wink haus blueMatic EAV Operating Manual

Automatic locking system with motor operated opening
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
blueMatic EAV
Automatic Locking System with
Motor Operated Opening
Operating Manual
After installation please pass on these instructions
to the end customer. (Disclosure obligation stipula-
ted in the Product Liability Act.)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the blueMatic EAV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for wink haus blueMatic EAV

Summary of Contents for wink haus blueMatic EAV

  • Page 1 EAV Automatic Locking System with Motor Operated Opening Operating Manual After installation please pass on these instructions to the end customer. (Disclosure obligation stipula- ted in the Product Liability Act.)
  • Page 2 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 This security door locking system complies with the requirements and directives es- tablished and stipulated by the Council on the Harmonization of Legal Regulations of Member States regarding Electromagnetic Compatibility (89/336/EEC).

  • Page 3: Table Of Contents

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Table of contents General information Important information page 5 Important General information page 5 information Intended use page 5 Product Use contrary to the intended purpose page 6 description Explanation of symbols...

  • Page 4: Table Of Contents

    33 blueMatic EAV with transponder page 33 4.2.1 Operation page 33 4.2.2 Programming page 34 blueMatic EAV with wireless remote control page 36 4.3.1 Operation page 36 4.3.2 Programming page 36 Wireless receiver for additional applications (e. g. garage door control units)

  • Page 5: Important Information

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Important information General information General information Dear Customer, Important information We would like to thank you for your confidence you have put in us by purchasing our high-quality product. Product Please read this operating manual carefully to become acquainted with the installation...

  • Page 6: Use Contrary To The Intended Purpose

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 The stipulations for use as intended have been met, once the Winkhaus fittings are: • installed according to their defined function and the installation specifications, • not used in any other way than described, • maintained and cared for at regular intervals as instructed, and/or defined sliding places oil at least 1 x annually (like e.g. chamfer of latch, automatic tracer pin …) if necessary more frequently, •...

  • Page 7: Explanation Of Symbols

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 • the handle is not loaded in the normal sense of rotation or a a force above 150 N General is applied onto the handle in the direction of actuation; information • the gap between the door frame and sash is increased or decreased, which would for instance result from readjusting the hinges or if the door drops; Important • auxiliary lifting tools or objects are used to open or close the lock;...

  • Page 8: Abbreviations/Explanations

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 • For security reasons, the lock has been designed to be used in conjunction with ge- nuine Winkhaus parts. Using other parts may adversely affect the given properties of the security lock. • It must be ensured that the door can be closed without any difficulties with the key. • Installation/Repair of electrical equipment requires expertise, thus such work should only be carried out by a qualified electrician.

  • Page 9: Product Description

    Product description General information The blueMatic EAV (automatic locking system with motor operated opening) is a state- of-the-art locking unit for securing and locking entry doors in a contact-free manner. Important The hooks can be retracted electrically so as to open the door.
  • Page 10 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Name Included MUST! Available Supplied in standard Man- as an ac- by custo- delivery of cessory mer/not datory the security or as an included in lock option standard delivery autoLock AV2 (Automatic lo- cking system STV-AV2-F/U ...)

  • Page 11: Troubleshooting

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 autoLock AV2 Automatic locking system General information Automatic three-point locking system with safety protection against faulty switching, DIN RS and LS directions Important information Part Description DIN right DIN left STV-AV2-F1660 L20/35 92/8 M2 rs/ls mc...
  • Page 12 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 autoLock AV2 Automatic locking system Part Description DIN right DIN left STV-AV2-F2460 L20/50 92/8 M2 rs/ls mc 295 320 1 295 321 9 STV-AV2-F2460 L20/50 92/8 M2 rs/ls est 253 411 1...

  • Page 13: Troubleshooting

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Motor housing General information Motor housing for powered unlocking, including control, but wi- thout cable Important • for transponder or wireless remote control information • switching unit for automatic door opener via floating contact • available mounted or separate Product description STV-Motor housing EAV 240 992 6...
  • Page 14 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Extension keep set/single keeps Select the corresponding standard frame parts in the current program manual (single keeps/alternatively extension keep set): Program Manual Wood/PVC/ALU 12/2008 493 476 7 Program Overview keep wood...

  • Page 15: Troubleshooting

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Cable transition KÜ-T-STV General information Plug-in and lying buried cable transition • Inserted by plug-in function with retaining screws Important • sash part with spring jacket and cable of 2 m [2.187 yd] or information 3.5 m [3.829 yd] (plug for motor housing included) • for STV-SET KÜ-T-integra-EAV sash part with spring jacket Product and cable of 1 m [1.094 yd] (cable end with 8-pole plug)

  • Page 16: Power Supply

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Power supply Power supply unit for blueMatic EAV: 100 - 240 V, 50/60 Hz, + + - 12 V DC, 2 A, to be installed on a top hat mounting rail Netzteil/Powersupply...

