XNET Network Video Server User's Guide
XNET
Network Video Server
User's Guide
Ver. 1.0 (071024)
1 of 44

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XNET and is the answer not in the manual?

Questions and answers

Related Manuals for CNB XNET

Summary of Contents for CNB XNET

  • Page 1 XNET Network Video Server User’s Guide XNET Network Video Server User’s Guide Ver. 1.0 (071024) 1 of 44...
  • Page 2 XNET Network Video Server User’s Guide Directions XNET are designed for indoor use only. When using XNET outdoors or in an environment that exceeds the limited range, you must separately use a water-resistant case. Be careful not to cause any physical damage by dropping or throwing the XNET. Especially keep the device out of reach from children.

  • Page 3: Table Of Contents

    ................... 13 3.2. Connecting to xDSL/Cable Modem ..............14 4. IP-Installer ......................... 15 4.1. Main window of IP-Installer ................15 5. Configuring XNET in Administrative Mode ............... 16 5.1. Log On ......................16 5.2. Basic Setup ...................... 18 5.3. Network Configuration ..................

  • Page 4: Introduction

    IP connection over internet or intranet. Unlike CCTV or DVR, the XNET is easy to install and owner will experience cost and space savings in the installation owing to the state of the art technologies embedded in the system.

  • Page 5: Product Description

    XNET Network Video Server User’s Guide  Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.)  Teleconference (Bi-directional audio conference)  Remote Learning  Weather and environmental observation 2. Product Description 2.1. Contents Open the package and check if you have the followings:...

  • Page 6: Physical Description

    XNET Network Video Server User’s Guide 2.3. Physical description 2.3.1. INS1000 Figure 2-1 Front view of INS1000 RS-232C Factory Reset Figure 2-2. Rear view of INS1000  VIDEO IN : Connect external video source(NTSC/PAL).  VIDEO OUT : Composite video output.
  • Page 7 RxD of RS-232C use only. 1 2 3 Ground of RS-232C  DC Power : Power input of XNET. Do not apply power through this power input when power is applied through LAN cable using proprietary PoE. 7 of 44...
  • Page 8 XNET Network Video Server User’s Guide  RS-485 and ALARM IN/OUT : Used for connecting P/T device, sensor, and alarm devices to XNET. Pin assignments are as follows Description Misc. Alarm Out Relay output : closed circuit in alarm to indicate alarm status.
  • Page 9 XNET Network Video Server User’s Guide 2.3.2. IJB1000 Figure 2-4. IJB1000 (Each function of wire is same as IVS100.) 9 of 44...

  • Page 10: Pc Requirements

    XNET Network Video Server User’s Guide 2.4. PC Requirements AV streaming data received from XNET can be decoded or stored in a PC running XNET-NVR program which is a viewing & recording program for a PC. Minimum requirement of the PC is...
  • Page 11 Cable modem you need supplementary information provided by your ISP. 5. Connect to XNET in Administrator Mode for initial parameter set-up. All parameters are set to factory default state when XNET is delivered. You are asked to configure the system for your environment in administration mode. Detailed information...
  • Page 12 Network connection or Cable modem. 7. Remote video connection to XNET Run “XNET-NVR” on your PC. Before connecting to XNET it is needed to configure the connection information on the XNET-NVR. More detailed information of using “XNET- 12 of 44...

  • Page 13: Connecting Xnet To Network

    IP address is shared by at least 2 IP devices. Refer to [IP-Installer User’s Guide] details of setting the IP address for XNET. 3.1. Connecting to LAN In case of connecting the XNET to LAN, it is generally connected as in Figure 3-1. IP Network (LAN/WAN Router...

  • Page 14: Connecting To Xdsl/Cable Modem

    3.2. Connecting to xDSL/Cable Modem 1. Follow through steps 1 to 4 in Section 2.5 to assign IP address and other network parameters to XNET. 2. Install XNET and connect it to xDSL or Cable modem as in Figure 3-2. IP Network (LAN/WAN...

  • Page 15: Ip-Installer

    XNET needs IP network parameters for connection to the network(Internet/Intranet). IP- Installer is a PC program for the initial network configuration to IP video products such as Network Camera or A/V Server. IP-Installer is provided in a CD supplied with XNET or it can be downloaded from “www.cnbtec.com”.

