Genelec 4010A Operating Manual page 3

Figure 1. Location of the acoustic axis
MAINS
SWITCH
MAINS
CONNECTOR
Figure 3. Control and connector layout on the rear panel of a 4010A.
2 English
ACOUSTIC
AXIS
WARNING
ELECTRIC SHOCK HAZARD. DO NOT OPEN. DO NOT SUBJECT
TO WATER OR MOISTURE. NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
AVERTISSEMENT
RISQUE DE CHOC ÉLECTRIQUE. NE PAS OUVRIR. NE PAS
EXPOSER À L'EAU OU L'HUMIDITÉ. AUCUN COMPOSANT À
L'INTÉRIEUR REMPLAÇABLE PAR L'UTILISATEUR. ADRESSER
TOUTE RÉPARATION À UN PERSONNEL QUALIFIÉ.
ON ISS DISABLE
SENSITIVITY -10 dB
TREBLE TILT +2 dB
BASS TILT -2 dB
BASS TILT -4 dB
MAINS INPUT
50 / 60 Hz 30 W
100 - 240 V~
4010A
ACTIVE
SPEAKER SYSTEM
-
+ GND
MADE IN FINLAND www.genelec.com
710127
Figure 2. The pin sequence of the balanced au-
dio input.
ISS DISABLE,
SENSITIVITY -10 dB,
TREBLE TILT,
AND BASS TILT
CONTROLS
PHOENIX SIGNAL
INPUT CONNECTOR
