Gingko Audio ClaraVu 7 Owner's Manual

Each ClaraVu speaker is hand-built in the USA instead of coming off a factory line. Each is thoroughly
tested and comes with a 2-year warranty to the original owner.
The ClaraVu 7 modular speaker system consists of a monitor speaker and a matching powered
subwoofer. They are perfect for apartment-size high-end systems, yet their big sound offers more than
satisfying performance in reference-level setups. A combination of 85 dB sensitivity and 8 ohm minimum
impedance means the ClaraVus are easily matched to a wide range of tube or solid state amplifiers.
The ClaraVu speaker enclosures are available in three beautiful finishes: maple, cherry and gloss piano
black. The modular construction of the system means that you can but the monitor speakers with
matching stands first, then add the sub modules to make a full range system.
The ClaraVu 7 monitor is a two-way speaker using a 1" soft dome tweeter and twin 6.5" paper cone
woofers in a unique isobaric configuration. Two woofers are mounted one in front of the other in a
sealed paperboard tube inside a rigid cabinet. The same design is used in the drivers of the sub module.
This design minimizes vibration and standing waves and results in the ClaraVu's high-resolution and
extreme musicality.
The ClaraVu 7 speakers will show you a "clear view" into your music by capturing all the details and
nuances of the recording and performance.
SPECIFICATONS:
Monitor Speakers – Retail $3995/pair
Tweeter: 1" silk dome using patented technology
Woofers: 2 custom drivers, 6.5" paper cone
Frequency Response: 45Hz-20KHz +/- 3dB
Impedance: 10 ohms nominal, 8 ohms minimum
Sensitivity: 85 dB
Recommended power: 30 watts
Dimensions: 22"h x 9"w x 15"d
Weight: 45 lbs. each
Cabinet finish - maple, cherry, and piano black
Stands – Retail $500/pair
Dimensions: 27"h x 13"w x 14"d
Weight: 38 lbs each
Finish: Gloss Piano Black
GINGKO AUDIO
ClaraVu™ 7 Modular Speaker System
Owner's Manual
Thank you for purchasing Gingko Audio's ClaraVu 7
speaker system.
These striking speakers are a result of 7 years of intensive
research and development. Each speaker is hand crafted in
the USA using the finest parts in the world. Custom drivers,
high-quality caps and coils, OCC copper cabling and unique
cabinet construction result in superlative resolution and
musicality.
Powered Sub Modules – Retail$1495 each
Woofers: 2 custom drivers, 6.5" paper cone
Sub amp: 75w into 8 ohms, 100w/ into 4 ohms
Options for hookup: low-level via interconnects or
high-level via speaker wires
Adjustments: Volume, Crossover frequency, Phase
Sensitivity: 85 dB
Weight: 48 lbs. each
Cabinet finish - maple, cherry, and piano black
1