  • Page 16: Configuring Xnet In Administrative Mode

    XNET Network Video Server User’s Guide 5. Configuring XNET in Administrative Mode 5.1. Log On There are 2 ways of connecting to XNET administrative mode. One is through Internet Explorer and the other is through “XNET-NVR” program. 1. Using Internet Explorer...
  • Page 17 XNET Network Video Server User’s Guide Figure 5-2. Log On Screen Factory default User Name and Password are set as „root‟ and „dw2001‟, respectively. Click on “OK” button to enter into the Basic Setup page of Administrative Mode. If you have changed the username and password of the Administrator, you must log on with the changed username and password.

  • Page 18: Basic Setup

    Description /Button Language Select a language of your choice Logical name of the XNET. It is same as the one set-up by IP- System Name installer. You can reassign the system name. Screen A directory for saving captured image files that can be get capture from Web viewer.
  • Page 19 XNET Network Video Server User’s Guide Input Video This filed is set by the factory Select a video size for transmission- Video Size NTSC(30 fps Max.) : 176x144/352x240/704x480.  PAL/SECAM (25 fps Max.) : 176x144/352x288/704x576  Max upload Assign maximum bandwidth of the uplink for the network rate connected to XNET.

  • Page 20: Network Configuration

    XNET Network Video Server User’s Guide 5.3. Network Configuration Setup the network parameters appropriately in accordance with your network environment. Many of the parameters in this page are same as those set up by “IP-Installer”. Figure 5-4. Network Configuration 20 of 44...
  • Page 21 Sub Field Description Field/Button /Button The network types supported by the XNET are LAN(fixed IP), PPPoE, and DHCP(automatic IP allocation) When the network environment is fixed IP, select „LAN‟ in the Static IP Set network type, and put the IP address, Subnet Mask, Gateway, DNS1 and DNS2.
  • Page 22 XNET Network Video Server User’s Guide Recv E-Mail Enter E-mail address to receive information sent from your Address network camera. This is same as E-mail field in IP-installer. Return E-Mail Fill in this field with correct e-mail address to identify the mail...

  • Page 23: User Admin & Time Setup

    XNET Network Video Server User’s Guide 5.4. User Admin & Time Setup You can change the ID and password of users and also assign different attributes for each user. Figure 5-5. User Admin. & Time Setup Sub Field Field/Button Description...
  • Page 24  You can delete specific user by clicking the DELETE button. If you want to restrict viewing access to the XNET, check at the box left to Yes and click on Save. Users need to input ID and password to connect to XNET in viewing mode in a pop up window as shown below.
  • Page 25 Synchronize Synchronize the time with the internet time server at the right. with an When the time server is out of the reach from XNET, you can Internet assign time server by filling in Specific Time Server field. Time Server...

  • Page 26: Sensor & Capture Setup

    XNET Network Video Server User’s Guide 5.5. Sensor & Capture Setup This is the setup page for sensors and video capture conditions. Captured video can be sent to user by FTP or E-mail upon configuration. Figure 5-7. Sensor & Capture Setup...
  • Page 27 Normal Open and Normal Close. Name Input logical name for the sensor. It sets the condition of video transmission via FTP or E-mail. The XNET supports 2 types of conditions which are mutually independent. Video Capture Sensor Check to enable Sensor initiated capture.

  • Page 28: Alarm Device Setup

    XNET Network Video Server User’s Guide 5.6. Alarm Device Setup Test the alarm output and describe the condition of alarm annunciation. Figure 5-8. Alarm Output Setup Sub Field Field/Button Description /Button Test alarm devices. Click on On/Off for testing. Small box with white background indicates the status of the Alarm Device relay by On/Off.

  • Page 29: Motion Region Setup

    XNET Network Video Server User’s Guide 5.7. Motion Region Setup Set the motion detection regions. Up to 3 regions can be defined. Figure 5-9. Motion Region Setup 29 of 44...
  • Page 30 XNET Network Video Server User’s Guide Sub Field Field/Button Description /Button Channel Not applicable. Selection Channel Set the sensitivity in motion detection for each channel. 1 is Sensitivity the most sensitive, and 10 is the least sensitive. Set up to 3 the motion detection zone Enable each zone by checking the box at the left of each Region.

