- Page 1 “Essential Element for Outdoor Entertainment ” Stainless Steel Gas Grill USE AND CARE GUIDE MODEL NO.: 720-0016-LP Sterling Forge SKU#: SF2405 FOR OUTDOOR USE ONLY CUSTOMER SERVICE: www.sterlingforgegrills.com...
-
Page 2: Table Of Contents
Feel free to contact us if we can help you. When you write please include the model number of the grill. We thank you for buying Sterling Forge Grill and wish you many years of enjoyment. Note: This appliance is NOT intended to be installed in or on recreational vehicles or boats. -
Page 3: Importance
IMPORTANCE WARNING * * * * * * FOR YOUR SAFETY I f you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Open lid 4. If odor continues, immediately call you gas supplier or your fire department. -
Page 4: Precautions
PRECAUTIONS Do not repair or replace any part of the grill WARNING Do not try lighting this appliance without unless specifically recommended in this reading the “LIGHTING INSTRUCTIONS” manual. All other service should be referred section of this manual. to a qualified technician. CHILDREN SHOULD NOT BE LEFT TESTED IN ACCORDANCE WITH ANSI ALONE OR UNATTENDED IN AN AREA... - Page 5 When using the grill, do not touch the grill could, in the presence of heat, ignite or rack, burner grate or immediate cause metal parts to corrode. surroundings as these areas become extremely hot and could cause burns. Use Do not use the grill for cooking excessively only dry potholders.
-
Page 6: Placement Of The Grill
PLACEMENT OF THE GRILL CLEARANCE To Non-Combustible Construction proximity to traffic paths and keeping A minimum of 3” clearance from the back of any gas supply lines as short as possible. the grill to non-combustible construction is Locate the grill only in a well-ventilated required for the lid to open fully. - Page 7 ASSEMBLY INSTRUCTIONS SIDE SHELVES ASSEMBLY Remove side panels and casters from the carton. Secure two casters to side panel, and secure two casters with brake to side panel together. Assemble bottom panel to side panels with screws as shown in figure below.
-
Page 8: Assembly Instructions
ASSEMBLY INSTRUCTIONS The screws used to attach the back panel are already aligned with holes in the back panel, tighten the screws on back panel of the grill as shown in figure below. Align the rods that are used to do fix door and doorframe with the holes; then put the doorframe on the top of door (see figure below). - Page 9 ASSEMBLY INSTRUCTIONS Assemble the doorframe and spice tray as shown in figure below Remove the upper portion of grill from carton. Place the upper portion of grill on to the cart.
- Page 10 ASSEMBLY INSTRUCTIONS The screws used to attach the side shelf are already screwed into the right side panel (see the figure below). Loosen the side shelf screw (don’t need to take them off). Align with the holes in the side shelf, then tighten the screws on side panels of the grill.
- Page 11 ASSEMBLY INSTRUCTIONS The screws used to attach the side shelf handle are already screwed into the handles (see figure below). Remove the screws from side shelf handle align with the holes in the side shelf, and tight up the screw. Hang up the utensil hooks on left side shelf as shown in figure below...
- Page 12 ASSEMBLY INSTRUCTIONS The screws for the rotisserie bracket are already screwed into the left side of the grill housing. Remove the screws and assemble the rotisserie motor bracket as shown in the figure below. If the burner will not light after several attempts then the burner can be match lit.
-
Page 13: Gas Hook
GAS HOOK-UP Only the pressure regulator and hose L.P. GAS HOOK-UP: assembly supplied with the grill should be Ensure that the black plastic grommets on used. Any replacement pressure regulator the LP cylinder valve are in place and that and hose assembly must be specified by the the hose does not come into contact with the grill manufacturer. -
Page 14: Leak Testing
LEAK TESTING Only those parts recommended by the GENERAL manufacturer should be used on the grill. Although all gas connections on the grill are leak Substitution will void the warranty. Do not use the tested at the factory prior to shipment, a complete grill until all connections have been checked and do gas tightness check must be performed at the not leak. -
Page 15: Operating Instruction
PROPANE CYLINDER CAUTIONS a) Do Not store a spare LP-gas cylinder under or near this appliance. b) NEVER fill the cylinder beyond 80 percent full. c) If the information in “a” and “b” is not followed exactly, a fire causing death or serious injury may occur. - Page 16 sends a spark to the pilot flame. If the burner does not light wait 5 minutes for any excess gas to If you’ve just attempted to light the burner with the dissipate and then retry. igniter, allow 5 minutes for any accumulated gas to dissipate.
