INSTALLATION AND OPERATION GUIDE FOR
Installation and service must be provided by a qualified installer,
ADEQUATE FIREPLACE VENTILATION IS REQUIRED FOR SAFETY
NOTE:
READ INSTRUCTIONS FULLY BEFORE INSTALLING OR OPERATING
INSTALLER: LEAVE THESE INSTRUCTIONS WITH CONSUMER!
The gas appliance must be burned only in a fully vented, non-combustible fireplace with the damper
completely open and the chimney free of any obstructions or restrictions. The fireplace must be designed and
approved to burn wood.
The realistic yellow flame produces carbon monoxide and soot. Under normal conditions, these products are
exhausted up the chimney. If fumes or soot, from the gas burning, are evident in the room when the damper is
fully open it indicates that the fireplace draft is defective. Do not operate your gas appliance until the fireplace
draft is corrected.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WARNING:
If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
It is the homeowner's responsibility to
assure their fireplace has adequate draft.
HARGROVE
Glass H-Tube and
Stainless Steel "S" Burner
service agency or the gas supplier.
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
1. Do not try to light any appliance.
2. Do not touch any electrical switch; do
not use the phone in your building.
3. Immediately call your gas supplier from a
neighbor's phone. Follow the gas
supplier's instructions.
4. If you cannot reach your gas supplier,
call the fire department.
1
Advertisement
Table of Contents
Related Manuals for Hargrove H-Tube
Summary of Contents for Hargrove H-Tube
- Page 1 INSTALLATION AND OPERATION GUIDE FOR HARGROVE Glass H-Tube and Stainless Steel “S” Burner Installation and service must be provided by a qualified installer, service agency or the gas supplier. ADEQUATE FIREPLACE VENTILATION IS REQUIRED FOR SAFETY NOTE: READ INSTRUCTIONS FULLY BEFORE INSTALLING OR OPERATING...
- Page 2 IMPORTANT INFORMATION WARNING: This appliance assembly contains burner orifices specifically for the input gas and Btu rating. Modifying or failure to use the factory orifice may cause property damage, personal injury or loss of life. 1. Do not use a natural gas set for propane or a propane set for natural gas. 2.
- Page 3 FIREPLACE SIZES Each gas appliance requires a minimum 16-inch front opening height and minimum 16-inch depth. To determine the largest set that will fit in a fireplace, the width at the center of the fireplace is the critical dimension. Table I below indicates the minimum center width for each size set. Front Width Center Width Back Width...
-
Page 4: Parts List
3. Connect the black flex connector (3) to the elbow (5). 4. Connect the 1/2" to 3/8” brass reducer (4) to the H-tube (1). 5. Make sure that the H-tube has the holes facing down. This will keep the sand from obstructing the holes. This will not affect flame height. - Page 5 INSTALLING STAINLESS STEEL “S” BURNER PARTS LIST FOR NATURAL GAS WITH NO VALVE ITEM DESCRIPTION 18SNSB0A0 24SNSB0A0 30SNSB0A0 1. S-Burner SSSB18 SSB24 SSB30 2. Black pipe cap CAP-8 CAP-8 CAP-8 3. Sand 4. Flex connector FCNW-18 FCNW-18 FCNW-18 5. Brass reducing elbow 50-6-8 50-6-8 50-6-8...
- Page 6 INSTALLING STAINLESS STEEL “S” BURNER PARTS LIST FOR NATURAL GAS WITH VALVE ITEM DESCRIPTION 18SNSB1B0 24SNSB1B0 30SNSB1B0 1. S-Burner SSSB18 SSSB24 SSSB30 2. Black pipe cap CAP-8 CAP-8 CAP-8 3. Valve CPC-C CPC-C CPC-C 4. Control knob SPC-K SPC-K SPC-K 5.
- Page 7 INSTALLING STAINLESS STEEL “S” BURNER PARTS LIST FOR LIQUID PROPANE WITH VALVE ITEM DESCRIPTION 18SNSB1B0 24SNSB1B0 30SNSB1B0 1. S-Burner SSSB18 SSSB24 SSSB30 2. Black pipe cap CAP-8 CAP-8 CAP-8 3. Valve CPC-C CPC-C CPC-C 4. Control knob SPC-K SPC-K SPC-K 5.
-
Page 8: Gas Connection
1. The gas supply line should be 1/2" Inside Diameter (ID) up to 30 feet and 3/4" for longer distance. 2. Use the gas connector (FCNW-18) to connect gas supply to the H-tube burner and “S” burner. 3. Read lighting instructions. Light pilot on the “S” burner and check for leaks using soapy water. These controls are factory preset and will not normally require additional adjustment of the pilot flame. - Page 9 Fig 4 Sand BURNER PAN MEDIA (Fig 4) 1. Cover the Glass H-tube with Sand. The Glass H-tube should be completely covered. 2. Light the gas and observe the flame for even distribution. 3. The glass or beads are placed over the sand.
-
Page 10: For Your Safety Read Before Lighting
FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot, which must C. Use only your hand to push in or be lit by hand. -
Page 11: Limited Warranty
8. Purchaser or user agrees to hold Hargrove Mfg Corp. harmless from any and all claims by the buyer as a result of injury or damage to an ultimate user or other person caused by the product sold herein by the seller to the buyer, whether the injury or damage results from the assembly, installation, operation, shipment, storage, or manufacture of this product.