  • Page 31: Ptz Setup

    XNET Network Video Server User’s Guide 5.8. PTZ Setup Setup and test the PT(Pan/Tilt) devices. Figure 5-10. PTZ Setup Sub Field Field/Button Description /Button Channel Not applicable Selection PTZ Model Choose the PT model. Selection Refer to section 5.12 for the addition of PT protocol data.
  • Page 32 XNET Network Video Server User’s Guide Check “Left”/”Right”/”UP”/”DOWN” You can set up the PTZ limitation & preset positions if the PT device supports it. Panning Set the left/right limitation and test. Limitation Select Left/Right position before setting. Panning Clear the panning limitation previously set.

  • Page 33: Encryption Set Up

    XNET Network Video Server User’s Guide 5.9. Encryption Set up Figure 5-11. Encryption Setup For additional security to the video and audio data transmitted from the network camera, you can set key codes and use them for encrypting the data from the network camera.
  • Page 34 XNET Network Video Server User’s Guide Sub Field Field/Button Description /Button Check at this box to apply data encryption. If it is unchecked encryption is applied on neither video nor audio data regardless of the selection below. Enable Data Encryption Video Check to enable encryption on the video data.

  • Page 35: Upgrade & Reset

    XNET Network Video Server User’s Guide 5.10. Upgrade & Reset You can upgrade the XNET via the IP network. Figure 5-12. Upgrade & Reset For each of the upgrade of the system component, upgrade code should be downloaded from cnbtec‟s home page before the system upgrade is performed.
  • Page 36 System software needed for the upgrade Upgrade can be downloaded from cnbtec‟s home page. Refer to [6.4. How To Upgrade Your XNET System]. Upgrade the bootloader installed in the network camera via Bootloader the network. Bootloader needed for the upgrade can be Upgrade downloaded from cnbtec‟s home page.

  • Page 37: Status Report

    XNET Network Video Server User’s Guide 5.11. Status Report It shows you system records since the system started. Figure 5-13. Status Report You can check the problems as well as the versions and event status of the whole system and each module.

  • Page 38: Tips For Using Xnet

    XNET Network Video Server User’s Guide 6. Tips for using XNET 6.1. ALARM-IN and ALARM-OUT ALARM connectors are used to connect various sensing and alerting devices. Examples of sensing devices are infrared sensors, motion sensors, heat/smoke sensors, magnetic sensor, etc.
  • Page 39 XNET Network Video Server User’s Guide Figure 6-2. SENSOR input 6.1.2. ALARM-OUT A Relay output is provided for connecting alarm devices or for remote on/off devices such as light control. Relay circuits are normal open and circuits are closed upon alarm output or remote on.
  • Page 40 XNET Network Video Server User’s Guide Connection of Sensor Photo Coupler NO/NCType Open CollectorType Sensor1+ Sensor Sensor Device Device Sensor1- +12V Sensor Sensor Power Power Supply Supply Connection of Relay Relay Switch Power Supply Alarm 1V~30VDC/AC,1A Device Power Supply(30V Optional...

  • Page 41: Trouble Shooting

    XNET Network Video Server User’s Guide 6.2. Trouble Shooting 1. After XNET is successfully installed.  XNET in viewing mode, neither channel name nor video is display and eventually timeout message is shown up. Check the power and network connection of XNET.

  • Page 42: Web Viewer

    Users are recommended to adjust resolution and frame rates to lower values for lower bandwidth network. 6.3. Web Viewer XNET is designed to be connected through internet explorer, too. For connection to XNET using internet explorer type in IP address or host address in the address input field of the internet explorer.
  • Page 43 PC is delivered to XNET. Capture and store the still image on your desk top screen. Connect to XNET in administrative mode of XNET. Rotate the screen by 180 degree. Connect to XNET. Stop the connection.

  • Page 44: How To Upgrade The Xnet

    XNET Network Video Server User’s Guide 6.4. How to Upgrade the XNET Unless otherwise instructed, the owners of the XNET are recommended to upgrade the system when upgraded firmware is released using manual upgrade procedure. Followings are the procedure to apply for the manual upgrade 1) Save the upgrade system software to your PC.
