MicroImage Video Systems ENC400B Operation Manual

ENC400B
Operation Manual
RGB to NTSC and S-Video Encoder
MicroImage Video Systems
division of World Video Sales Co., Inc.
P.O. Box 331
Boyertown, PA 19512
610-754-6800
Fax 610-754-9766
info@mivs.com
www.mivs.com
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 2
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 3
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 3
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 3
Video Connections . . . . . . . . . . . . . . . . . . . . . . . . Page 3
In case of difficulty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 3
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 4
Returns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 4
(RGB) 1.0 Vpp Composite, 75 S terminated
Input level
(S) 5.0 Vpp max 75 S terminated
Output level (Y & Video) 1 Vpp typical into 75 ohm
(C) 0.28 Vpp burst typical into 75 ohm
Connectors (R, G, B, S, Video) BNC female
(S-Video) 4 pin mini DIN F
Resolution Greater than 400 lines
Modulation R-Y, B-Y Axes
Genlock Combination Analog & Digital Synthesis
Sync Internal (sync on green) or External (default)
Video System NTSC, RS170
H & V Frequency 15.734 Khz (H), 59.95 Hz (V)
Chroma Frequency 3.579545 Mhz
Operating: 0° - 40° C (32° - 104° F)
Temperature
Storage: -40° - 60° C (-40° - 140° F)
Humidity
Operating 10% - 90%, Storage 5% - 95% (non-condensing)
Power 11-20 VDC (+12 VDC typical)
120V power adapter included
Size 5.6" (w) x 4.1" (D) x 1.6" (H)
142 mm (w) x 104 mm (D) x 40 mm (H)
12 oz. (340 g)
Weight
Manufactured in USA by MicroImage Video Systems
Page 2
Contents
Rev 2 02-16-2001

Specifications
