- Page 1 KPW-2012-D-x Din-Rail AC-DC 12V Power Supply User s Manual DOC.091217...
- Page 2 (C) 2009 KTI Networks Inc. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any directive work (such as translation or transformation) without permission from KTI Networks Inc.
- Page 3 The information contained in this document is subject to change without prior notice. Copyright (C) All Rights Reserved. FCC NOTICE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including the interference that may cause undesired operation.
-
Page 4: Specifications
DC Power Output Interfaces Type 1: Screw-type terminal block (Vout＋, Vout－, Vout＋, Vout－) Type 2: DC plug with bundled DC plug cable ＋12VDC, 1.8A max. Output Power Power Specification KPW-2012-D 100%@－20 C ~＋50 C, 50%@＋60 KPW-2012-D-E 100%@－20 C ~＋60 Protection... - Page 5 Mechanical Dimension (base) 40 x 80 x 95 mm (WxDxH) Housing Enclosed metal Mounting Din-Rail mounting, Panel mounting, Desktop mounting Environmental Operating Temperature KPW-2012-D: －20 C ~＋50 KPW-2012-D-E: －20 C ~＋60 －30 Storage Temperature C ~＋85 Relative Humidity 10% ~ 90% non-condensing...
-
Page 6: Installation
Installation Unpacking The product package contains: The power supply unit One DC plug cable One product CD-ROM Safety Cautions To reduce the risk of bodily injury, electrical shock, fire and damage to the product, observe the following precautions. Do not service any product except as explained in your system documentation. Opening or removing covers may expose you to electrical shock. -
Page 7: Din Rail Mounting
Din-Rail Mounting Install the Din-Rail bracket on the rear panel as shown below: Mount the device unit on a Din-Rail as shown below:... -
Page 8: Panel Mounting
Final Dimension after Installation Panel Mounting An optional panel mounting bracket supports mounting the power supply on a plane surface securely. - Page 9 Install the bracket onto the device unit as shown below and use two screw holes to fix the unit on a plane surface: Final Dimension after Installation...
-
Page 10: Ac Power Input
AC Power Input The power supply provides two types of power interfaces, IEC320 and terminal block for receiving AC power input. Using Terminal Block Use 3P terminal plug for AC power wires. Install the wires into the plug securely. The colors of the power wires are: Contacts Europe (IEC) - Page 11 Install the wired plug onto the AC socket properly. For safety purpose, use the provided yellow cap to cover the unused IEC320 receptacle. Using IEC320 Interface One AC power cord which meets the specification of your country of origin is supplied in package. Plug the power cord into the IEC320 receptacle properly.
-
Page 12: Dc Power Output
DC Power Output The power supply provides two pairs of industrial terminal block connectors for installations and one typical DC plug support for commercial installation. Using Terminal Blocks DC OUT ( 2P x 2 Contacts) ＋terminal －terminal ＋terminal －terminal :＋12VDC, 1.8A total max.) Use the supplied 2P plug for DC power wires. - Page 13 Plug the wired DC plug into DC OUT socket as shown below and put cap on any unused DC OUT contacts. Using DC plug cable To support the devices which have only DC IN Jack interface, one DC plug cable shown below is supplied. DC Plug Cable -13-...
- Page 14 Insert the cable into DC OUT terminal block of the power unit as illustrated below and uncover any unused contacts. An Example of supplying power to a device with DC Jack. -14-...
