Touch Panel Controllers
User Manual
10.12.2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the uniCUE-7-B and is the answer not in the manual?

Questions and answers

Summary of Contents for CUE uniCUE-7-B

  • Page 1 Touch Panel Controllers User Manual 10.12.2012...
  • Page 2: Table Of Contents

    RELAY AUDIO LINE CUEwire Device Connection 26 Download User Application Overview Using Cue Visual Composer Using Admin Web UM045_01_Touch_Panel_Controllers 10.12.2012 © CUE, a.s., Praha, Czech Republic 1990 - 2011 All rights reserved. Specifications are subject to change without prior notice.
  • Page 3: Introduction

    The IR sensor located on a front panel can receive IR signal from CUE wireless IR control panels without the need to use any external IR receiver. In addition uniCUEs are equipped with internal IR sensor allowing to capture IR codes.
  • Page 4: Application Diagram

    Touch Panel Controllers / Application Diagram Application Diagram Devices can be controlled using IP, serial channels, IR channels, general I/Os and relays. All CUE keypads, keyboards and interfaces can be connected using RS-485 serial ports. In addition uniCUE is fully compatible with other CUEunits such as touch panels and controllers connected via Ethernet.
  • Page 5: Box Contents

    Touch panel controller uniCUE-7-B Touch panel controller uniCUE-12-B Power supply 30 W Power cable Ethernet cable straight-through IR Adapter /i Connector set CE declaration RoHS declaration Data Sheet Cue System Connector Wiring © CUE, a.s. All Rights Reserved.
  • Page 6: Specifications

    Digital open collector output max. 80 mA, 5-pin connector with common ground 2x Relay NO-C-NC, 24 V, max. 0.5 A, 6-pin connector Software XPL2 runtime for application created in Cue Visual Composer Admin Web for setup Video Streaming video preview...
  • Page 7: Physical Description

    IR Receiver The built-in IR sensor carries the same functionality as irCUE Receiver or irCUE Receiver 485. This means that touch panel can receive IR signal from CUE wireless IR control panels without the need to use any external IR receiver.
  • Page 8: Rear Panel

    Powering of uniCUE is provided by 24 VDC. Use only delivered power supply. Control Ports Rear panel of uniCUE is equipped with following control ports ▪ 2x Serial port ES-232/422/485 ▪ 4x IR/Serial port ▪ 4x General I/O ▪ 2x Relay 24 V, NO-C-NC contacts © CUE, a.s. All Rights Reserved.
  • Page 9: Dimensions

    PROPERTY OF FAKTUM DESIGN 617 00 BRNO ANY REPRODUCTION IN PART OR DEBUR AND BREAK TEL.: 545 210 633 AS A WHOLE WITHOUT THE WRITTEN WWW.FAKTUM.CZ PERMISSION OF FAKTUM DESIGN SHARP EDGES SCAL IS PROHIBITED. © CUE, a.s. All Rights Reserved.
  • Page 10: Mounting

    Mounting Back Box Physical Description The back box (product code CS0409) provides a steel enclosure for uniCUE-7-B and uniCUE-12-B build-in touch touch panel controllers. It is designed for pre-construction applications. The back box is equipped with knockouts for cable installation.
  • Page 11 Insert the back box 2 into the cut-out 1 and take the cables through broken off knockout. Fasten 2x support 4 to the wall using screws 5. Adjust the metal holder 7 as described in the chapter Adjusting the Panel on the Wall. © CUE, a.s. All Rights Reserved.
  • Page 12 Fix the back box 2 with mortar or plaster. Neaten the visible front part of the back box with stuke or another appropriate material. Adjust the metal holder 7 as described in the chapter Adjusting the Panel on the Wall. © CUE, a.s. All Rights Reserved.
  • Page 13: Adjusting Unit On The Wall

    617 00 BRNO ANY REPRODUCTION IN PART OR DEBUR AND BREAK TEL.: 545 210 633 AS A WHOLE WITHOUT THE WRITTEN WWW.FAKTUM.CZ PERMISSION OF FAKTUM DESIGN SHARP EDGES SCALE: 1:1 IS PROHIBITED. SHEET 1 OF 1 © CUE, a.s. All Rights Reserved.
  • Page 14: Placing Unit Into The Back Box