  • Page 17: Troubleshooting

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Transponderset EAV General information Consisting of: • 1 reader/control unit (for flush-type box) Important - mounting of the reader on the inside information • 1 antenna for exposed installation (90 x 90 x 13 mm, [3.543 x 3.543 x 0.512”], color white), cable of 2.5 m [2.734 yd]...

  • Page 18: Installation

    Print-no. 250 020 1 02/2011 Installation Routing details For installing the blueMatic EAV it is required to rout out for standard three-point lo- cking system and additionally the motor housing, as shown in the following diagrams. NOTICE! Important for wood/...

  • Page 19: Cable Transition Kü-T-Stv (Plug-In)

    Figure 3.1-2: Location of the motor housing for blueMatic EAV description Installation Operation Programming Maintenance Figure 3.1-3: Location of the main lock housing for blueMatic EAV and care NOTICE! Errors a) The routing for the main lock housing must be 16 mm [0.630”] as Troubleshooting...
  • Page 20 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Sash part 6 : • If cover plate 4 is used, mill slotted 16 resp. 20 Ø oblong hole 90 mm (see Figure 3.2-1, deep with wood doors approx. 50 mm) •...
  • Page 21 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 NOTICE! Provide cable slack of about 3 - 5 cm [1.181 - 1.969”] for the General spring tension behind the sash part of the cable transition. information • Complete the plug-in connection after putting the door on its hinges Important •...
  • Page 22 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Installations DANGER! The installation of electrical equipment requires expertise, thus such work should only be carried out by qualified electricians. DANGER! Generally assemble and install only with the power off! CAUTION! The Door must easily lock mechanically before checking the electric func-...

  • Page 23: Troubleshooting

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 3.3.1 General connection diagram General information Recommendation: flush-type box or junction box for cable connection Important to/from the motor housing or cable transition N PE information power supply 4 5 free...

  • Page 24: Access Control System Transponder Set

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Access control system transponder set Prerequisites for installation: • The transponder signal is processed in the reader/control unit. • This unit has to be installed in a standard flush-type box inside the building (close to the door). NOTICE! Should you want to accommodate the control unit and button in the same flush-type box, this must have a depth of 65 mm [2.559”]. •...
  • Page 25 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Terminals „12 V DC“ General „0 V DC“ information serial interface serial interface antenna Important information antenna potential free contact C potential free contact NO Product Figure 3.4-1: Terminal assignment of the transponder reader...

  • Page 26: Access Control System Wireless Remote Control

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Access control system wireless remote control Prerequisites for installation: • To ensure the reliable performance, the position of the wireless receiver is of ut- most importance for the received power. • Do not install it at or nearby sources of possible interference (e.g. EDP/high-perfor- mance power distributor). • To prevent manipulation of the receiver we recommend installing the receiver on the inner side of the door! 3.5.1 Wireless remote control set Installation sequence: •...
  • Page 27 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Name Name General „P1 button“ „buzzer“ information „green LED“ „relay“ Important „red LED“ „jumper“ 12 V/24 V information Product to/from the motor housing description or cable transition Installation Operation Programming „Open“...

  • Page 28: Wireless Receiver (Separate)

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 12 V = delivery status 24 V Figure 3.5.1-3: Adjustment of the jumper for voltage selection • The default setting of the jumper is 12 V. • The wireless receiver can be adjusted from 12 V to 24 V via the jumper. NOTICE! Check the proper position of the jumper before starting operation! 3.5.2 Wireless receiver (separate)
  • Page 29 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 NOTICE! Do follow the relevant installation instructions of the additional General applications! information • Put the cover back on the housing and lock and screw it down. Important information Terminals 8, 9 NO relay K4 - non-operated contact is open, it closes by activating per remote...
  • Page 30 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Non-Winkhaus access control system 3.6.1 Non-Winkhaus access control system general Please observe the following instructions when using other than the precalled systems to control the automatic locking system with motor operated opening (e. g. transpon- der set, wireless remote control): •...
  • Page 31 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 • Assembly connection between control unit ekey home integra 2 and motor General housing EAV 4 . For this connect the wires of the cable of 2 m (included in deli- information very of the integra - EAV 5 ) with terminal X6 (see figure: 3.6.1-1, detail A).

  • Page 32: Control Of Additional Applications (Only Integra 2)

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Name Name motor housing EAV separable cable transition KÜ-T-integra-EAV cable integra - EAV (2 m) control unit ekey home integra finger scanner ekey home integra cable Typ „A“ ekey home integra (2 or 4 m) 3.6.2.1 Control of additional applications (only integra 2)

  • Page 33: Operation/Programming

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Operation/Programming General information blueMatic EAV Important 4.1.1 Locking and unlocking information Locking: Product • Even when closing the door it is automatically locked by two massive hooks and description the latch in the main lock housing. • Additional protection is provided by manual locking: one rotation of the key (1 x 360°) causes the dead bolt in the main lock housing to be thrown.

