow.
- Page 27 Rules When Encountering Vessels There are three main situations that you may encounter with other vessels which could lead to a collision unless the Steering Rules are followed: •Meeting: you are approaching another vessel head-on •Crossing: you are travelling across the path of another vessel •Overtaking: you are passing or being passed by another vessel When Crossing: Every boat has a "Danger Zone"...
- Page 28 Sportsman dealer to arrange for your boat to be repaired. The boat owner is responsible for delivering the boat to the dealer for warranty service.
- Page 29 1) A Hull, component, or other product that has been repaired without authorization of Sportsman or that has been altered in any way that affects its use and operation; 2) Expenses related to inspection or warranty service for hauling out, transportation to and from any dealer or Sportsman factory, towing or storage changes, inconvenience or loss of time or income;...
- Page 30 Thank you for your purchase of your Sportsman Boat. Please contact us at any of the following: Sportsman Boats Manufacturing, Inc. 113 Issac Way Summerville, SC 29483 Office:843-376-2628 Fax: 843-376-2636 P.O. Box 2100 Summerville, SC 29484 Email: sales@sportsmanboatsmfg.com Visit:www.sportsmanboatsmfg.com...