    Note: If the touch panel does not adhere to the wall perfectly, you can adjust it as described in the capture Adjusting the Panel on the Wall. © CUE, a.s. All Rights Reserved.
  • Page 15: Taking Unit Out

    Hold the panel upright and pull its bottom part If you need to remove the panel out out. In this position you can tilt the panel to completely, hold it upright, push mount cables. downwards and pull it out. © CUE, a.s. All Rights Reserved.
  • Page 16: Cleaning

    Turn the touch panel off. Spray a small amount of the cleaning solution onto one of the cloths. Clean the touch panel overlay with the damp cloth. Wipe the touch panel overlay with the dry cloth. © CUE, a.s. All Rights Reserved.
  • Page 17: Connecting

    S G S G S G S G S S S S G NC C NO NC C NO SYSTEM AUDIO LINE DEFAULT 5 V DC L G R Audio line output Audio line output Output 5 VDC Button system default © CUE, a.s. All Rights Reserved.
  • Page 18: Cuenet (Lan)

    LAN Network Connection Attach one end of an RJ-45 Ethernet straight-through cable to the CUEnet (LAN) port and attach the other end of the RJ-45 Ethernet cable to your computer. Network Ethernet cable straight-through © CUE, a.s. All Rights Reserved.
  • Page 19 Set IP address to 192.168.1.1 (or other then right-click and select Properties. address different from 192.168.1.127 and from 192.168.1.128) and Subnet mask to Select Internet Protocol (TCP/IP) and click 255.255.255.0. Leave other options unchanged Properties button. and click OK. © CUE, a.s. All Rights Reserved.
  • Page 20: Pwr In

    Connector pin out PWR IN 2-pin 3.5 mm Description Power +24 VDC Ground OUT 5 V Connector pin out PWR OUT 2-pin 3.5 mm Description Output +5 VDC, max. 1 A Ground © CUE, a.s. All Rights Reserved.
  • Page 21: Serial

    SERIAL RS-485 5-pin 3.5 mm Signal Description RS-422 Transmit Data (Idles High) RS-422 Transmit Data (Idles Low) Ground 1 2 3 4 5 N.C. RS-422 Receive Data (Idles High) N.C. RS-422 Receive Data (Idles Low) © CUE, a.s. All Rights Reserved.
  • Page 22: Ir/Serial

    Up to ten IR Sprayers can be connected to each output in parallel ▪ It is not recommended to connect more infra-red emitters of various manufacturers in parallel because the output can be either overloaded or damaged. © CUE, a.s. All Rights Reserved.
  • Page 23: General I/O

    Digital output can switch max. 24 VDC / 80 mA. Output voltage for output switch on is approx. 0.6 V. I/O schematic diagram Connector pin out GENERAL I/O 5-pin 3.5 mm Signal Description 1 2 3 4 Signal Input / Output Signal 1 - 4 Common ground for all I/Os © CUE, a.s. All Rights Reserved.
  • Page 24: Relay

    This connector provides un-amplified unbalanced line level audio. Connect audio devices, such as an audio amplifier or powered speakers to this connector. Connector pin out AUDIO LINE OUT 3-pin 3.5 mm Signal Description Left Left channel Ground L G R Right Right channel © CUE, a.s. All Rights Reserved.
  • Page 25: Cuewire Device Connection

    1 2 3 4 5 S G S G S G S G S S S S G NC C NO NC C NO SYSTEM AUDIO LINE DEFAULT 5 V DC L G R © CUE, a.s. All Rights Reserved.
  • Page 26: Download User Application Overview

    Touch Panel Controllers / Download User Application Download User Application Overview User control application is dedicated to control and it is programmed by Cue Visual Composer programming tools. Using Cue Visual Composer Steps are Connect touch panel controller to your computer as described in chapter Connecting / CUEnet (LAN).
  • Page 27: Using Admin Web

