Motorized Treadmill Owner’s Manual HS212TM FORCE PLEASE READ ALL INSTRUCTIONS IN THE OWNER'S MANUAL. CAREFULLY BEFORE ASSEMBLY AND USE OF THE TREADMILL, AND KEEP IT FOR FUTURE REFERENCE.
Page 2
CONTENTS------------------------------------------------------------------------------------1 IMPORTANT SAFETY PRECAUTIONS----------------------------------------------2 ASSEMBLY INSTRUCTIONS--------------------------------------------------------- 3-5 FOLDING & UNFOLDING INSTRUCTIONS-----------------------------------------6 INCLINE INSTRUCTIONS----------------------------------------------------------------7 GROUNDING METHODS-----------------------------------------------------------------8 OPERATION GUIDE-------------------------------------------------------------------9-14 GETTING STARTED GUIDE ----------------------------------------------------------15 SAFETY EXERCISE----------------------------------------------------------------------16 WARM-UP EXERCISE--------------------------------------------------------------------17 MOTOR BELT ADJUSTMENT----------------------------------------------------------18 MAINTENANCEINSTRUCTIONS------------------------------------------------------19 BELT ADJUSTMENT----------------------------------------------------------------------20 EXPLODED DRAWING-------------------------------------------------------------------21 PARTS LIST---------------------------------------------------------------------------- 22-23 ERROR CODES AND SIGNIFICANCE----------------------------------------------24...
Important Safety Precautions Before starting any exercise Programme, consult with your physician or health professional. This applies especially to persons above 35 years old or to people who have had health problems before. Please do not turn on the power to the Treadmill until assembly is completely finished and the motor cover is attached.
Page 4
WHEN YOU OPEN THE CARTON, YOU WILL FIND THE PARTS ILLUSTRATED BELOW. If any are missing please contact your dealer immediately. MAIN FRAME ALLEN WRENCH SCREW DRIVER FRONT COVER 2PCS WIRELESS ALLEN WRENCH POWER CODE BOLT M8*30 CHEST BELT 2PCS RECEIVER MP3 LINE BOLT M8*15...
Page 5
Assembly: STEP 1: Open the carton and take out all of the parts then check them against the information above. If any are missing please contact your dealer immediately. Using both hands, hold the COMPUTER (18) and pull up the UPRIGHT (4L & 4R) in the arrow direction until the screw holes are in alignment.
ATTENTION: Please double check that all assembly steps are completed and that all bolts and screws are tight. Please read these instructions carefully before starting the Treadmill. Folding Instructions: Lift up the bed of the machine and continue to lift until you hear a "click"...
INCLINE INSTRUCTIONS Buttons marked 【INCLINE+】 【 INCLINE-】 and 【 + 】 【 - 】 on the left handrail are incline add and subtract buttons in 2% increments. To adjust the incline when the treadmill is running, press the button for more than 2 seconds, to add or subtract inclination. The computer also has shortcut keys 2%, 4%, 6%, 8%, and 10% Picture A shows incline “0%”, Picture B shows incline “12%”.
Page 8
Grounding: This product must be grounded. If the machine should malfunction or breakdown, the grounding will provide a path of least resistance for the electric current thus reducing the risk of electric shock. This product is equipped with a power cord having an equipment-grounding conductor and a grounding plug.
WINDOW DISPLAYS PROGRAM (PROG): Displays “---” in manual mode. TIME: Indicates the time you have exercised. SPEED: Displays the speed, speed range is 1km/h-20km/h. INCLINE and PULSE: Display the incline when “INCL” flashes, then displays the pulse value when “PULSE”...
Page 10
Turn on the power, every window will be lit for 2 seconds, then the machine will enter manual mode. MANUAL MODE: Put on the safety key then press the START button. After 3 seconds countdown, the treadmill will start with the lowest speed. ...
Page 11
FAN FUNCTION: Press the fan button to start and stop the fan. POWER SAVING MODE If the computer receives no instructions or no button is pressed for 10 minutes. The system will close the display and enter standby mode. Press any button to awaken the system.
Page 12
RUNNING PARAMETERS DISPLAY AND SETTING RANGES PARAMETER CATEGORY DEFAULT VALUE SETTING RANGE REMARK (-1-) 0(MAN) 0—1 0=MAN 1=WOMAN (-2-) 10-99 (-3-) HEIGHT 170 CM 100-240CM WEIGHT (-4-) 70KG 20-160KG MP3 MUSIC AUDIO AMPLIFIER FUNCTION Insert the MP3 jack plug into the MP3 socket on the console. HRC PROGRAM: ...
Page 13
Please do not use HRC with MP3 function, as interference could result. 11. PROGRAM EXERCISE CHART Time SET TIME/20=EVERY GRADE TIME Program 10 11 12 13 14 15 16 17 18 19 20 SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE...
SPEED 10 8 10 8 INCLINE SPEED 10 6 10 6 INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE 10 8 10 8 SPEED INCLINE SPEED 10 8 10 8 INCLINE SPEED 10 6 10 6 INCLINE SPEED INCLINE SPEED INCLINE Maintenance Instructions: Checking Belt Tension: If you feel the running belt has occasional pause when you are running, the running belt or motor...
Page 15
the motor belt is just right. Step 3: Re-tighten the motor attachment bolts and replace the motor cover. WARNING Please make sure to remove the power plug before cleaning or maintaining the Treadmill. CLEANING General cleaning of the unit will greatly prolong the Treadmill's life. ...
Page 16
Place the Treadmill on a level surface then set it to run at approximately 6-8 km/h. Observe the running belt deviation to the right or left. If the belt is drifting to the right, unplug the safety lock and power switch, and turn the right adjusting bolt 1/4 turn clockwise, then insert the power switch and safety lock, run the Treadmill and observe the running belt deviation condition.
Page 18
DESCRIPTION REMARK DESCRIPTION REMARK ADJUSTABLE ∮9*∮62*23.5 MAIN FRAME WHEEL BASE FRAME INNER PLUG 30*60*t1.5 PIPE MOVING WHEEL INCLINE BRACKET 40*80*t1.8 PIPE PLUG UPRIGHT EDGING WIRLESS CHEST MOTOR BRACKET BELT RECEIVER FRONT ROLLER PLANAR PAD ∮30*∮6.5*16 REAR ROLLER CUSHION RING PROTECTING COMPUTER BRACKET WIRE PLUG COMPUTER CHIP...
Page 19
DESCRIPTION REMARK DESCRIPTION REMARK GASKET HEAD SELF COMPUTER MIDELE WIRE M4*15 TAPPING SCREW ∮ 8.1* ∮ COMPUTER BOTTOM WIRE SPRING WASHER 12.3*t2.1 ∮ 8.4* ∮ SENSOR INNER WASHER 14.5*t0.8 COUNTERSUNK HEAD SINGLE LINE M5*30 SCREW CONTROLLER LOCK NUT HANDRAIL BAR LOCK NUT HEX NUT HEX NUT...
Page 20
GASKET HEAD SCREW M5*10 Fault Codes and Significances Fault Code Fault Description Fault Processing Stops and goes into fault Status. The machine will not run, the Communication computer shows fault code “E1”, and the alarm Beeps three abnormal: The times. control board and Possible Reasons: Check all the connection points between the computer are not...