-
Page 17: Lighting Illustrations
LIGHTING ILLUSTRATIONS Main & Burner Lighting Illustration Make sure the lid is open 2. Push and turn one of main burner knob to HI position 3. After the burner is lit, adjust the knob as desired... -
Page 18: Care & Maintenance
CARE & MAINTENANCE STAINLESS STEEL SURE THE RANGETOP BURNER IS COOL The grill is made from non-rusting and non- BEFORE REMOVAL. magnetic stainless steel. There are many different stainless steel cleaners available. Always use the GRILL BURNERS mildest cleaning procedure first, scrubbing in the Extreme care should be taken when moving a direction of the grain. -
Page 19: Exploded View
EXPLODED VIEW 720-0016 SF2405- 01 SF- AC - 02 SF- AC - 01 SF2405- 02 SF2405- 25 SF- AC - 03 SF2405- 24 SF2405- 03 SF2405- 23 SF- AC - 11 SF2405- 22 SF- AC - 04 SF2405- 04 SF2405- 06 SF2405- 07 SF- AC - 05 SF2405- 08... -
Page 20: Parts List
PARTS LIST 720-0016 REF# DESCRIPTION Q’TY REF# DESCRIPTION SF-AC-01 Name Plate SF2405-08 Control Panel SF-AC-02 Heat Indicator SF2405-09 Grease Tray SF-AC-03 Heat Insulating Spacer SF2405-10 Left Side Shelf SF-AC-04 Motor Bracket SF2405-11 Side Panel, Cart SF-AC-05 Manifold Retainer Bracket SF2405-12 3” Caster SF-AC-06 Control Knob Seat SF2405-13 Bottom Panel... -
Page 21: Troubleshooting
TROUBLESHOOTING 1. The smell of gas in conjunction with the burner SPIDER AND INSECT WARNING!!! Spiders and insects can nest in the burners of this flames appearing yellow. or any other grill, and cause the gas to flow from the 2. -
Page 22: Grilling Hints
GRILLING HINTS The doneness of meat, whether rare, medium, or Use a spatula instead of tongs or a fork to turn the well done, is affected to a large degree by the meat, as a spatula will not puncture the meat and thickness of the cut. - Page 23 Green beans Peas Place in aluminum foil pan. French fries Medium 15 to 30 minutes Grill, stirring occasionally. MEATS Beef Grill, turning once when juices rise to the surface. Do not leave hamburgers unattended since a flare-up Hamburgers 1/2 to 3/4 inch Medium 10 to 18 minutes could occur quickly.
- Page 24 Grill, turning occasionally. Ribs During last few minutes brush with barbecue sauce, turn Medium 30 to 40 minutes several times. Pork Ham steaks Remove excess fat from edge. Slash remaining fat at 2-inch (precooked) 1/2 inch slices High 4 to 8 minutes intervals.
-
Page 25: Grill Recipe Suggestions
GRILL RECIPE SUGGESTIONS BBQ SALMON in butter and sprinkled with chopped Serve with mixed salad, dressed with parsley and a crisp lettuce salad. vinaigrette flavored with fresh dill. 2 large salmon steaks 2 tbs. Oil Note: Substitute catfish, halibut or cod for BARBECUED LONDON BROIL Salt &... - Page 26 1-1/2 lb. flank steak or boned chicken 1 c. water kabobs with oil. Grill 7-8 minutes each breasts side. 1 chicken bouillon cube 2 tbs. oil 1 can beer for basting sauce ½ cup limejuice Bring marinade to boil on the side burner ½...
-
Page 27: Limited Warranty
LIMITED WARRANTY MODEL NO. 720-0016-LP Sterling Forge SKU# SF2405 STAINLESS STEEL OUTDOOR GAS GRILL Nexgrill Industries, Inc.. warrants to the original consumer purchaser of each Outdoor Gas Grill that when subject to normal residential use, it is free from defects in workmanship and materials for the periods specified below.
