Kingston Technology KHX16C10B1RK2/16X Specifications

Memory Module Specifi cations
KHX16C10B1RK2/16X
16GB (8GB 1G x 64-Bit x 2 pcs.)
DDR3-1600 CL10 240-Pin DIMM Kit
DESCRIPTION
Kingston's KHX16C10B1RK2/16X is a kit of two 1G x 64-bit
(8GB) DDR3-1600 CL10 SDRAM (Synchronous DRAM) 2Rx8
memory modules, based on sixteen 512M x 8-bit DDR3 FBGA
components per module. Each module kit supports Intel
(Extreme Memory Profiles). Total kit capacity is 16GB. Each
module kit has been tested to run at DDR3-1600 at a low
latency timing of 10-10-10 at 1.5V. The SPDs are programmed
to JEDEC standard latency DDR3-1333 timing of 9-9-9 at 1.5V.
Each 240-pin DIMM uses gold contact fingers and requires
+1.5V. The JEDEC standard electrical and mechanical specifi-
cations are as follows:
XMP TIMING PARAMETERS
•
JEDEC: DDR3-1333 CL9-9-9 @1.5V
•
XMP Profile #1: D3-1600 CL10-10-10 @1.5V

SPECIFICATIONS

CL(IDD)
Row Cycle Time (tRCmin)
Refresh to Active/Refresh
Command Time (tRFCmin)
Row Active Time (tRASmin)
Maximum Operating Power
UL Rating
Operating Temperature
Storage Temperature
*Power will vary depending on the SDRAM used.
FEATURES
•
JEDEC standard 1.5V (1.425V ~ 1.575V) Power Supply
•
VDDQ = 1.5V (1.425V ~ 1.575V)
•
667MHz fCK for 1333Mb/sec/pin
® XMP
•
8 independent internal bank
•
Programmable CAS Latency: 9, 8, 7, 6
•
Posted CAS
•
Programmable Additive Latency: 0, CL - 2, or CL - 1 clock
•
Programmable CAS Write Latency(CWL) = 7 (DDR3-1333)
•
8-bit pre-fetch
•
Burst Length: 8 (Interleave without any limit, sequential with
starting address "000" only), 4 with tCCD = 4 which does not
allow seamless read or write [either on the fly using A12 or
MRS]
•
Bi-directional Differential Data Strobe
•
Internal(self) calibration : Internal self calibration through ZQ
pin (RZQ : 240 ohm ± 1%)
•
On Die Termination using ODT pin
•
Average Refresh Period 7.8us at lower than TCASE 85°C,
3.9us at 85°C < TCASE < 95°C
•
Asynchronous Reset
•
PCB : Height 1.180" (30.00mm), double sided component
Document No. 4806495-001.A00
9 cycles
49.5ns (min.)
260ns (min.)
36ns (min.)
2.460 W* (per module)
94 V - 0
0 o C to 85 o C
o o
-55 C to +100 C
Continued >>
08/16/12 Page 1