    Use button Export All... to export application and store it in file *.cvca. Run the Internet browser on your PC and type in the same touch panel IP address as you see in Cue Visual Composer project, window Properties / IP address.
  • Page 28: Ir Capture

    IR remoter Start Cue Visual Composer and capture IR codes by standard way. Push Start Capture button in Cue Visual Composer and then press appropriate button on IR remoter. Button Start Capture Instructions and messages are displayed on the touch panel and in the Cue Visual Composer.
  • Page 29: Factory Default And System Default

    Use Internet clock Not changed Primary NTP server Empty Not changed Secondary NTP server Empty Not changed Applications Empty Not changed File storage Empty Not changed System Firmware Current version Not changed Password Empty Empty © CUE, a.s. All Rights Reserved.
  • Page 30: On Screen Display

    If Motion Sensor is switched to Yes the Motion Sensor resumes touch panel from Backlight Saver mode automatically. Status This page shows current status of the touch panel. © CUE, a.s. All Rights Reserved.
  • Page 31: Ip Settings

    (and any changes you elect to make to the IP address, subnet 192.168.1.1 mask, or default gateway). This information must be entered into the Cue Visual Composer program written for your specific application. For control systems with more than one unit, a unique IP address must be given to each CUEunit.
  • Page 32: Applications

    The running application can be stopped via the Stop button. Files are uploaded from a personal computer to the touch panel using Cue Visual Composer software or using Admin Web. Calibration Use this page for calibration. We recommend use stylus.
  • Page 33: Admin Web

    (and any changes you elect to make to the IP address, subnet mask, or default gateway). This information must be entered into the Cue Visual Composer program written for your specific application. For control systems with more than one CUEunits, a unique IP address must be given to each CUEunit.
  • Page 34 Set a name or an address and the port of your SMTP server. The SMTP server and port are used by the XPL2 commands EmailSend and PresetEmailSend. Be sure to click the Apply button for any changes to become effective! © CUE, a.s. All Rights Reserved.
  • Page 35: Date And Time

    NTP servers. Use the Primary NTP server and Secondary NTP server boxes for this purpose. Be sure to click the Apply button for any changes to the internet clock to become effective! © CUE, a.s. All Rights Reserved.
  • Page 36: Applications

    Touch Panel Controllers / Admin Web Applications This page is used for uploading compiled Cue Visual Composer programs to your CUEunit. All uploaded applications are listed on this page, along with their file properties: file name/file size/date. The CUEunit has a generous memory; unused free space is shown at the bottom of this page.
  • Page 37: Settings

    In addition some settings done by On Screen Display can be enabled or disabled. Calibration Use this page to start calibration and follow instructions on the touch panel. For proper calibration use a stylus. © CUE, a.s. All Rights Reserved.
  • Page 38: System

    Confirm new password box. An error message will appear if the confirmation does not match, in which case you should reenter your password again in both boxes. Finally, the new password is implemented by clicking the Apply button. © CUE, a.s. All Rights Reserved.
  • Page 39: Backup

    If you want to retain them, use the Backup command before the Restore command. Note: To see the backed-up/restored applications, click the Applications menu. To see backed-up/ restored files and folders, click the File Storage menu. © CUE, a.s. All Rights Reserved.
  • Page 40: Reset

    Touch Panel Controllers / Admin Web Reset To restart your CUEunit, click the Reset button. License This page describes software license. © CUE, a.s. All Rights Reserved.
  • Page 41: Software And Firmware License

    MATERIALS IN YOUR POSSESSION REGARDING THE SOFTWARE. License Grant: CUE grants to You, as an individual, a license to install and use one (1) copy of the Software on a single computer at a time; provided, however, that You may make copies of the Software solely for Your development of applications for CUE hardware and demonstration versions of such applications.
  • Page 42: Notes

    Touch Panel Controllers / Notes Notes ....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................© CUE, a.s. All Rights Reserved.
  • Page 43 Touch Panel Controllers / Notes ......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................© CUE, a.s. All Rights Reserved.
  • Page 44 CUE, a.s. K Nouzovu 6, 143 00 Praha 4, Czech Republic www.cuesystem.com support@cuesystem.com...
