5.3
Power board
No 1
Connector
Connector to main board details
Pin
Signal
1
+12.25V
2
+12.25V
3
+12.25V
4
GND
5
GND
6
GND
7
GND
8
PFC - ON
P1165E&P5260E
No 2
No 3
No 1
No 2
No 3
No 4
8
1
9
16
Pin
Signal
9
GND
10
GND
11
GND
12
GND
13
GND
14
+12.25V
15
+12.25V
16
+12.25V
No 4
Description
Connect to main board
Safety switch
Power supply for ballast
Thermal sensor
37
