- Page 1 VDSL2 LAN Extender User Manual Version 1.00 December 2007...
-
Page 2: Copyright By Proscend Communications Inc., All Right Reserved
The information in this document has been checked carefully and is believed to be correct as of the date of publication. Proscend Communications Inc. reserves the right to make changes in the product of specification, or both, presented in this publication at any time without notice. -
Page 3: Table Of Contents
VDSL LAN Extender User Manual, V100 Tables of Contents Copyright by Proscend Communications Inc., all right reserved....1 Tables of Contents ..................2 Chapter 1 Introduction................ 3 Features ..........................3 Specification ........................3 Applications ........................4 Chapter 2 Hardware Installation ..............5 2.1 Front Panel ............................ -
Page 4: Chapter 1 Introduction
User Manual, V100 Chapter 1 Introduction Proscend 100 VDSL LAN Extender is a long reach Ethernet media converter with one Ethernet port (RJ-45 connector) and one VDSL port (RJ-45 connector) is a bridge mode modem, well accommodating VDSL2 (Very-high-data-rate Digital Subscribe Loop) technologies to extend Ethernet service over single-pair phone line. -
Page 5: Applications
VDSL LAN Extender User Manual, V100 1.3 Applications LAN Extender Application Page:4... -
Page 6: Chapter 2 Hardware Installation
VDSL LAN Extender User Manual, V100 Chapter 2 Hardware Installation This chapter shows the front panel and how to install the hardware. 2.1 Front Panel Please see the side view below configure 2.1: Front panel can be separated into five parts from left to right: (1) DIP switch (2) RJ-45 connector for Ethernet (3) LEDs for Ethernet... - Page 7 VDSL LAN Extender User Manual, V100 The following table describes the DIP Switchs’ setting. Pin 1 Pin 2 Pin 3 Pin 4 Side Channel Rate Limit Interleave Symmetric Fast Asymmetric Pin 1: CO, CPE switch GO: LAN Extender acts as Central Office (CO) side. GPE: LAN Extender acts as Customer Premise Equipment (CPE) side.
-
Page 8: Real Panel
VDSL LAN Extender User Manual, V100 The following table describes the LEDs’ function of the product. LEDs for VDSL blinking Device Power ON Device Power OFF CPE-mode CO-mode Slow: Idle Linked Off line Fast: Training 2.2 Real Panel The DC Jack on the rear panel can be connected to power supply adaptor with the DC input. -
Page 9: Appendix I
VDSL LAN Extender User Manual, V100 Appendix I Connector Architecture Ethernet Port Connector (RJ-45) The Ethernet Port interface is a 8 position Modular Jack. The table below displays the pin out assignments. Pin Number Assignment (MDI-X) Figure RX+; Receive data + RX-;... -
Page 10: Appendix Ii
VDSL LAN Extender User Manual, V100 Appendix II Chassis Accessory Proscend also provide the Mini-Chassis solution for application on the rack in CO side. The major factor of Chassis 800 is listed below: 2 U high Support 8-slot in one unit Two units of mini-chassis are able to fit into the 19-inch standard rack to support 16-slot in 2U height., as the illustration below...
