Nav6 Plus Navtex System User Guide
etc.
•
On a yacht, pushpit mounting is permissible.
Note: due to the variety of possible mounting methods (horizontal
rail, vertical rail, deck, etc) ICS do not supply the antenna mounting
bracket as standard. They are readily available from most marine
electronics stores.
Mounting the Sensor Unit Mounting the Sensor Unit
Mounting the Sensor Unit Mounting the Sensor Unit
•
First, fix the antenna mount in the desired location.
•
If required, thread the sensor cable through the antenna mount
(if the antenna mount thread has a slot to accept the sensor
cable mount this may not be necessary).
•
Now fit the Sensor Unit on top of the antenna mount.
•
Holding the top of the Sensor Unit, rotate the large plastic nut on
the bottom in order to engage the thread of the antenna mount.
•
Continue to tighten the nut until the Sensor Unit is locked.
•
Note that it is possible to position the Sensor Unit to face
whichever way the user desires.
•
Do not use a wrench to tighten the nut – hand-tighten only.
Mounting the optional 45cm Extension Whip Mounting the optional 45cm Extension Whip Mounting the optional 45cm Extension Whip Mounting the optional 45cm Extension Whip
•
Remove the red plastic plug on the top of the Sensor Unit.
•
Screw in the Extension Whip.
•
It is advisable to apply a smear of grease to the thread to ensure
that salt deposits do not cause the thread to seize up.
Connections to the Sensor Unit Connections to the Sensor Unit
Connections to the Sensor Unit Connections to the Sensor Unit
The sensor cable should be routed back to the intended location of
the Display Unit. We do not recommend cutting the cable, but this
may be done if, necessary, without effecting the performance of the
product.
Note that the sensor cable consists of two twisted pairs, one for
power and one for serial data communications.
39