  • Page 34: Programming

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 • The transponder data is transmitted to the reader unit via the antenna. • An acoustic signal at the reader unit will acknowledge the data transfer. • The reader checks whether this ttransponder chip is authorized to access and allows or denies access. Action Acoustic Signal Result Door with transponder authorized chip „Open“...
  • Page 35 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 NOTICE! If you do not swipe the transponder chip across the antenna for General a period of 5 seconds, the teach-in mode will be stopped. The reader unit information returns to operating mode. Action Acoustic Signal Result Important information Pass all the transponder Transponder chips...

  • Page 36: Bluematic Eav With Wireless Remote Control

    Print-no. 250 020 1 02/2011 NOTICE! Keep the programming cards at a safe place to prevent any kind of misuse. If you lose the cards, the reader unit will have to be exchanged in its entirety! Please contact customer service in such a case. blueMatic EAV with wireless remote control 4.3.1 Operation • It is operated via the wireless remote controls working contactless. •...
  • Page 37 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 If no remote control has been programmed (for example after „delete-all“ func- General tion), it would apply to all remote controls. The teach-in mode can be started with information any remote control.
  • Page 38 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Replacing the batteries in the wireless remote control • At the button ring hole, pull the colored battery cover from the bottom of the remo- te control outwards. • The battery compartment swings out. • Replace the batteries. • Insert two Lithium CR 2016.31 batteries. NOTICE! Pay attention to the correct polarity! ECO-WATCH! Properly dispose of the batteries as demanded by environ-...
  • Page 39 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 • Activate the desired button of the remote control while the LED is lit up General • As long as the LED is lit, you can program additional remote control buttons. information Display Memory full: The memory has been filled to capacity (max. 85 buttons), if the Important teach-in button of a new wireless remote control is used and both LED displays of the information receiver flash simultaneously.

  • Page 40: Wireless Receiver For Additional Applications

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Displaying the occupied memory units: • Press and hold the P1 button of the receiver until the green LED lights up. • Keep the button pressed until the LED goes off. • Then release the button immediately. The display is a binary code: LED green = 1, LED red = 0 Wireless receiver for additional applications (e. g. garage door control units) NOTICE! The programming of remote controls via this receiver is not possible.

  • Page 41: Maintenance And Care

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Deleting via the wireless receiver General information Partial deletion: • Press and hold the P1 button for about 2 seconds. Important • When the green LED lights up, release the P1 button. information • Press the button of the wireless remote control you would like to delete. • The deletion of the button is signaled by the flashing LED. Product description Delete-all: • Press and hold the P1 button until the green LED lights up. • Release the P1 button. Installation • When the LED lights, press the P1 button again until both LED flash three times. Operation The memory is full once 85 buttons have been saved in the wireless remote control.

  • Page 42: Errors/Causes/Troubleshooting

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Errors/Causes/Troubleshooting Error Indication Possible cause Troubleshooting the door does not Hooks not engaged • the door is warped • check the installation, lock automatically • the contact pressure is and the keep adjust- too high ment and alignment • the door has not been • adjust the hinge plates installed properly...

  • Page 43: Technical Specifications

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Error Indication Possible cause Troubleshooting General Power failure when/ information during: a) the door is locked • the door can be opera- ted mechanically (pro- Important file cylinder/handle) information b) the door is open, the door is possibly • the motor is not in...

  • Page 44: Antenna/Reader Unit

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Antenna/Reader unit Dimensions (antenna): antenna housing: 90 x 90 x 13 mm [3.543 x 3.543 x 0.512”], for exposed installation, cable is perma- nently installed Dimensions (reader): 45 x 45 x 22 mm [1.772 x 1.772 x 0.866”] Reading distance: between 0 and 8 cm [0 - 3.150”] (depending on...

  • Page 45: Cable Transition Kü-T

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Number of code combinations: 2 to the power of 64 (as „Rolling Code“) General Modulation: AM/ASK information Rated output E.R.P.: 50 - 100 µW Range in an unobstructed area: max. 30 m [32.808 yd]...

  • Page 46: Accessories

    Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 Accessories Transponder chip Transponder chip (separate) as an extension to transponder set EAV (241 026 5). • form: key fob • color: blue STV-Transponder chip T01 blue 212 676 6 Wireless remote control Wireless remote control (separate) as an extension to the wire- less remote control set (241 027 3).
  • Page 47 Operating Manual blueMatic EAV Print-no. 250 020 1 02/2011 EC Declaration of Conformity General information For the products: Important blueMatic EAV information in the design: Product description Safety door locking system autoLock AV2 + motor control EAV 1 (mounted/not mounted)
