Summary of Contents for ArcVision ARC19805

  • Page 1 Digital Video Recorder Thank you for purchasing our product. Please read this User Manual before using the product. Manual V1.2 - 1 -...
  • Page 2 SAFETY PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN! CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This label may appear on the bottom of the unit due to space limitations. The lightning flash with an arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “...
  • Page 3: Table Of Contents

    Contents 1.OVERVIEW ......................4 (1)A ....................4 BOUT THIS ANUAL (2)T ....................4 YSTEM (3)F .......................5 EATURES 2.INSTALLATION ......................6 (1)C &M ................6 AMERA ONITOR ONNECTION (2)S .....................7 ENSOR CONNECTION (3)P ....................7 OWER CONNECTION 3.UNIT DESCRIPTION....................8 (1)F ......................8 RONT ANEL (2)R ......................9 ANEL 4.MAIN SCREEN ......................10 5.MAIN MENU ......................
  • Page 4: Overview

    1.OVERVIEW (1)About this Manual This manual describes the procedures for operating the four-channel digital video recorder (DVR). This manual describes each function using text instruction and Graphic User Interface (GUI). Appendix A contains quick reference guide for front panel controls. (2)The Menu System The menu system is used to configure the DVR and gives control over recording resolution, camera sequencing, timer settings and alarm triggering and alarm...
  • Page 5: Features

    (3)Features Your four-channel color DVR provides real-time live playback monitoring, and recording features, with quad-mode processing or each-mode recording. Also offers the following features: ․NTSC/PAL Compatible (Selector Switch). ․Cost effective Digital Video Solution. ․Compact Size. ․User-friendly Menu System. ․Flexible Recording Rate: Quad Mode Max.: 30fps (NTSC);...
  • Page 6: Installation

    2.INSTALLATION (1)Camera&Monitor Connection Connect camera to the CAMERA INPUT(1~4) and Monitor on the rear panel of unit. - 6 -...
  • Page 7: Sensor Connection

    (2)Sensor connection Connect sensors to D-SUB 10 Pin as specified below. Connecting dry-contact type sensors(switches)are recommended. In case of sensors with a voltage output(5V system),GND of sensor must be connected to GND of DVR unit and the signal line to an alarm input as shown in following figure. Short-circuit between any of 0 from 15 and GND is recognized as an alarm.
  • Page 8: Unit Description

    3.Unit Description (1) Front Panel POWER LED ․The power LED is lit when the DVR is ON. ① . CAMERA Number Button (1-4) ․Select the camera (1-4) image in live recording and playback mode. ② . QUAD ․Changes to(4) quarterly split screen or full display screen. ③...
  • Page 9: Rear Panel

    ⑪ . PLAY : ․To playback recorded images. ․When the Playback key is pressed, you will be asked to input the time period (time of previous recorded video) for searching purpose, then press the Playback key again to view the selected videos. ⑫...
  • Page 10: Main Screen

    4.MAIN SCREEN Example Note: The above picture shows: CH2:Not Recording EACH: Record Mode (T):Record Schedule (M):Master HDD is use - 10 -...
  • Page 11: Main Menu

    5.MAIN MENU MAIN MENU CAMERA SELECT RECORD SELECT RECORD MODE RECORD FRAMERATE VIDEO QUALITY RECORD SCHEDULE SUB MENU HARD DRIVE SETUP SENSOR SETUP < > PRESS( ), THEN (ENTER) PRESS (MENU) TO EXIT You can see the arrow(>)symbol on screen in front of the current function to be selected.
  • Page 12: Camera Selection

    (1) CAMERA SELECTION This function is used for setting up camera views. It consists of 16 different optional camera view combinations. Move the cursor to Camera Select field, and press ENTER to display the system information to change the camera view combinations. After the Camera Select field has been set, the cameras that are selected (during setup) will be displayed (The default setting is “----“).
  • Page 13: Record Frame Rate

    (4) RECORD FRAME RATE When “RECORD FRAME RATE” is selected, you may choose the following recording speeds for “Quad” mode: NTSC:30,15,10,7,5,4,3,2,1fps. PAL :25,12,8,6,4,3,2,1fps. Likewise, you may choose the following recording speeds per channel when using 4 cameras in “EACH” mode: NTSC:30,15,10,7,5,4,3,2,1fps.
  • Page 14: Video Quality

    (5) VIDEO QUALITY This function provides for the adjustment of the image quality: LOW/ NORMAL / HIGH Move to the Record Frame Rate field, and press ENTER . Set the recording image quality from the three options. Press MENU to exit the Video Quality. NOTE: Higher quality images require more recording (HDD storage) space.
  • Page 15: Sub Menu

    (7) SUB MENU SUB MENU PASSWORD CHANGE TIME SET < > PRESS( ), THEN (ENTER) PRESS (MENU) TO EXI Password Change (A password is required to format (erase) the hard drive). 1)When you select, “PASSWORD CHANGE”, a password input menu replaces the “Sub Menu”.
  • Page 16 TIME SET Below is a graphic of the “Time Menu” screen: TIME MENU TIME 2003/01/01 01:01:00 2003/01/01 01:01:00 PRESS( ), THEN (ENTER) PRESS (MENU) TO EXIT PRESS(<,>), THEN (SELECT) PRESS (MENU) TO EXIT When you select the” TIME SET” the above menu is shown. Use the”...
  • Page 17: Hard Drive Setup

    (8) HARD DRIVE SETUP This menu displays the size of the hard disk and the remaining storage space. HARD DRIVE SETUP OVERWRITE ENABLED MASTER HDD SIZE 39266MB MASTER HDD SIZE USED 0MB % MASTER HDD SIZE FORMAT SLAVE HDD SIZE SLAVE HDD USED SLAVE HDD FORMAT Move to the Hard Drive Setup Menu and press ENTER .
  • Page 18: Alarm Sensor Setup

    (9) ALARM SENSOR SETUP SENSOR SETUP SENSOR RECORD TIME 30 ALARM OUT TIME CHANNEL-1 NOT INSTAL LLED CHANNEL-2 NOT INSTAL LLED CHANNEL-3 NOT INSTAL LLED CHANNEL-4 NOT INSTAL LLED < > PRESS( ), THEN (ENTER) PRESS (MENU) TO EXIT Sensor Record Time This function provides the setup of sensor recording time after a sensor device has been triggered.
  • Page 19: Play

    6.PLAY SEARCH TIME HARD DRIVE:MASTER 13/06/05 13:52:34~13/06-05 13:52:36 >01 TIME 13/06/05 13:52:34 <,> )MOVE(ENTER)CHANGE(PLAY)PLAY (MENU)EXIT(FF)SELECT EVENT OR TIME > 01 TIME the latest recording the earliest recording Press the PLAY button to display the time-search menu Press the PLAY button again to start playback. You can play back a recording from a specific event by moving the cursor (>) and pressing the PLAY button.
  • Page 20: Specification

    7.Specification Item Description Remarks NTSC/PAL Video Input Format 4CH Composite Video Input Channel 1CH Composite Video Output Channel NTSC 120 fields/s 4*30 fields/s Display Frame 100 fields/s 4*25ields/s NTSC Max.30fps(Quad) Recording Frame Max.25fps(Quad) Rate(Quad Mode) NTSC Max.7.5fields/s(Each Mode) fields/s(per Recording Frame Each Mode=Max...
  • Page 21 Item Description Remarks Operation temperature 41f~104f( ~40 ) Operation humidity LESS THAN90% Weight Approx 4KG Power supply DC 12V/4A - 21 -...
