Turbo BTE3211ALP Operator's Manual

Lp/ng gas grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

By Barbeques Galore.
Liquid Propane Gas (LPG) Grill
Models BTE3211ALP, BTE3811ALP
Natural Gas (NG ) Grill
Models BTE3211ANG, BTE3811ANG
FREE HELP
Grill Information Center:
FROM THE GRILL EXPERTS
Grand Hall is the expert on this product
and trained to help you with:
Ÿ
Assembly Questions
Ÿ
Grill Operation
Ÿ
Replacement of Damaged or Missing parts
visit www.grandhall.com or call:
1-877-934-7455
Monday - Friday 8:00am-4:30pm CST
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL #
__________________
(see silver CSA label on main body of grill)
R
BTE3211ALP/NG
Operator's Manual
BTE3811ALP/NG
WARNING
!
Ÿ
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property damage.
Ÿ
Whether this grill was assembled by you or
someone else, you must read this entire manual
before using your grill to ensure the grill is
properly assembled, installed and maintained.
Ÿ
Use your grill at least 3 feet away from any
wall or surface. Use your grill at least 3 feet
away from combustible objects that can melt or
catch fire such as vinyl or wood siding, fences
and overhangs or sources of ignition including
pilot lights on water heaters and live electrical
appliances.
Ÿ
THIS GAS APPLIANCE IS DESIGNED FOR OUT-
DOOR USE ONLY.
Ÿ
Never use this gas appliance on a balcony, deck,
or patio above the ground floor of your home.
Ÿ
Never use your gas grill in a garage, porch,
shed, breezeway or any other enclosed area.
Ÿ
Never obstruct the flow of ventilation air
around your gas grill housing.
Never disconnect the gas regulator or any gas
fitting while your grill is lit. A lit grill can ignite
leaking gas and cause a fire or explosion which
could result in property damage, personal injury
or death.
Manual # P80151126A - Date:2011/ 01/14
!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTE3211ALP and is the answer not in the manual?

Questions and answers

Related Manuals for Turbo BTE3211ALP

Summary of Contents for Turbo BTE3211ALP

  • Page 1: Primary Safety Warnings

    Operator's Manual By Barbeques Galore. Liquid Propane Gas (LPG) Grill Models BTE3211ALP, BTE3811ALP Natural Gas (NG ) Grill Models BTE3211ANG, BTE3811ANG BTE3211ALP/NG BTE3811ALP/NG FREE HELP WARNING Grill Information Center: FROM THE GRILL EXPERTS Ÿ Failure to comply with these instructions could...
