- Page 1 INSTALLATION, OPERATION & MAINTENANCE MANUAL Portable Room Air Conditioner PS-81A PS-101A PS-121A French version of this manual is available on our website AITONS EQUIPMENT • Guelph, ON N1H 6H9 • 1-888-744-2911 • www.aitons.com...
-
Page 2: Table Of Contents
PS-81, 101, 121A Installation, Operation & Maintenance AITONS EQUIPMENT TABLE OF CONTENTS SAFETY PRECAUTIONS SAFETY PRECAUTIONS Safety rules........................3 Safety rules ............................3 Operating conditions .........................3 Operating conditions......................3 Electrical information..........................4 Electrical information ......................4 IDENTIFICATION OF PARTS IDENTIFICATION OF PARTS Accessories ............................4 Accessories ........................4 Identification of parts..........................5 ......................5 AIR CONDITIONER FEATURES... -
Page 3: Safety Precautions Safety Rules
PS-81, 101, 121A Installation, Operation & Maintenance AITONS EQUIPMENT SAFETY PRECAUTIONS Safety rules To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring the instructions may cause harm or damage. Always do this Never do this Do not operate your air conditioner in a damp/... -
Page 4: Electrical Information
PS-81, 101, 121A AITONS EQUIPMENT Installation, Operation & Maintenance IDENTIFICATION OF PARTS For your safety WARNING Do not store or use gasoline or other flammable substances/vapors in the vicinity of this or any other appliance. To avoid fire hazard or electric shock, do not use an extension cord or an adaptor plug. Do not remove any prong from the power cord. -
Page 5: Identification Of Parts
PS-81, 101, 121A Installation, Operation & Maintenance AITONS EQUIPMENT IDENTIFICATION OF PARTS Front Control Panel Horizontal Louver Blade (swings automatically) Casters Carrying Handles (both sides) Fig.1 Rear Upper Air Filter (Behind the grille) Air Outlet Power cord outlet Air intake Drain Outlet Air intake Lower Air Filter... -
Page 6: Air Conditioner Features
PS-81, 101, 121A AITONS EQUIPMENT Installation, Operation & Maintenance AIR CONDITIONER FEATURES ELECTRONIC CONTROL OPERATING INSTRUCTIONS Before you begin, thoroughly familiarize yourself with the functions control panel and remote controller. The unit can be controlled by the unit control panel alone or with the remote controller . NOTE: This manual does not include Remote Controller Operations, see the <<Remote Controller Instruction>>... -
Page 7: Operating Instructions
PS-81, 101, 121A Installation, Operation & Maintenance AITONS EQUIPMENT OPERATING INSTRUCTIONS SWING button FAN operation Used to initiate the automatic swing function. Press the "MODE" button until the When the swing mode is on, press the swing "FAN " indicator light comes on. button to stop the lover at the desired angle. -
Page 8: Operating Instructions
PS-81, 101, 121A AITONS EQUIPMENT Installation, Operation & Maintenance OPERATING INSTRUCTIONS Other features Auto-Restart If there is a loss of power, once power is restored, the unit will automatically reset in the last mode it was operating prior to the power failure. Compressor Time Delay After the unit has stopped, it can not be restarted for 3 minutes. -
Page 9: Installation Instructions
PS-81, 101, 121A Installation, Operation & Maintenance AITONS EQUIPMENT INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS Location The air conditioner should be placed on a firm foundation to minimize noise and virbration. For safe and secure positioning, place the unit on a smooth, level floor strong enough to support the unit. The unit has casters to aid placement, but it should only be rolled on smooth, flat surfaces. - Page 10 PS-81, 101, 121A AITONS EQUIPMENT Installation, Operation & Maintenance INSTALLATION INSTRUCTIONS Installation in a double-hung sash window Foam seal A (adhesive type) 1. Cut the foam seal (adhesive type) to the proper length and attach it to the window stool. Fig.8 e unit.
-
Page 11: Installation In A Sliding Sash Window
PS-81, 101, 121A Installation, Operation & Maintenance AITONS EQUIPMENT INSTALLATION INSTRUCTIONS Installation in a sliding sash window 1. Cut the foam seal (adhesive type) to the proper length and Foam seal A (adhesive type) attach it to the window frame. See Fig.12. 2. -
Page 12: Exhaust Hose Installation
PS-81, 101, 121A AITONS EQUIPMENT Installation, Operation & Maintenance INSTALLATION INSTRUCTIONS Exhaust hose installation: The exhaust hose and adaptor must be installed or removed in accordance with the usage mode. COOL or AUTO mode Install Fig.16 FAN, OR DEHUMIDIFY mode Remove Hole seat Hook... -
Page 13: Condensate Drainage
PS-81, 101, 121A Installation, Operation & Maintenance AITONS EQUIPMENT INSTALLATION INSTRUCTIONS Condensate drainage: While operating in Dry (dehumidifying) mode, Remove the remove the drain plug from the back of the unit, drain plug install the drain connector (5/8” universal female mender) with 3/4”... -
Page 14: Care And Maintenance
PS-81, 101, 121A AITONS EQUIPMENT Installation, Operation & Maintenance CARE AND MAINTENANCE CARE AND MAINTENANCE Air filter (slide out) IMPORTANT: ode, 1) Be sure to unplug the unit before cleaning or servicing. e unit, 2) Do not use gasoline, paint thinner or other chemicals to clean female the unit. -
Page 15: Troubleshooting Tips
